- Page 1 Installation and maintenance manual To be kept inside the machine MAN2100105 Vers. 1 - 30/01/09 www.rheavendors.com...
- Page 2 SELECTION LABELS DISPLAY SELECTIONS COINS KEYBOARD VALIDATOR PLATE SUPPORT CUP STATION LIQUID WASTE BUCKET COFFEE BEANS CANISTER INSTANT CANISTERS COFFEE GRINDER COFFEE DOSER MICRO MIXING COFFEE BOWLS BREWER WATER PIPE WATER PIPE OUTLET PIPES COFFEE SUPPORT GROUND BUCKET LIQUID WASTE TRAY COFFEE CPU/POWER...
-
Page 3: Table Of Contents
INDEX TECHNICAL DATA AND DECLARATION OF CONFORMITY ................4 INTRODUCTION ................................6 DESCRIPTION OF THE EQUIPMENT ........................6 ADVICE FOR THE INSTALLER ..........................7 BASIC OPERATING PRINCIPLES ..........................7 TRANSPORTATION...............................8 UNPACKING..................................9 POSITIONING .................................9 CONNECTION TO THE MAINS WATER SUPPLY AND TO THE ELECTRICAL SUPPLY ......9 HOW TO ACTIVATE OR DEACTIVATE THE MACHINE ...................10 START-UP OPERATIONS ............................12 PROGRAMMING OF THE MACHINE ........................15... -
Page 4: Technical Data And Declaration Of Conformity
Technical Data and Declaration of Conformity Height (mm) 562 - 592 - 618 Width (mm) Depth (mm) WEIGHT (Kg) 1700 1200 Power consumption (W) at 230 V ~ 50/60 Hz Selection Keys number Water inlet pressure between 0,1 MPa (1 bar) and 0,8 Connection to the main water supply MPa (8 bar) mains water connection 3/8”... - Page 5 This document contains confidential information, which is property of Rhea Projects S.p.A. The content of this document cannot be neither circulated to third parties, nor copied or duplicated in any form, without previous written consent by Rhea Projects S.p.A. Use, duplication or divulgation of technical information contained in this document can be subject to legal protection by Rhea Projects S.p.A.
-
Page 6: Introduction
+39.02.9655086 or surf our web site www.rheavendors.com or send en e-mail at the address rheavendors@rheavendors.com. In order to speed up the response to your requests it will be necessary to supply: - All data appearing on the Serial Number Label. -
Page 7: Advice For The Installer
Obtainable Drinks All beverages obtainable from your machine are shown in the list attached to this manual, and they vary substantially according to the version of the machine. It is possible to program the machine through the Rheaction software using the Rhea black flash card. For further information contact Rhea vendors Customer Service. Advice for the installer Installation and maintenance operations described in text with normal background (white) must be carried out only by qualified technical personnel. -
Page 8: Transportation
Preparation of hot drinks from instant ingredients This procedure is usually carried out after the cup is correctly positioned under the outlet pipes of the beverage. More than one procedure of this sort can be carried out simultaneously or in sequence during a vend cycle. This procedure is usually carried out after the cup is correctly positioned under the outlet pipes of the beverage. -
Page 9: Unpacking
WARNING: They must be moved on with dolly, at reduced speed and preventing any excessive bending movement of the machines. WARNING: the machine weighs from 33 Kg to 40 Kg ca. Take care during transfer to avoid accidents to people (example: muscular rip, hernia, etc.). If the machine must be stocked for a period before installing it, please keep the machine in a dry place (the relative humidity must not exceed 80%), with temperature between 5°... -
Page 10: How To Activate Or Deactivate The Machine
- If the mains pressure is higher than 0,8 MPa (8 bar), a pressure reducer must be mounted, calibrated at 0,3 MPa (3 bar), on the water connecting hose of the machine; in any case the mounting of a pressure reducer is advisable in all installations where high pressure peaks occur. - Page 11 CPU/POWER board. Only for PB, the display shows the version of the master loaded on the Espresso brewer board. At the end of checks, the standard invitation message will appear on the display, e.g.: rheavendors cino xs Grande During the First installation procedure, the following messages are displayed:...
