Uniteck UNIFIX 300.1 C Instruction Manual

The tilting mounting bracket for campervan
Hide thumbs

Advertisement

Quick Links

Download this manual
EN
Le support de fixation inclinable
FR
pour camping-car
The tilting mounting bracket for
EN
campervan
El soporte de fijación para camper
ES
Il supporto di fissaggio per
IT
camper
UNIFIX
300.1 C
www.uniteck.fr
p.2 – 13
p.14 – 25
p.26 – 37
www.uniteck.fr
CO00492
02/05/2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the UNIFIX 300.1 C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Uniteck UNIFIX 300.1 C

Summary of Contents for Uniteck UNIFIX 300.1 C

  • Page 1 300.1 C Le support de fixation inclinable p.2 – 13 pour camping-car p.14 – 25 The tilting mounting bracket for campervan p.26 – 37 El soporte de fijación para camper Il supporto di fissaggio per www.uniteck.fr camper CO00492 www.uniteck.fr 02/05/2022...

  • Page 2: Safety Instructions

    The inclination can be adjusted using two springs positions with stop angles at 45° or 65°. For a precise adjustment, UNIFIX 300.1 C is delivered with a rope fixing system that allows to keep an inclination angle between 0° and 65°.
  • Page 3 PANELS COMPATIBILITY UNIFIX 300.1 C was specially designed to fix UNISUN 300.12 M photovoltaic panels (300W) with the following dimensions:1500 x 990 x 40mm. DIMENSIONS Mounting bracket dimensions in centimeters (without panel) : RECOMMENDATIONS • Mount Unifix mounting bracket only on surfaces with sufficient load-bearing capacity.
  • Page 4 UNIFIX 300.1 C – ASSEMBLY Spare parts list : N°1 N°2 N°3 N°4 N°5 N°6 N°7 N°8 N°9 N°10 N°11 N°12 N°13 N°14 N°15 N°16 N°17 N°18 M8x70 BHC M8x20 N°19 N°20 N°21 N°22 N°23 N°24 N°25 N°26 M6x16 M5x50 N°27...
  • Page 5 UNIFIX 300.1 C – ASSEMBLY • Place N°2 parts at the end of each N°1 part. Pre-tighten the nuts, final tightening will be done later. N°19 M6x16 N°20 N°21 N°1 N°2 Same step must be done 4 times • Place and screw parts N°3, 4, 5, 6 at the end of each N°1 part. Then tighten the nuts already pre- tightened on former step.
  • Page 6 UNIFIX 300.1 C – ASSEMBLY Screw parts N°7 and N°8 • N°7 N°8 N°16 N°17 N°18 BHC M8x20 • Pre-tighten parts N°9 on parts N°3 and N°4 (the ones that do not have locks). Final tightening will be done later.
  • Page 7 UNIFIX 300.1 C – ASSEMBLY • Place parts N°12, 13, 14, 10 as on step N°1 below. • Insert parts N°15, 17, 18 as on step N°2. Tighten. Note: Adjust tightening so that part N°10 is not blocked, as it will move with the panel during inclination.
  • Page 8 UNIFIX 300.1 C – ASSEMBLY • Pre-tighten parts N°11 on part N°10. Close the mounting bracket and check that openings of parts N°11 are properly centered to the screws. Once the openings well centered, you can tighten the screws. •...
  • Page 9 These values correspond to stop angles (max. inclination) of each position. • Screw the rope system, that allows to adjust panel’s inclination from 0° to 65°, and to keep a choosen position. N°24 M5x50 N°20 N°21 N°23 N°25 N°26 N°27 www.uniteck.fr...
  • Page 10 Screw the panel to the mount (fix it on parts N°10). Be sure to properly place parts N°16 and N°28. N°16 N°17 N°18 N°28 M8x20 BHC M8x20 Lock system positions : Closed Open Before starting the vehicle, check that the locks are in “closed” position, and locked by key. www.uniteck.fr...
  • Page 11 Recommendations : Apply glue in lines. Avoid closed shapes that prevent air from flowing and slow down polymerization: If the gluing surface is not sufficient compared to the glue and to gluing areas, it is possible to reforce the fixing by adding self-drilling screws and bolting. Gluing areas in grey www.uniteck.fr...
  • Page 12 Fixing on roof rack (U-bolts and screws not included): screw U-bolts in the grooves on parts N°3, 4, 5 and 6. Oblong drilling allows to adjust the mount on the roof rack depending on the distance between the bars, and their diameter (4 M6 U-bolts with screws must be added). www.uniteck.fr...

  • Page 13: Warranty

    Caution: Our after-sales service does not accept carriage forward/ collected returns. After the warranty, our after-sales service ensures repairs after acceptance of a quotation. After-sales service contact : UNITECK 1 Avenue de Rome Zae Via Europa - bâtiment Cassis 34350 Vendres...
