Wireless Microphone Set
USER MANUAL
FR : Un manuel dans votre langue est disponible sur Internet:
IT: Il manuale nella sua lingua può essere trovato su Internet:
ES: Puede encontrar un manual en su idioma en Internet:
PT: Um manual em seu idioma pode ser encontrado na Internet:
PL: Instrukcję w swoim języku możesz znaleźć na stronie:
SV: En handbok på ditt språk finns på Internet:
NL: Een handleiding in uw taal vindt u op internet:
bit.ly/3RQuzJi
EN
Advertisement
Related Manuals for Easypix MyStudio Wireless Mic Uno
Summary of Contents for Easypix MyStudio Wireless Mic Uno
- Page 1 Wireless Microphone Set USER MANUAL FR : Un manuel dans votre langue est disponible sur Internet: IT: Il manuale nella sua lingua può essere trovato su Internet: ES: Puede encontrar un manual en su idioma en Internet: PT: Um manual em seu idioma pode ser encontrado na Internet: PL: Instrukcję...
-
Page 2: Table Of Contents
Table of content General instructions................3 Explanation of safety warnings ............. 4 Product introduction................4 Intended use ..................4 Declaration and prove safety ..............5 Restrictions ................... 5 Safety instructions ................6 Operating environment ................ 7 Radio interference and disturbance ............. 8 Storage environment ................ - Page 3 Easypix is not responsible or liable for misuse of the information that is contained herein. If you have any suggestions for improvements or amendments or have found errors in this publication, please notify us.
-
Page 4: General Instructions
General instructions Read this manual and its safety instructions before using this product. Follow all the instructions. This will avoid fire, explosions, electric shocks or other hazards that may result in damage to property and/or severe or fatal injuries. The product shall only be used by persons who have fully read and understand the contents of this user manual. -
Page 5: Explanation Of Safety Warnings
NOTICE Indicates information considered important, but not hazard-related. Product introduction MyStudio Wireless Mic Uno is a compact, rechargeable wireless microphone system consisting of a microphone transmitter and a dual channel receiver. Intended use This product is intended for use anywhere where wireless and convenient ‘plug and play’... -
Page 6: Declaration And Prove Safety
Declaration and prove safety The product has been verified in accordance with the essential requirements and other relevant provisions of Directives 2014/53/EU, 2011/65/EU & (EU) 2015/863 and in accordance with the Radio Equipment Regulations 2017 (SI 2017 No. 1206). Its safety complies with the requirements of the relevant national regulations. -
Page 7: Safety Instructions
Safety instructions WARNING This product is only suitable for the purpose described, the manufacturer is not liable for damage caused by abnormal use. WARNING Please read this instruction manual carefully before use. Keep all small parts out of the reach of small children. •... -
Page 8: Operating Environment
Operating environment NOTE Operation only permitted in closed rooms. - Do not use the product in places where the use of radio equipment is prohibited. - Do not use the product near hospitals as well as medical devices such as pacemakers, hearing aids, etc. -
Page 9: Radio Interference And Disturbance
- Check with your doctor or the manufacturer of your medical device (pacemaker, hearing aid, implant with electronic control, etc.) to ensure that it will not interfere with the use of the product. Frequencies of MyStudio Wireless MIC UNO: Modulation type Transmitting frequency and transmit power GFSK •... -
Page 10: Storage Environment
NOTICE The range in buildings can deviate greatly from the ‘line of sight’ range. In addition to the transmitting power and the receiver characteristics, environmental influences such as air humidity or structural conditions on site play an important role for the range. Storage environment •... -
Page 11: Description Of The Microphone
Description of the microphone 1) Windshield Holder 8) 3.5mm Audio Input for 2) Db Gain Adjustment additional external MIC 3) Power On/Off 9) Reset Button 4) Battery Indicator (Press if pairing is unsuccessful) 5) Connection Indicator 10) USB Type-C Charging Port 6) Mute Indicator 11) Microphone 7) ENC Indicator... -
