Summary of Contents for Hytera ADA-01
- Page 1 ADA-01 Wireless Audio Adapter ADA-01无线音频适配器 SM27W1 Wireless Remote Speaker Microphone SM27W1无线扬声器话筒 USER MANUAL 使用说明书...
-
Page 2: Copyright Information
Copyright Information please visit our website at: http://www.hytera.com. Instructions Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited (the Company) in the People's ● Ensure the distance between the wireless remote speaker Republic of China (PRC) and/or other countries or areas. The microphone (RSM) and the mobile radio is within 10 meters Company retains the ownership of its trademarks and product names. -
Page 3: Product Overview
Name Qty. Wireless Remote Speaker Microphone (RSM) Wireless Audio Adapter USB Data Cable Vehicle Charger Screws Part Name Part Name User Manual Push-to-Talk (PTT ) Key Speaker Top Key (TK) Male Buckle LED Indicator USB Port Wireless ring PTT mentioned in this manual is an optional Microphone Female Buckle accessory. -
Page 4: Led Indicator
Wireless Audio Adapter Wireless RSM Wireless Audio LED Indication Status Adapter Status Waiting for pairing Glows blue and connection of the wireless ring PTT Glows green Fully charged Specifications Part Name Part Name Item Description Indication Point Lock Knob Talk Time >... - Page 5 2. Rotate the lock knob clockwise to fasten it. Installing Wireless RSM Insert the male buckle of the wireless RSM into the female buckle of the vehicle charger, and then fix the wireless RSM against the vehicle charger. See the figure below. Installing Vehicle Charger Install the vehicle charger on a suitable place on the vehicle panel, and then use two screws to fix it.
-
Page 6: Basic Operations
● Wireless RSM: Long press the Power On/Off/Switch key until the Before use, charge the wireless RSM as follows: LCD displays "Select Power Off", and then press the Power On/ Use the USB data cable to connect the wireless RSM to the power Off/Switch key. -
Page 7: Adjusting The Volume
After successful pairing, the wireless RSM will be connected to the to the wireless audio adapter automatically. wireless audio adapter automatically. After successful connection, the LED indicators of the wireless After successful connection, the LED indicator of wireless RSM audio adapter and the wireless ring PTT will flash blue rapidly. will flash blue rapidly and the LED indicator of the wireless audio Using Wireless Audio Adapter with Wireless Ring PTT adapter will glow blue (waiting for pairing and connection of... -
Page 8: Troubleshooting
Zone option, and then press the Right key or the Left key to select a Phenomena Analysis Solution zone. The wireless RSM The battery power Please recharge the wireless Selecting a Channel cannot be powered may run out. RSM. In the home screen, press the Power On/Off/Switch key to switch to Channel option, and then press the Right key or the Left key to select The battery power Charge the wireless RSM for... - Page 9 Product Cleaning Before cleaning, turn off the product. ● Clean up the dust and fine particles on the product surface and charging piece with a clean and dry lint-free cloth or a brush regularly. ● Use neutral cleanser and a non-woven fabric to clean the keys and front case after long-time use.
