AIMIBO Q3 TX User Manual

4k wireless hdmi transmitter and receiver
Hide thumbs Also See for Q3 TX:
Table of Contents

Advertisement

Quick Links

4K Wireless HDMI
Transmitter and Receiver
User Manual
EN
Model: Q3 TX - Q3 RX
Ver A 2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q3 TX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AIMIBO Q3 TX

Summary of Contents for AIMIBO Q3 TX

  • Page 1 4K Wireless HDMI Transmitter and Receiver User Manual Model: Q3 TX - Q3 RX Ver A 2.0...
  • Page 2 If you want to view the online manual, you can scan the QR code to watch it.
  • Page 3 Manual Catalog Product Introduction Specification Compatible Package Included Product Overview How to install? How to re-pair? How to get a smooth streaming experience? How to use receiver as a wireless display adapter?

  • Page 4: Table Of Contents

    How to switch transmitters? How to customize the startup interface background image? How to change the dongle's name and password? How to change screen rotation? Description of receiver's settings page Troubleshooting Activate Warranty Card After-sales support...

  • Page 5: Product Introduction

    Plus, the receiver supports wireless screen mirroring in stunning 4k resolution, and 1 receiver can connect to up to 8 transmitters. Specification Model: Q3 TX - Q3 RX １ Power Input: 5V/1A Wifi: 2.4/ 5Ghz HDMI version: HDMI 1.4 TX Resolution: 1920X1080 @ 60Hz.

  • Page 6: Package Included

    Compatible Transmitter can work with most HDMI output devices, １ like Laptop, PC, Camera, DSLR, PS5, Blu-ray Player, TV Stick, TV Box, DVD, DVR, Set-top boxes, Cable/Satellite boxes, tablet and more. Receiver can work with most display, like HDTV, Projector, and Monitor. Mini/Micro HDMI adapters can convert the mini/micro HDMI interface for laptop, camcorder, camera, or tablet to a standard HDMI port.
  • Page 7 Product Overview Receiver-RX 2 in 1 port for external antenna & charging cable HDMI Port Indicator Light Function Button Transmitter-TX USB-C charging port HDMI Port Indicator Light Function Button RX Function Button: Hold 3-5 second for screen rotation, Hold 15 seconds to restore factory settings.

