- Page 1 Goldie Assembly Instructions Goldie Wall Light jardan.com.au...
- Page 2 Goldie Assembly Instructions Components Required 1 x Goldie Sconce 1 x Allen Key Size 3 1 x Wall Bracket 1 x Drill + Drill bits 1 x LED Driver 2 x Screws + Substrate fixings jardan.com.au...
- Page 3 Goldie Assembly Instructions Using the Wall Bracket, mark out the location and level on the wall. Mark out the fixing points and central cavity by drawing around the inside of the rectangle. Use suitable substrate fixings for the screw terminals at the marked locations. Drill or cut out the central cavity on the wall taking care not to interfere with the fixing points.
- Page 4 Goldie Assembly Instructions Wearing gloves so as not to mark the surface, position the Goldie Wall Plate over the bracket with the grub screws at the top and bottom. The orientation can be rotated if required before the grub screws are tightened.
-
Page 5: Warranty And Care
WARNING This installation must only be done by a licensed electrician. Due to the nature of the bronze finish, Goldie will patina and age over time. Always wear gloves when handling to avoid marking, Jardan does not take responsibility for any marking during installation.
