- Page 1 4K Wireless HDMI Transmitter and Receiver User Manual Model: Q3 TX - Q3 RX Ver A 2.0...
-
Page 2: Product Introduction
Product Introduction This Wireless HDMI Transmitter and Receiver is the perfect solution for seamless connectivity up to 165 feet away. With easy plug-and-play setup, stream anything to a larger screen effortlessly. Our 5G technology ensures a smooth streaming experience. Plus, the receiver supports wireless screen mirroring in stunning 4k resolution, and 1 receiver can connect to up to 8 transmitters. -
Page 3: Package Included
Compatible １ Transmitter can work with most HDMI output devices, like Laptop, PC, Camera, DSLR, PS5, Blu-ray Player, TV Stick, TV Box, DVD, DVR, Set-top boxes, Cable/Satellite boxes, tablet and more. Receiver can work with most display, like HDTV, Projector, and Monitor. - Page 4 Contact Way: Technical support email: Support@Aimibo.tv Website: https://aimibo.tv WhatApp:...
-
Page 5: Product Overview
Product Overview... -
Page 6: Connection Method
Connection Method Connect a external antenna USB cable for receiver and power it via a 5V/1A USB charger or your device's USB port, then plug the receiver to your TV/monitor. 5V/1A After connect receiver to TV, a language selection interface will appear on the screen. Single-click the function key on the receiver to select your preferred language. - Page 7 Connect the transmitter to the HDMI port on your laptop/PC, and power it on via a 5V/1A USB charger. 5V/1A Wait about 5 seconds, the TX's indicator light will become flashing to solid, and then the screen will automatically project.
- Page 8 10 seconds, the receiver will automatically initialize the program and return to the language selection interface. Release the button to pair with RX-AIMIBO Press and hold the function button on the transmitter for 3 seconds. Release the button when the indicator light turns off, and the transmitter will restart.
- Page 9 appear, which indicates that the pairing process is complete. Slow flash Not connected Fast flash Pairing Solid on Connected Once the pairing is successful, an "1" icon will appear in the upper right corner of the gray screen interface. After waiting for 5 seconds, they will auto mirror again.
- Page 10 Wi-Fi channel to a less congested one, please follow these steps: Disconnect the transmitter by single-clicking the function button. Go t o your phone's network settings and find the WiFi network named "RX-AIMIBO", then enter the password: 12345678.
- Page 11 Launch a browser on your phone and enter the IP address "192.168.203.1". Choose "Wireless channel", select the 5G as your WiFi mode. Choose your country, and select a WiFi channel, select a Bandwidth. Wifi channel is between 36 and 161. (Note: need to choose one that is far away from the current channel,...
- Page 12 ● When using it for the first time, please connect the device to your home WIFI router first Click WIFI on your phone settings page, connect your phone to the Receiver's WI-FI. (Device name is RX-Bxxxxxxx, the default password is 12345678). Turn on phone/pad browser, input 192.168.203.1, and enter the receiver settings page.
- Page 13 Connect your iPhone to the same network as the receiver (same home router WIFI). If the product fails to connect with same home router, please click WIFI in the phone settings page, and find the receiver hot spot and connect it. (RX-BXXXXXXX, password: 12345678) Swipe the screen to enter the Apple Device Control Center.
- Page 14 Method 1 Open the phone settings, and find the cast function of your phone. Select the receiver "RX-Bxxxxxxx" as the target. ● The setting path of the cast function of different brands of phones/tablets: ○ Huawei: Settings >Wireless Projection/Multi-screen Interactive ○...
- Page 15 ●If can't find the receiver SSID, refresh the Google Home homepage, confirm that your home WiFi appears in the upper right corner of the gray screen, and also make sure that your Android phone is connected to the same network as the device, or restart your phone. If the language of the setting page is not your native language,...
- Page 16 Internet: Used for receiver to connect home WIFI router. Device Name: This receiver’s name: RX-AIMIBO Wifi Password: This receiver’s password:12345678 Display: The default is set to video Resolution:Select resolution for receiver Display mode:Change the ratio of the output screen Wireless Channel: Change the channel to a less congested Wifi...
- Page 17 One receiver can be paired with up to 8 transmitters simultaneously. When multiple transmitters are paired, you can switch among them by clicking the function buttons of the transmitters. Click the function key of the working Transmitter 1, and the screen of the Receiving end will return to the gray screen interface.
-
Page 18: Troubleshooting
Click the function key of Transmitter 2, the interface of PC2 will be transmitted to the Receiver. PC１is in standby PC２in use Troubleshooting The pairing between the transmitter and receiver has been disconnected. Please re-pair the transmitter and receiver. The antenna signal of the receiver is not being properly received. - Page 19 Insufficient power supply. Please try to connect to a power outlet through an adapter to power the transmitter and receiver separately. The transmitter supports up to 1080P output. If the HDMI output device defaults to outputting 4K, the transmitter cannot normally transmit the picture. Please modify the HDMI output device resolution to 1080 (computer, etc.).
- Page 20 Insufficient power supply. Please try to connect to a power outlet through an adapter to power the transmitter and receiver. When using this product for a long time in an unstable power environment, the product temperature will be abnormal and overheat protection will be activated temporarily invalid.
- Page 21 Ensure that the receiver's antenna is not obstructed by equipment or the TV. For better signal stability, please move the antenna away from behind the TV. The fewer obstacles between the transmitter and receiver antennas, the more stable the signal transmission will be. This product only supports 2.0 stereo sound and does not support 2.1 stereo sound, 5.1 stereo sound, 7.1 stereo sound, Dolby Atmos sound.
- Page 22 The resolution of the receiver is set at default factory setting at 1080P. You need to enter into receiver background settings to adjust resolution Use your phone's wifi settings to connect with receiver. Open your phone's browser and enter into 192.168.203.1，to enter into receiver's setting page.
-
Page 23: After Sales Support
After-sales support Our Warranty: money back guarantee free replacement If you have any quality issue or operation issue, please kindly contact us to figure out the problem. Email: support@aimibo.tv Website: https://aimibo.tv WhatsApp... - Page 24 FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 25 ISED Statement English: This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesiredoperation of the device. The digital apparatus complies with Canadian CAN ICES-3 (B)/NMB-3(B).