  • Page 8: How To Install

    How to install Connect a USB cable for receiver and power it via a 5V/1A USB charger, then plug the Receiver to your TV/monitor/ projector. 5V/2A After connect receiver to TV, you will see a blue screen interface. 5V/2A Connect the transmitter to the HDMI port on your laptop/PC, and power it on via a 5V/1A USB charger.
  • Page 9 5V/2A Wait about 5 seconds, the TX's indicator light will become flashing to solid, and then the screen will automatically project. You can find a video demonstrating how to connect by scanning the code below: How to re-pair Connect external antenna to Receiver and power supply, plug it into TV or other HDMI input device;...
  • Page 10 To enter pairing mode, press and hold the function button on the receiver for 3 seconds. Release the button when the prompt appears on the screen to pair with RX-AIMIBO. Note: If you press and hold the function key for more than 10 seconds, the receiver will automatically initialize the program and return to the blue screen interface.
  • Page 11 Once the pairing is successful, an "1" icon will appear in the upper right corner of the blue screen interface. After waiting for 5 seconds, they will auto mirror again. Note: If pairing takes too long, the receiver may automatically exit pairing mode.
  • Page 12 Disconnect the transmitter by single-clicking the function button. Go to your phone's network settings and find the WiFi network named "RX-AIMIBO", then enter the password: 12345678. Launch a browser on your phone and enter the IP address "192.168.203.1".
  • Page 13 Choose "Wireless channel", select the 5G as your WiFi mode. Choose your country, and select a WiFi channel, select a Bandwidth. Wifi channel is between 36 and 161. (Note: You need to choose one that is far away from the current channel, like current is 40, you'd better to choose 161.) Test different channels within this range to find the optimal one for your setup.
  • Page 14 You can find a video demonstrating how to change Wifi channel: How to use receiver as a wireless display adapter Connect the dongle to your TV/monitor's HDMI port, and plug the antenna & USB cable to it, and power it to a 5V/1A USB charger or your TV's USB port.
  • Page 15 Turn on your device (iPhone, iPad, MacBook, Android smartphone or tablet) Wifi setting. Connect it to the dongle's antenna signal. Name: RX-AIMIBO, Password: 12345678. RX-AIMIBO When you connect to the dongle's wireless signal, the TV blue screen's right upper corner will show number 1 and the above image.
  • Page 16 TV. RX-AIMIBO For Android device Find your smartphone mirror function on its setting page, such as, Samsung phone's screen function called "smart view" Choose 'RX-AIMIBO' as a target, then you can cast your smartphone to TV. RX-AIMIBO...
  • Page 17 Open browser and enter IP address: 192.168.203.1, wait for 2 seconds, the dongle's background setting will show out. Please select your router's name and enter password to connect this dongle to your router's network. RX-AIMIBO � � � When the dongle's background setting connects to your router's network, the TV blue screen's right upper corner will show your router's name.
  • Page 18 Please back to your Wifi setting page, and choose back your router's network. Note: Don't forget to choose back to your router's network, or your iPhone/ iPad will have no internet. Click 'screen mirroring' and choose 'RX-AIMIBO' as target, then you can cast your iPhone/ iPad to TV. RX-AIMIBO...
  • Page 19 TV by scanning the code below: For mac OS device Please back to your Wifi setting page, and choose back your router's network. RX-AIMIBO Click 'Screen Mirror' and choose 'RX-AIMIBO' as target, then you can cast your mac OS to TV. RX-AIMIBO...
  • Page 20 You can find a video demonstrating how to connect Macbook to TV by scanning the code below: For Android devices Please back to your Wifi setting page, and choose back your router's network. Your router Find your smartphone or tablet's mirror function on its setting page, such as, Samsung phone's screen function called "smart view"...
  • Page 21 Choose 'RX-AIMIBO' as target, then you can cast your smartphone or tablet to TV. RX-AIMIBO You can find a video demonstrating how to connect Android to TV by scanning the code below: For Windows devices (Don't need the above steps) Press "Win + K"...

  • Page 22: How To Switch Transmitters

    RX-AIMIBO *Press ' ', choose 'Duplicate' or 'Extend' mode. You can find a video demonstrating how to connect Windows to TV by scanning the code below: How to switch transmitters One receiver can be paired with up to 8 transmitters simultaneously.

  • Page 23: How To Customize The Startup Interface Background Image

    Click the function key of the working Transmitter 1, and the screen of the Receiving end will return to the blue screen interface. PC１is in standby Click the function key of Transmitter 2, the interface of PC2 will be transmitted to the Receiver. PC１is in standby PC２in use How to customize the startup...
  • Page 24 HDMI port into the TV to complete the operation. You just need to connect the antenna to the RX and power it on. 5V/2A Connect the computer to the RX's signal. The Wifi is RX-AIMIBO and the password is 12345678. RX-AIMIBO...
  • Page 25 On the computer web page, enter the IP address: 192.168.203.1. Click on 'UI Background' to enter the image upload interface. Click 'Select Picture' to upload an image. The image requirements are: 1920*1080 pixels, JPG format, and under 200KB in size. Click 'Upload' and wait for the upload to succeed.

  • Page 26: How To Change The Dongle's Name And Password

    Wifi setting. Connect it to the dongle's antenna signal. Name: AMB-XXX, Password: 12345678. RX-AIMIBO Open browser and enter IP address: 192.168.203.1, wait for 2 seconds, the dongle's background setting will show out. Click on 'Device Name' to modify it, and click on 'WIFI Password' to modify it as well.

