EDIFIER MS50A User Manual page 2

MS50A
WIRELESS SPEAKER
User manual
1. Product overview
Thank you for choosing EDIFIER! For correct operations,
please carefully read this manual before use.
Note:
• Information contained herein may be subject to change from time
to time without prior notice.
• MS50A is an active speaker using both Wi-Fi and Bluetooth
wireless technologies. The core application is online streaming
media playback based on Amazon Alexa (Work with Alexa). After
registering this speaker to Amazon Alexa with an Amazon account,
you will be able to use streaming services such as Spotify,
Amazon Music, Pandora, etc. The speaker can be controlled in
Alexa App as well as using interactive voice devices such as Echo.
With Alexa, you can create your personal playlist, control play/
pause, build a multi-room system with other devices, and build
two speakers to a stereo group.
• The MS50A is compatible with Apple AirPlay.
• This speaker can be connected to phones, PC, etc. for wireless
playback via Bluetooth.
• You can refer to the Quickstart Guide (included in the box) to set
up and enjoy your music right away.
2. What's in the box
Open the box and ensure the following items are included:
Speaker
Note:
• Please use the power cable included in the box.
3. Operation
Button controls:
①
②
① Mode switch:
Press: audio mode switch
Press and hold for 3s:
Wi-Fi connection
(Wi-Fi mode)
Bluetooth pairing
(Bluetooth mode)
② Previous track
③ Next track
④ Pause/play
Press and hold for 6s:
restore to factory settings
Indicators:
3s
3s
Connection:
Wi-Fi connection
or tablet from the App Store/Google Play Store or from
www
2. When power
enter Wi-Fi connection mode (white LED blinking rapidly). To reset
Wi-Fi connection, press the "
(white LED), then press and hold the "
Wi-Fi connection mode again;
device, and connect the speaker to network;
4. Once connected, a steady white LED will be lit;
5. This speaker can work with alexa, after it is connected to
n
speaker to your Amazon Alexa account, please follow the
instructions to complete the registration.
Bluetooth connection
1. Power on this speaker and wait for it to start up (approximately
20 seconds). Press the "
(blue LED).
2. This speaker is in Bluetooth pairing mode when blue LED blinks
rapidly, please select "EDIFIER MS50A" to connect.
3. Blue LED will lit steadily after pairing is complete, now you can
play music on the paired device.
Stereo group and multi-room system setup:
Stereo group setup:
You can use two MS50A to build a stereo group for better music
experience.
1. Make sure two MS50A speakers are connected to the same
network as your mobile device;
2. To setup stereo gr
group" on the home screen and click to add, then follow the
instructions to build a stereo group;
3. Set the two speakers as the left and right channel output
respectively and rename the stereo group.
4. To cancel the stereo gr
stereo group you want to cancel, and follow the instructions to
cancel the stereo group.
Multi-room system setup:
After this speaker is registered in the Amazon Alexa, you can add it to
a multi-room system through the Alexa App and play music/podcasts/
news on multiple speakers simultaneously.
1. Preparations: Connect this speaker to the same network as the
other "work with Alexa" speakers, and ensure they are logged in
to the same Amazon Alexa account.
2. Setup: Open the Alexa App, switch to the Device interface, follow
the instructions to join the existing multi-room system, or create a
new multi-room system. Please see relevant instructions of the
Alexa App for details.
Stereo group and multi-room system setup:
Music playback:
1. Online steaming media playback
(1) For Amazon Music, Spotify, Pandora, Tuneln, iHeartRadio and
other music services linked to Alexa, after relevant accounts are
linked, you can play through Alexa and control this speaker by
using other interactive voice devices like Echo.
can select to play on this speaker in the Spotify App;
air-played by using iPhone, iPad, iMac and other devices.
2. Local playback
For local playback devices, you can connect them to this speaker
through Bluetooth for playback, or use Apple AirPlay or Spotify
Connect to play through Wi-Fi.
