Professional model of air riveter to install blind rivets.
Thank you very much for purchasing "LOBSTER" air riveter. To ensure correct operation, please read
this instruction manual carefully, and keep it in a safe place for later reference.
Professional model of air riveter to install blind rivets.
● Thank you very much for purchasing "LOBSTER" air riveter. To ensure correct operation, please
read this instruction manual carefully, and keep it in a safe place for later reference.
● This is Original instructions. (Original Instruction Manual is written in English Ianguage.)
MANUFACTURER
MANUFACTURER
International Marketing&Sales Division
12-8 Shijo-cho, Higashi-Osaka City
Osaka 579-8053, Japan
Telephone: +81(72)981-7466 Telefacs: +81(72)981-9420
URL https://www.lobtex.co.jp/
AIR RIVETER
ＡＩＲ ＲＩＶＥＴＥＲ
INSTRUCTION MANUAL
INSTRUCTION MANUAL
BUILT-IN ON-DEMAND
BUILT-IN ON-DEMAND
VACUUM SYSTEM
VACUUM SYSTEM
R1A1
R2A2
CONTENTS
CONTENTS
INTRODUCTION ..................... 2
IMPORTANT SAFETY
INSTRUCTIONS.................................1
IMPORTANT SAFETY
NOMENCLATURE .............................3
INSTRUCTIONS
NOMENCLATURE .................. 6
TECHNICAL DATA ...........................4
TECHNICAL DATA .................. 7
PREPARATION BEFORE USE .......5
PREPARATION BEFORE USE ... 8
OPERATING THE AIR RIVETER ... 10
MAINTENANCE .................................8
STORAGE........................................12
MAINTENANCE
STORAGE ........................... 15
PARTS TABLE ................................13
ORDERING PARTS ............... 15
ORDERING PARTS .........................14
EXPLODED VIEW ............... 16
TROUBLESHOOTING .....................15
PARTS LIST ........................ 17
TROUBLESHOOTING ............ 18
............... 3
.................. 11
Ｎｏ .RAR2A2S90131
PRINTED IN JAPAN
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lobtex LOBSTER R2A2
Summary of Contents for Lobtex LOBSTER R2A2
-
Page 1: Table Of Contents
● This is Original instructions. (Original Instruction Manual is written in English Ianguage.) MANUFACTURER MANUFACTURER International Marketing&Sales Division 12-8 Shijo-cho, Higashi-Osaka City Osaka 579-8053, Japan Telephone: +81(72)981-7466 Telefacs: +81(72)981-9420 URL https://www.lobtex.co.jp/ Ｎｏ .RAR2A2S90131 PRINTED IN JAPAN... -
Page 2: Introduction
● Lobtex Co., Ltd. has the copyright of this manual. It is prohibited to publish, copy or translate to other language without prior consent. -
Page 3: Instructions
IMPORTANT SAFETY INSTRUCTIONS ● IMPORTANT SAFETY INTRUCTIONS ◆ Be sure to read the following Important Safety Instructions carefully and make sure that you ◆ Be sure to read the following Important Safety Instructions carefully and make sure that you understand them thoroughly before using this tool. understand them thoroughly before using this tool. - Page 4 • Repair work should only be carried out by a qualified technician. Please contact your nearest “LOBSTER” distributor, representative, or direct to Lobtex Co., Ltd., Osaka. If the tool is repaired • by someone without the necessary qualifications and experience, the tool may not perform to •...
- Page 5 ⚠ CAUTION 18. The production date of this product is shown brevity code below the tools.(on page5) (Example)year: ２０②⓪ month: ⑩ → B O O ○○○○ ↓ ↓ ↓ ↓ (Lot No. ) How to check manufactured date A year/month of manufacture １...
