- Page 1 User Manual GSL60RDS | GSL90RDS 60 & 90cm Slide-out Rangehood Please read the user manual carefully before using the unit...
- Page 2 Dear Customer, Congratulations on the purchase of your new product from Glen Dimplex Group. We recommend you please take some time to read the instruction manual thoroughly to familiarise yourself with the functionality and operations to ensure optimum performance of your new appliance.
-
Page 3: Table Of Contents
Contents Front Fascia Rail Replacement Safety Information 4 - 6 Inserting and Replacing Warnings the Carbon Filters Safety Precautions Install the Check Valve Product Use Cabinet Mounting — Top Unpacking Cabinet Mounting — Wall Environment Protection Cleaning & Maintenance Product Overview Cleaning the Rangehood Included in the Box Cleaning the Filters... -
Page 4: Safety Information
Safety Information We recommend that you read the instructions in this owner’s manual carefully before use for the best performance and to extend the life of your appliance. It will provide you with all the information you need to ensure its safe installation, use and maintenance. -
Page 5: Safety Precautions
Safety Information — If the power supply cord of this rangehood is damaged in any way, it must only be replaced by one of our authorised service agents. Please call or email our customer service team for further assistance. Contact details can be found on the back of this user manual. —... -
Page 6: Product Use
1.1 General Safety Warnings 1. SAFETY INSTRUCTIONS Safety Information Product Use This rangehood is designed to be used in households and for non-commercial uses such as: 1.1 General Safety Warnings 1. SAFETY INSTRUCTIONS — Staff kitchen areas in shops, offices and other working environments. —... -
Page 7: Product Overview
Product Overview Ducting outlet Light Controller Aluminium mesh filters Included in the Box — 1x rangehood — 1x 3m length of 120mm flexi ducting — 1x 80mm facsia (fitted) — 1x set of CF110 carbon filters — 1x 40mm fascia —... -
Page 8: Daily Use
Daily Use Operating the Rangehood Fan off Light switch Light off Low fan speed Light on Medium fan speed Fan speed switch High fan speed Power the rangehood by sliding out the drawer. To operate the rangehood fan, slide the fan speed switch to low fan speed position. -
Page 9: Installation
Important! In addition to the information this manual, please check all relevant state requirements for minimum-maximum mounting heights, as well as regulations regarding the extraction of air. Glen Dimplex is not liable if your rangehood is not installed in accordance with these legal requirements. -
Page 10: Rangehood Installation Height
Important! If the user / installer decides to install the 650 - 750mm rangehood at a distance of less than the minimum height above the cooking surface, Glen Dimplex declines responsibility for any damage suffered to the rangehood or surrounding cabinetry due to excess heat or steam. -
Page 11: Ducting Options
Installation Ducting Options — Before beginning the installation of your rangehood, consider your ducting method. It is recommended to duct the rangehood outside wherever possible to ensure maximum performance. The guide below illustrates the various ducting options to be considered. Ducting out through the roof Ducting out through the wall Ducting out through the eave... -
Page 12: Recirculation Or Vented Operation
Installation Recirculation or Vented Operation — This rangehood can be operated in either vented mode or in recirculating mode. — To set the rangehood to either operation, remove the mesh filters and turn the switches to desired operation as shown below. Recirculating or Vented Operation Vented Mode Turn the switches here to enable venting outside. -
Page 13: Front Fascia Rail Replacement
Installation Front Fascia Rail Replacement Note: For the recirculating mode, the 80mm fascia panel must be fitted so the air vent at the front of unit is not covered during operation. — When ducting the rangehood to the outside atmosphere, either the 40mm or 80mm fascia panel can be used. - Page 14 Installation Insert the fold of the alternative front fascia onto the edge of the slide out extension rail and push down, figure 4. Once the fascia panel is pushed in, pivot it left or right to align the holes in the extension plate with the screw hole provisions in the fascia panel, figure 5.