Page 12: Description Of The Receiver
Description of the receiver 1) Battery Indicator 6) USB Type-C Charging Port 2) TX battery display icon 7) Mounting Clip 3) RX battery display icon 8) Reset button 4) 3.5mm Audio Output (Press if pairing is unsuccessful) 5) USB Type-C Audio Output 9) Power On/Off... -
Page 13: Charging
Charging Please ensure the microphone and receiver are fully charged before first use. Complete charging by connecting the device's USB Type-C port to your computer. NOTICE When successfully docked and charging the power indicators will illuminate. Charging is complete when the power / battery indicators are no longer illuminated. -
Page 14: Recording With Wireless Mic Uno
Recording with Wireless MIC UNO Preparing the receiver and the microphone 1. Connect the receiver to your camera, smartphone, laptop or recording device. This can be done by using either the 3.5mm cable for connection to a DSLR camera for example, or by using the USB-C cable. -
Page 15: Muting The Microphone
4. Adjust the gain setting to your preferred level (See ‘Adjusting gain levels’). 5. Start recording on your device. Muting the microphone To mute the microphone, short press and release the Power button. The mute indicator is on and ENC indicator is off to indicate that the microphone is muted. - Page 16 NOTE: Db gain adjustment is not possible when the microphone is muted. Db Level Memory Each time the microphone is switched on it will operate on the last chosen Db level before it was turned off.
-
Page 17: Connection Reset
Connection reset If a problem occurs where the wireless connection is lost, a new connection must be made between the microphone and receiver. This process is completed using the reset buttons: 1. Turn on both the mic and receiver units Using a small point press the reset button on the Mic –... -
Page 18: Functions And Indicators: Microphone
Functions and indicators: Microphone Function Button LED Status Long press power Power On Connection indicator LED flashes. button Long press power Power Off All LED’s are off. button Connection indicator LED flashes Disconnected slowly. Connection indicator LED is Connected remain on. Short press Db button ENC LED indicator flashes Gain Adjustment... -
Page 19: Functions And Indicators: Receiver
Functions and indicators: Receiver Function Button LED Status Power On Long press power button Battery LED flashes once Power Off Long press power button ALL LED’s off The MIC signal bars are not displayed Disconnected on the screen. The MIC signal bar appears on the Connected screen. -
Page 20: Box Contents
Box contents • 1x Receiver • 2x USB Cables • 1x Microphone • 1x 3.5mm Cable • 1x Clip-on Windshield • User Manual EN/DE • Hard Case Operating instructions in other languages are available for download at bit.ly/3RQuzJi or www.easypix.info/download-manuals/download/mystudio-mic-uno/... -
Page 21: Technical Specifications
Technical specifications MyStudio Mic Uno - Wireless Microphone Set • 1x Dual channel receiver • 1x Wireless MIC • Digital transmission 2.4GHz • Working distance up to 100M • Adjustable gain control Level 1:~40db Level 2:~50db Level 3:~70db • For use with devices containing an audio input •... -
Page 22: Disposal
Disposal Disposal of packaging: Dispose of the packaging according to its type. Add cardboard and paperboard to the waste paper, foils and plastic wrapping to the recyclable waste collection. Waste electrical and electronic equipment and/or batteries disposed of by users in private households in the European Union: This symbol on the product or on its packaging indicates that it cannot be disposed of with household waste. - Page 23 batteries. For more information on recycling this device and/or battery, contact your local council, the shop where you purchased the device or your household waste disposal service. Recycling materials helps to conserve natural resources and ensures that it is recycled in a way that protects human health and the environment.
-
Page 24: Declaration Of Conformity
Directives 2014/53/EU and 2011/65/EU & (EU) 2015/863. The full text of the EU Declaration of Conformity can be found in German and English at: www.easypix.info/download/pdf/doc-mystudio-mic-uno.pdf UKCA Declaration of conformity We hereby declare that the product complies with the Radio Equipment Regulations 2017 (SI 2017 No.1206).
