Summary of Contents for Ozone OZ-FGL-LIFE-G2G
- Page 1 WELCOME USER MANUAL GLASS DOOR LOCK OZ-FGL-LIFE-G2G OZ-FGL-LIFE-G2W Fingerprint Password OzoLife Mobile App RFID Card Remote Control (Optional) DOWNLOAD NOW OzoLife OzoLife iOS OzoLife Android WWW.OZONESECUTECH.COM EMAIL ID: INFO@OZONESECUTECH.COM | CUSTOMER CARE: +91-9310012300...
-
Page 2: Table Of Contents
INDEX Introduction Technical Specification Lock Structure Product Features & Packing Details Installation Steps Operation Steps 9-10 Warranty Card 12-13... -
Page 3: Introduction
INTRODUCTION CAUTION - Necessary safety measures must be ensured before starting the installation to prevent damage to assets and personnel. - Accuracy of the door preparation is a critical parameter for the proper door installation, Lock functioning, and security of the product. - Page 4 - The information in this user guide is subject to change without notice. This product must be installed by an Ozone professional. In case of defects resulting from installation by other than an Ozone professional, the Product warranty will be void. Ozone reserves the right to charge on out-of-warranty products.
-
Page 5: Technical Specification
Technical Specification < Fingerprint Speed 0.3S Working Voltage 4 pcs (1.5V “AA”) alkaline batteries Misidentification < 0.0001% Rate Opening Method Left and right interchange Zinc alloy/ABS Lock Material Fingerprint Capacity 200 Pcs 0.96 inch Display Size Static power Less than 10ua consumption Fingerprint, RFID Card, Passw Unlock Way... -
Page 6: Lock Structure
Lock Structure 1. Display 2. Keypad & RFID Card 3. Fingerprint 4. Battery Cover 5. Mechanical Knob 6. Emergency Power Supply 7. Door Bell (1) Display (4) Battery Cover 9:49 Welcome (2) Keypad & RFID Card (7) Door Bell (3) Fingerprint (5) Mechanical Knob (6)Emergency Power Supply... -
Page 7: Product Features & Packing Details
PRODUCT FEATURES 1) Micro USB emergency power supply: Incase of emergency the product could be operated by USB through power bank. 2) Fingerprint: use registered fingerprint to open the lock. 3) Digital keypad/RFID card indication area: use registered password or RFID card to open the lock. -
Page 8: Installation Steps
The reversing method of frameless glass door Remove the 4 fixing screws on the front panel, rotate the U-shaped bracket by 180°, and then tighten the 4 screws. 180° Frameless glass door installation Adhesive positioning plate Adhesive posi oning plate Glass door seam should be more than 2mm Glass door centerline Remove the adhesive tape from the... - Page 9 Firstly push the U clip from the side Plug in the cables and cover the of the glass door and screw up 4 back panel and then screw up 4 fixing screws. fixing screws. (The side lock fixing is as above) (The side lock fixing is as above) Cable assembly and disassembly...
- Page 10 The installation of single opening (blade) Safe opening area Arrow points to the outside Install the main lock (installation Note:When the blade is installed, its method is the same as above), and triangle direction must point to the then unscrew the lock tongue to outside (the hole should be opened mark it when the door is closed according to the size of opening...
-
Page 11: Operation Steps
How To Pair The Lock With Ozolife App: ADD LOCK Search OzoLife app from the App store and register. Open App and access it and follow below way add lock (Auto connection/add manually) Auto connection. Add Manually Wake-up the keypad then press # then enter registered admin (password) with # or fingerprint or RFID card. - Page 12 ADD TEMPORARY CODE SETTING After adding temporary code, need to try on lock then finished. Max. Support 10 groups of code, and code can be edited or deleted. Temporary codes can be settled down by period. Remote unlocking: Press bell icon when keypad is off then unlock the door through Ozolife app How To Add Remote Control (Op onal) Wake-up the keypad then press # then press 1 for “Manage user’...
-
Page 13: Faq
FAQs How to read operation records? Select “Opening record” option on lock main interface After installation, touch sensing keyboard or screen not responding. a) First check that the positive and negative electrodes of the battery have been installed upside down. b) Check whether the battery has enough power. -
Page 14: Warranty Card
WARRANTY CARD E-Mail ID Invoice No. Total Quantity... - Page 16 • Read this manual carefully before installation and keep it safe, for future reference. OzoLife Ozone Secutech Pvt. Ltd. Registered Office: H 40, Bali Nagar, New Delhi - 110015, India Operations Office: Plot No. 548, Phase V, Udyog Vihar , Gurugram, Haryana - 122016, India...
