Instruction Manual
Item name: RIDE ON RETRO SCOOTER 3 WHEELS
Item number: 060-ROT-03
* Product appearance and colors may vary from the photo.
WARNING：
This product should only be assembled by an adult.
ATTENTION
This vehicle is packed with the battery disconnected. Connect
the battery before use.
This manual contains important safety, performance and
maintenance information. Read the manual thoroughly before
allowing your child to ride your new electric ride-on toy. Failure
to read the user manual can result in property damage or bodily
injuries. Keep this user manual for future reference.
Advertisement
Table of Contents
Related Manuals for Kidzone 060-ROT-03
Summary of Contents for Kidzone 060-ROT-03
- Page 1 Instruction Manual Item name: RIDE ON RETRO SCOOTER 3 WHEELS Item number: 060-ROT-03 * Product appearance and colors may vary from the photo. WARNING： This product should only be assembled by an adult. ATTENTION This vehicle is packed with the battery disconnected. Connect the battery before use.
-
Page 2: Safety Instruction
Safety Instruction When using electrical product, basic safety precaution should always be followed including the following Read all Instruction before operating this product WARNING: • To Protect against electrical shock, do not immerse cord, charger, transformer, battery, or the product in water or other liquid. •... -
Page 3: Prevent Fire
WARNING: PREVENT FIRE injury and could also ruin the electrical system. in serious injury. • The battery must be handled by adults only. The battery is heavy and contains sulfuric acid(electrolyte). Dropping the battery could result in serious injury. • Never allow children to charge the battery. Battery charging must be done by adults only. - Page 4 WARNING FAILURE TO FOLLOW THE SAFETY INSTRUCTIONS LISTED BELOW MAY RESULT IN SERIOUS INJURY OR DEATH. The owner’s manual contains assembly, use and maintenance instructions. Child Safety Warnings • Adults supervising children must read and understand this entire manual before allowing any child to use this product.
- Page 5 WARNING 5• If necessary, adults and supervisors are always responsible for setting up gates and barriers to ensure a safe riding environment for the child rider. 6• Be aware that this ride-on toy does not have braking capabilities. Allowing use of this ride-on toy in areas that require braking may cause rolls, crashes, serious injury, or death to the child rider.
- Page 6 WARNING Battery and Charging Warnings The following safety hazards may result in serious injury or death to the user of the ride-on: Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries. • Corrosive Material Warnings Battery posts, terminals and related accessories contain lead and lead •...
- Page 7 WARNING • Regularly check charger, supply cord and connector for wear and damage. Look for frayed or kinked wires, any exposed inner wires, any missing insulation. If any damage is observed do not plug in the charger and do not charge the battery.
- Page 8 Battery: DC 6V 4.0 AH Suitable Age: 3+ years / 36+ months Maximum User Weight: 66 lb / 30 kg Dimension: 42” x 18.3” x 28.6” (1068 x 466 x 726 mm) Speed: 1.5 mph (2.5km/h) Charge Time: 8 - 12 hours Charger: 6V 500mA Fuse: F5A self-resetting fuse Battery Operating Life: 12 - 18 months...
- Page 9 Parts and Feature 8. Rear Axle Rear Mirror Vehicle Body 1x 9. M8 Nut M3.5 x 12 Screws Handle (Pre-installed in the rear axle and front axle) 10. M10 Washer Metal Plate Mudguard (Pre-installed in the rear axle and front axle) 11.
-
Page 10: Assembly Instruction
Assembly Instruction Estimated Assemble Time: 40 mins Tools Needed: Screwdriver, pliers, hammer, spanner. Some parts are small and have sharp edges. Do not let children handle parts or the assembly. This product should be assembled by adult. M3.5x12 Screw Wheel Hub M8 Nut Rear Wheel Metal Plate... - Page 12 Assembly Instruction Mudguard Front Axle Front Wheel Insert the front wheel and the mudguard to the front of the vehicle. Handle Hand Brakes M5 x 65 Bolt M5 Nut Assemble the handle on the front axle, then secure using a M5 x 65 bolt and a M5 nut. NOTE: Hand brakes have no actual function.
- Page 13 Assembly Instruction Rear Mirror Insert the rear mirror to the handle. Remove the seat from the vehicle. The wire connector plug butt. Replace the seat and secure using the removed bolt.
- Page 14 Assembly Instruction Attach the toolbox to the rear of the vehicle body. NOTE: Make sure all M3.5 x 12 screws are securely fastened before operating the vehicle. M3.5 x 12 Screw Toolbox...
-
Page 15: User Instruction
User Instruction WARNING: Fully charge the battery for 8 - 12 hours. • Do not charge the battery for more than 20 hours. • • The battery should only be charged by an adult. Horn Button Operating the vehicle • To turn on the vehicle, insert the key to the general power switch and turn right, the dashboard light also turns on. - Page 16 User Instruction Charging the battery • The charging port is located below the seat. WARNING: The battery should only be charged by an adult. • Only charge the battery for 8 - 12 hours, do not charge the battery for more than •...
-
Page 17: Circuit Diagram
Circuit Diagram Care and Maintenance • Check the product regularly and make sure there is no missing or loose parts. Re-tighten any loose parts if necessary. • Make sure there is no cracked or broken plastic parts. • • Disconnect the battery if the product is not use for a long period of time. -
Page 18: Troubleshooting
Troubleshooting Problem Possible reason Solution Low Battery Fully charge the battery is overload or operated incorrectly. Wait for 10-15 Fuse Protection seconds to reactivate the vehicle automatically. Vehicle does not move Re-tighten all wheel nuts Loose wheel nuts Disconnected / Badly connected Reconnect the battery battery Battery/motor failure... -
Page 19: Warranty Terms