-
Page 12: Start-Up Operations
INSTALLATION At the end of the operation the display will shows: rheavendors Cino XS Grande 11.2 Second installation phase The second phase of the installation of the machine contains the cleaning of the parts in contact with foodstuff, the loading of the food products and the installation of some accessories. - Page 13 The display shows: 1 = PROGR 2 = DATA 3 = FREE 4 = CLEAN Start cleaning operations washing the mixing bowls. Press 4. The display shows: CLEANINGS 1 – 2 – 3 8=HC Use keys 1, 2 and 3 to clean, inc ase of PB version, the coffee brewer and the mixing bowls, in case of SM version, the 3 mixing bowls.
- Page 14 Remove also the outlet pipes support, the mixing bowls and the mixing fan. Immerse all parts in the solution. Using a cloth soaked in the solution, proceed to clean also the attachment bases of the mixers, which remain fixed to the machine.
-
Page 15: Programming Of The Machine
After having refilled, refit the canister and open the slide lock and pull the tongue of the coffee beans canister out. 11.2.3 Inserting the selection labels The selection labels are supplied in a special pocket with the Instructions Manual. When the machine if open and off, remove the orange selections cover and slip the labels in the special slots following the diagram on the Memory Configuration Chart attached to the Manual. - Page 16 • Switch off the machine; • Insert the flash card into the flash slot in the front of the machine. • Switch on the machine. • Wait until the display shows: 1 = KEY - - - > VMC 2 = VMC - - - > KEY •...
- Page 17 PROGRAMMING - - - -MISCELLANEOUS - - DIAGNOSTICS - - - - - - - - - - - - - - - - - - - - - - SALES AUDIT - - - - - - - - - - - - - - - - - - - - - PROGRAMMING- - - - -MDB- - - - - - - - - - - - PROGRAMMING- - - -...
- Page 18 The grounded coffee dosage can be manually adjusted, with the vending machine switched off and unplugged, pressin the lever on the doser and moving it upwards to decrease the dosage and downwoards to increase the dosage. Press again 2 (Version PB). The display shows: coffee sequence 1 = before Use this parameter to set the priority of starting between milk and ground coffee for drinks made with these...
- Page 19 start delay WATER 1 Pressing 4 and 5 increase or decrease respectively the water pouring delay after the beginning of the selection. Pressing 2 the display shows: flow WATER X slow Pressing 4 and 5 it is possible to choose among the three parameters “slow”, “medium”, “quick” to increase or decrease the correspondent water flow.
- Page 20 preparing otherwise if you select one of the available selection names the display will show: selection name preparing Pressing again 2 NEW: Using Rheaction Professional, starting from edition 3.3A, you can create the names of all selections by yourself! When you create the configuration file you have to select from the menu “Selection Name”...
- Page 21 Press 4 and 5 to increase or decrease the position of the mixing bowl water to be associated to decaffeinated canister. Pressing 2 the display shows: price decaf/barley 0 = + 1 = - Pressing 4 and 5, set 0 for a price increasing or 1 for a price decreasing; the price will be modified of the value of the price associated at the current button.
- Page 22 Proceed as for previous preselections. At the end of the setting of buttons, push 1 to confirm the set data. All the settings described in this and in following paragraphs can be set in an easier way using rheaction software. For further information contact rheavendors Customer Service 12.5.2 Pre-setting of the normal sale prices One price for each selection available can be memorised in the machine.
-
Page 23: Programming Temperature
PROGRAMMING TEMPERATURE is videoed. Entering 2 the video shows: TEMPERATURE Boiler Entering 4 and 5 set the value. Pressing button 2 the display shows: DEF. FIRST COFFEE Minutes Use this parameter to obtain drinks made with coffee beans at a right temperature also after long periods of inactivity of the coffee group. - Page 24 to programme a serial Executive payment system; coin-mech type PRICE HOLDING to programme a serial Executive payment system in Price Holding mode; coin-mech type to programme a serial MDB payment system WARNING: the appliance recognizes automatically the presence of a serial MDB payment system at the switching on.