-
Page 15: Inserting And Replacing The Carbon Filters
Installation Inserting and Replacing the Carbon Filters (Recirculating Mode Only) The carbon filters are utilised to remove odour form the air that is recirculated back into the room. Depending on the amount of use, the carbon filters should be changed every 3 - 4 months. -
Page 16: Install The Check Valve
Installation Install the Check Valve (Ducted Operation Only) Ensure correct operation of the butterfly flaps before installing the check valve onto the rangehood. Position the check valve over the outlet in the top of the rangehood and manoeuvre it so that each of the 4 tabs clicks into place, figure 1. The rangehood should be placed at a distance of 650 –... -
Page 17: Cabinet Mounting - Top
Installation Cabinet Mounting — Top Drill 6 holes with a diameter of Ø4mm into the partition of the rangehood cabinet following the measurements outlined in figure 2. Note: If the rangehood is to be recirculated, then skip to step 3. Back of Cabinet... - Page 18 Installation Following the dimension in figure 3, cut a 130mm hole into the partition and as well as the top of the cabinet, figure 4. Following the dimensions in figure 3, drill a Ø45mm in the partition of the cabinet. This will allow the power cable to pass through and be plugged into a 10amp GPO which should be positioned in the top left of the cabinet.
- Page 19 Installation Feed the ducting through the partition and secure the rangehood to the cabinet with the enclosed 6 x M4 screws and flat washers, figure 6. If there is a gap between the back of the rangehood and cabinet, attach the rail with the included screws figure 7, and adjust as required. Feed the ducting (if connected) through the hole in the top of the cabinet and connect to an exhaust pipe leading to the outside atmosphere.
-
Page 20: Cabinet Mounting - Wall
1 or 2 (depending on model purchased). Secure fixing screws into the lower set of holes ensuring that they protrude out 5-6mm. Note: If the rangehood is to be recirculated, then skip to step 3. GSL60RDS GSL90RDS... - Page 21 Installation Following the dimension in figure 3, cut a 130mm hole into the partition and as well as the top of the cabinet, figure 4. Following the dimensions in figure 3, drill a Ø45mm in the partition of the cabinet. This will allow the power cable to pass through and be plugged into a 10amp GPO which should be positioned in the top left of the cabinet.
- Page 22 Installation Fix the included L brackets to the top of the rangehood, figure 6. Feed the ducting (if connected) through the partition and secure the rangehood to the cabinet by hanging it on the screws installed in step 1. Fix 2 more screws through the L brackets into the cabinet wall to secure the rangehood, figure 7.
-
Page 23: Cleaning & Maintenance
LED lamp assemblies are a spare part and are not repairable or replaceable by the customer. If an LED lamp fails, it must be replaced by a suitably qualified technician. Please contact Glen Dimplex after sales service via the details on the back of this user manual for any service enquiries. -
Page 24: Troubleshooting
Troubleshooting Problem Possible cause Solution Motor has failed Contact service agent Lights on but motor is not working Possible PCB issue Contact service agent Disconnect power and Fan is obstructed clear any obstructions House fuses blown Reset / replace fuses Lights and motor not working Refit mains power... -
Page 25: Product Information
Product Information Climate class GSL60RDS GSL90RDS Ducted outlet size (mm) Carbon filter CF110 (included) Voltage 220 - 240V ~ / 50Hz Extraction 440m Light power 1 x 5W LED strip Filter qty. & type 2x aluminium mesh 2x aluminium mesh... -
Page 26: Manufacturer Guarantee
2 years from the date the product is purchased as a brand-new product from a retailer located in Australia / New Zealand. In the case of Glen Dimplex Group products used for purposes other than personal, domestic or household purposes (including business or commercial use), a period of 90 days from the date the product is purchased as a brand-new product from a retailer located in Australia / New Zealand. - Page 27 Glen Dimplex; The repair relates to the replacement of consumable parts such as fuses and bulbs or any other parts of the product which require routine replacement;...
- Page 28 4. How to Make a Claim You may make a claim under this warranty through our website, contacting our customer care line or via email. Contact details for Glen Dimplex Australia and New Zealand can be found at the end of this document.
- Page 29 Notes...
- Page 30 Product / Installer Details For future reference we suggest that you staple a copy of your purchase receipt here and complete the below so the information is always at hand. Product Details Model number: Serial number: Description: Purchase Details Date of purchase: Place of purchase: Store name: Address:...
- Page 31 All Glen Dimplex appliances are for Domestic use only, and must be installed by a licenced installer into Domestic Applications only, without exception and to the required Authorities guidelines.
- Page 32 glendimplex.com.au | glendimplex.co.nz...
