- Page 1 USER’S MANUAL CUBE STORAGE ORGANIZER HW61411 THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
- Page 2 Before You Start Please read all instructions carefully. Retain instructions for future reference. Separate and count all parts and hardware. Read through each step carefully and follow the proper order. We recommend that, where possible, all items are assembled near to the area in which they will be placed in use, to avoid moving the product unnecessarily once assembled.
- Page 3 We are very appreciated that you purchased our products. It is our willingness if you can use it proper l y. Please confirm if the spare parts are complete. It can also de assembled as required. ● Please confirm and inspect the parts according to the assembly drawing.
-
Page 4: Parts List
PARTS LIST Part image 13.8”×13.8” 13.8”×17.7” 13.8”×13.8” （4 spare）... -
Page 5: Assembly Steps
ASSEMBLY STEPS × 1 × 4 the connectors Before next step, please make sure to assemble the shelf corner to the end of the connector hole. STEP 1 × 3 × 6 STEP 2... - Page 6 ASSEMBLY STEPS × 4 × 5 STEP 3...
- Page 7 ASSEMBLY STEPS × 4 × 5 STEP 4...
- Page 8 ASSEMBLY STEPS × 5 × 1 To tighten the connections between the parts, please knock down the connectors with a rubber hammer to ensure that the shelf corners are assembled to the end of the connector holes. STEP 5...
- Page 9 ASSEMBLY STEPS × 4 × 9 × 10 Please repeat step 3 to 5, make sure all connectors are assembled in place STEP 6...
- Page 10 ASSEMBLY STEPS × 12 × 23 × 25 × 1 STEP 6...
- Page 11 ASSEMBLY STEPS × 4 × 1 × 5 × 2 STEP 7...
- Page 12 ASSEMBLY STEPS × 19 STEP 8...
- Page 13 Contact our friendly customer service department for help first. Replacements for missing or damaged parts will be shipped ASAP ! US office: Fontana UK office: Ipswich AU office: Truganina DE office: Hamburg FR office: Saint Vigor d'Ymonville PL office: Gdańsk US:cs.us@costway.com UK:cs.uk@costway.com AU:cs.au@costway.com...