- Page 25 12.5.6 Diagnostics programmes In the programming mode, a certain number of diagnostics programmes can be carried out in order to test the correct operation of some components of the machine. To modify the parameters, in the programming mode, press 1 until the sub-menu DIAGNOSTICS - - - - - - - - - - - - - - - - - - - - - - is visualised.
- Page 26 This value indicates the total money cashed. This value cannot be set to zero. PARTIAL CASH This value indicates the amount of money cashed starting from the last reset operation. N. TOT. SEL. CASH This value indicates the total number of beverages paid cash. N.
- Page 27 12.5.8 Special presetting for MDB/ICP standard systems The MDB/ICP standard systems are commonly used in the machine after programming function " COIN MECH TYPE " to value MDB (see above). Due to the characteristics of this system, the credit is managed mostly by the machine.
- Page 28 Press 4 and 5 and modify the values of the function displayed. Set at 0 each coin from A to P which the coin- mechanism must accept and at 1 all the coins, which the machine must not accept. By pressing 2 the following messages are displayed: Bill reader Abil 0,1,2...
-
Page 29: Installation Of The Payment Systems
hh:mm appears. This function programmes the time for the daily automatic cleaning cycle. It is advisable to programme the automatic cleaning at the beginning of the day. The automatic cleaning is activated only when the value hh:mm is not set at 00:00 and when at least 5 cycles has been made by the machine in 24 h. At the end of programming, press 1. -
Page 30: Cleaning And Loading Operations
The machine is now ready to use the payment system . Cleaning and loading operations WARNING: The personnel in charge of the loading of the ingredients must own a valid certificate of good health following local and NATIONAL NORMS. Furthermore, compliance with any other domestic or local regulations must be checked. -
Page 31: Ordinary And Prevention Maintenance
remove the coffee brewer following the steps shown into the pictures and clean it. Remove the waste grounded coffee bucket. After washing all parts replace them in their original position. 14.2 Weekly cleaning These operations are carried out once a week, after completing the daily cleaning operations. Make sure that the machine is off. - Page 32 1 – 2 – 3 8=HC Press button 8. The display shows: Health cleaning Brewer P1 = start Press button 1 to start coffee brewer cleaning sequence. The disply shows: Cleaning Active Put pastille and Push P4 = start insert the sanitary washing tab inside the brewer and press button 4. The display shows: P3 to continue Rinsing 0:45...
- Page 33 At the end of the procedure place all parts in their correct position. 15.1.5 Washing and disinfecting of components in contact with foodstuff. With the vending machine switched on, make sure that the display shows: rheavendors cino xs grande Place...
- Page 34 your cup Open the door. Insert the plastic key into the safety switch. The display shows: The display shows: 1 = PROGR 2 = DATA 3 = FREE 4 = CLEAN Start cleaning operations washing the mixing bowls. Press 4. The display shows: CLEANINGS 1 –...
- Page 35 Remove also the outlet pipes support, the mixing bowls and the mixing fan. Immerse all parts in the solution. Using a cloth soaked in the solution, proceed to clean also the attachment bases of the mixers, which remain fixed to the machine.
-
Page 36: Machine Out Of Service
Machine out of service 16.1 Temporary out of service Should a long period be foreseen in which the machine will not operate, the following operations must be carried out. Press the key P inside the door. The display shows: 1 = PROGR 2 = DATA 3 = FREE 4 = CLEAN... -
Page 37: Further Advice For The User
Further advice for the user The automatic vending machine in your hands is safe for those who follow the loading and ordinary cleaning instructions indicated in this manual. The user must not gain access to areas in the machine, which feature a cover requiring a tool to be removed. - Page 38 The coffee brewer is not correctly Check the micro-switch of the The display shows " OFF 8B": the placed presence of the coffee brewer machine does not vend beverages through the coffee brewer (PB Versions) The display shows " OFF 9": the (PB Versions) No coffee beans Fill the coffee beans canister.
- Page 39 18.2 Miscellaneous shortcomings The shortcomings described in this section are not indicated by any message displayed on the machine. SYMPTOM PROBABLE CAUSE SOLUTION The machine does not switch on No mains voltage Wait for the resetting of mains (no component is powered) voltage The boiler is overheated Reset the safety thermal switch...