-
Page 6: Nomenclature
● NOMENCLATURE Tank Joint Tank Case Unit Bleed Plug Nosepiece Frame Head Frame Head Nut Trigger Vacuum Knob Bottom View Exhaust Port Cylinder Cup Cylinder Cup Serial No. Warning Label Rotary Jopint (Screw size : Parallel pipe thread G1/4) FRAME HEAD INTERNAL PARTS Jaw Case Lock Washer Ultra Jaws 'H' O-ring P10A... -
Page 7: Technical Data
● TECHNICAL DATA Model No. R2A2 Weight kg Operating air pressure MPa 0.5 ～ 0.6 Dimensions (Length×Height×Width) mm 331×318×143 Air consumption per minute L/min （At air pressure 0.6 MPa） 105 (on the occasion of vacuum is working) Tool stroke mm Traction power at 0.6 MPa 18.5 (on the occasion of vacuum is working) -
Page 8: Preparation Before Use
● PREPARATION BEFORE USE １ １ Set the Tank Case Unit to the Tank Joint. ⚠ WARNING ● Always attach the Tank Case Unit before use. If you work without attaching the Tank Case Unit, there is a risk that the mandrel of rivet that has beencut is not discharged, and will be clogged inside exhaust pipe, causing a fault of the equipment. - Page 9 １ ３ Set up the compressor, and be sure to install an air fi lter, air regulator and air lubricator (3-device set) between the compressor and the tool. Air regulator Rotary Joint Spool Cap Air fi lter Air lubricator ● Adjust the drip-feed amount of the air lubricator to the minimum setting. ●...
-
Page 10: Operating The Air Riveter
● OPERATING THE AIR RIVETER １ １ Select a suitable size of rivet for the workpiece to be riveted. １ ２ Replace the Nosepiece with one which matches the size of the rivet to be used. (Refer to “Preparation Before Use” on page 8.) １... -
Page 11: Maintenance
● MAINTENANCE After long periods of use, debris from cut mandrels and other foreign materials tend to build up in various parts of the tool, and the hydraulic oil level also drops, both of which can lead to operating problems.The tool should be cleaned periodically. １... - Page 12 １ ５ Using a brush or the like, clean parts. In particular, carefully clean the following areas. • Back of the Frame Head • Toothed section of the Jaw • Sliding section between the Jaw Case and the Jaw １ ６...
- Page 13 ２ Replacement of the Nosepiece * If the Nosepiece is damaged, replace it with a new one. * If you change the rivet size, replace with an applicable Nosepiece. Frame Head Nosepiece (AF 22mm) (AF 22mm) (AF 22mm) １ (AF 14mm) (AF 14mm) (AF 14mm) １...
- Page 14 ⚠ CAUTION ● Do not lubricate the air riveter with the Frame Head Nut and frame head removed. Doing so may result in an improper amount of hydraulic oil and cause trouble with the air riveter. Frame Head Nut Frame Head Plunger １...
-
Page 15: Storage
１ ７ Attach the Bleed Plug and Seal Washer to the air riveter using a hexagonal wrench (width across fl ats: 4 mm). １ ８ Wipe off hydraulic oil adhering to the main body or spilling out before use. * During disassembly/assembly, be careful to prevent cutting dusts of metal and other objects from getting into the hydraulic oil and Air Cylinder. -
Page 16: Exploded View
● EXPLODED VIEW... -
Page 17: Parts List
● PARTS LIST Index Code Part name Material Frame Head Nut 70040 Aluminum Material 2-B Nosepiece 6.4 10226 Steel ① : Plastic, Steel, Frame Head 70039 Steel Stainless, Sponge, Paper Jaw Case 63990 Steel ② : Aluminum, Steel, Rubber Ultra Jaws 'H' 10493 Steel Jaw Pusher... -
Page 18: Troubleshooting
● TROUBLE SHOOTING If a problem occurs, check the followings. If the problem persists after checking the items in the table below, contact your nearest “LOBSTER” dealer or direct to us. In making any enquiries about this product or requests for repair work, first check the troubleshooting items below, and then make a note of the model number, the usage conditions and the trouble symptoms in as much detail as possible. -
Page 19: Warranty And Service
WARRANTY & SERVICE ® LOBSTER WARRANTS THAT GOODS COVERED BY THIS MANUAL WILL CONFORM TO APPLICABLE SPECIFICATIONS A N D D R A W I N G S A N D T H AT S U C H G O O D S W I L L B E MANUFACTURED AND INSPECTED ACCORDING TO GENERALLY ACCEPTED PRACTICES OF COMPANIES MANUFACTURING INDUSTRIAL TOOLS. - Page 20 ＭＥＭＯ...