Volume control:
The volume can be controlled in the following ways:
(1) Touch panel on this speaker: In Wi-Fi or Bluetooth mode, volume
level can be controlled through the touch panel on this speaker,
please see the touch panel control instructions;
and enter the playing control interface for volume control;
(3) Interactive voice devices: Under the same network, use the
interactive voice devices like Echo logging in the same Amazon
account to control volume through voice commands.
System update and restore to factory settings
System update
re version code in the "
Restore to factory settings
Press and hold the "
"Restor
factory settings, please note that Wi-Fi connection, Bluetooth pairing
and Amazon account registration information will all be cleared,
meanwhile, this speaker will return to Wi-Fi mode and the volume will
resume to 50% level.
4. Troubleshooting
Troubleshooting
1. Check if the speaker is ON.
2. Ensure the speaker is switched to Bluetooth mode.
3. Disconnect from any Bluetooth device by pressing and holding
the "
4. Turn off the speaker and restart it, then switch to Bluetooth
mode and search for "MS50A" again.
No sound
1. Check if main power is connected, or if the wall outlet is
switched on.
is set correctly on the speaker.
3. Check if there is a signal output from the audio source.
4. Try to turn up the volume using the volume control.
5. Turn off the speaker and restart it.
5. Appendix
Power output: mid-bass+treble: 25W+15W
Frequency response: 52Hz-18KHz
Audio input: Wi-Fi, Bluetooth
Declaration for EU
Frequency Band (Bluetooth): 2.402GHz ~ 2.480GHz
Frequency Band (2.4G): 2.400GHz ~ 2.4835GHz
Frequency Band (5G): 5.15GHz ~ 5.35GHz, 5.47GHz ~ 5.725GHz,
5.725GHz ~ 5.85GHz
RF Power output: ≤20 dBm (EIRP) (5.725GHz~5.850GHz excluded)
RF Power output: ≤14 dBm (EIRP) (5.725GHz~5.850GHz)
Model: EDF100008
FCC ID: Z9G-EDF112
IC: 10004A-EDF112
P.O. Box 6264
Hong Kong
Tel: +852 2522 6989
Fax: +852 2522 1989
Printed in China
NOTICE:
For the need of technical improvement and system upgrade, information
contained herein may be subject to change from time to time without prior notice.
Products of EDIFIER will be customized for different applications. Pictures and
illustrations shown on this manual may be slightly different from actual product.
If any difference is found, the actual product prevails.
MS50A
Haut-parleur Sans Fil
Guide de démarrage rapide
Quickstart guide
(1) White LED: Wi-Fi mode
State
Blink rapidly
Steady lit
Heartbeat
Blink
(2) Blue LED: Bluetooth mode
State
Blink rapidly
Steady lit
Blink
(3) Blue and white LED blinks alternately:
starting up/of
State
Blink rapidly
Brightness of indicators
(1) Unconnected to network: low brightness;
(2) Connected to network:
Day time (7am to 9pm): full brightness
Night time (9pm to 7am): low brightness
r.com;
" button on this speaker for 6s or click
" button, then search for "MS50A" again.
Wireless Speaker
Quickstart Guide
③
⑤
⑥
④
⑤ Power on/off / mute
Press: mute/unmute
Press and hold for 1.5s:
power on/off
⑥ Slide counter-clockwise:
volume down
⑦ Slide clockwise: volume up
Description
3 blinks per
second
Steady lit
Long and short
blinks alternatively
1 blink per second
Description
3 blinks per
second
Steady lit
1 blink per second
Description
Blue and white
LED lit and off
alternately
and rapidly
" button to switch to Wi-Fi mode
rompt you to register this
" button to switch to Bluetooth mode
ready connected to network
" interface, and upgrade
Power cable
Functions
Ready to connect
to a new Wi-Fi
network
connected
disconnected
Functions
Bluetooth pairing
Bluetooth
connected
re update
Functions
starting up / over
update
" button for 3s to enter
restore to
r.com/support
⑦
Wi-Fi
Wi-Fi
Mute
Mute
reo
you
can be
or the
relevant