  • Page 27: How To Change Screen Rotation

    RX-AIMIBO � � RX-AIMIBO � � After modifying the password, unplug the dongle's charging cable and reconnect it, or click "reboot" in the IP '192.168.203.1' setting page, for the changes to take effect. How to change screen rotation Press RX's middle button for 3-5 seconds, you can change the screen rotation to Horizontal (Landscape) or Vertical (Portrait).

  • Page 28: Description Of Receiver's Settings Page

    Description of the receiver settings page If the language of the setting page is not your native language, please click item 12 to change the language.
  • Page 29 Internet: Used for receiver to connect home WIFI router. Internet: Used for receiver to connect home WIFI router. Device Name: This receiver's name: RX-AIMIBO Device Name: This receiver's name: RX-AIMIBO Wifi Password: This receiver's password:12345678 Wifi Password: This receiver's password:12345678...

  • Page 30: Troubleshooting

    Troubleshooting Why does my TV stay stuck on a blue screen after connecting the transmitter and receiver? Please verify that you have correctly installed the transmitter and receiver to your devices: Step 1: Connect the TX to the HDMI out port of your device, such as a laptop or cable box.
  • Page 31 Please follow these steps to re-pair the TX and RX: Step 1: Press and hold the RX button until your TV displays "Release the button to pair with RX-AIMIBO," then release the button. Step 2: Press and hold the TX button until the TX indicator light turns off, and then release the button.
  • Page 32 If you are using an HDMI splitter for screen splitting, please ensure that you have selected the correct type. HDMI splitters require power supply, unlike HDMI switches, which lack output functionality. Additionally, if you have the correct HDMI splitter but still can't screen mirror, try removing the adapter and directly connecting the devices.
  • Page 33 Connect the receiver to your TV and power it on. Step 2: Go to your phone's network settings and find the WiFi network named "RX-AIMIBO," then enter the password: 12345678. Step 3: Launch a browser on your phone and enter the IP address "192.168.203.1".
  • Page 34 Why do the TX and RX become very hot during use? Normal heat dissipation: It is normal for electronic devices to generate some heat during operation. The internal components and chips of the devices produce heat while functioning, and devices typically incorporate heat dissipation measures to maintain the temperature within an acceptable range.
  • Page 35 set to the correct HDMI input channel. Sometimes, if the RX device is plugged into HDMI 1 on the TV but the channel is set to HDMI 2, it can result in a black screen. Try connecting to another display: If the HDMI connection and channel settings are correct, but the TV continues to display "no HDMI signal,"...
  • Page 36 Only transmit images, no sound. Cause 1: This product only supports 2.0 stereo sound and does not support 2.1 stereo sound, 5.1 stereo sound, 7.1 stereo sound, Dolby Atmos sound. Solution: Please check your audio settings on your output device. Change it to 2.0 stereo sound. Cause 2: Modify the audio output source of the laptop.
  • Page 37 Why can't I watch Netflix on my Android phone? Due to the wide variety of Android phone models on the market, our technical department is continuously testing compatibility with HDCP protocol apps for more models. If your device can play TikTok but not Netflix, we regret to inform you that our device cannot bypass the HDCP protocol on your device.

  • Page 38: Activate Warranty Card

    2 years, enjoying free replacements for 2 years and lifelong technical support. Activation Process: Visit aimibo.tv/warranty Scan the QR code. Fill in your name, email, and order number. Our customer service team will confirm and process your activation request.

  • Page 39: After-Sales Support

    After-sales support Our Warranty: money back guarantee free replacement If you have any quality issue or operation issue, please kindly contact us to figure out the problem. Email: support@aimibo.tv Website: https://aimibo.tv SUBSCRIBE AIMIBO: WhatsApp...
  • Page 40 FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 41 ISED Statement English: This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesiredoperation of the device. The digital apparatus complies with Canadian CAN ICES-3 (B)/NMB-3(B).
