- Page 1 INSTALLATION GUIDE G- SYST E M FR EE STA ND I N G SCAN THIS QR CODE FOR THE FULL INSTALL VIDEO. Questions or Concerns? Contact us at: support@tealtriangle.com...
- Page 2 WARNING AND DISCLAIMER Spire LLC (d/b/a Teal Triangle) expressly disclaims any and all liability for personal injury, property damage or loss, whether direct, indirect, incidental, resulting from the incorrect mounting, improper use, inadequate maintenance, or neglect of this...
- Page 3 G-SYSTEM PARTS WEIGHT LIMITS: REQUIRED TOOLS: 50 lbs. max per attachment 10mm socket 300 lbs. max total 10mm or adjustable wrench Attachments Attachment Rail Qty Varies Qty 1 Upper Vertical Track Qty 2 Bike kits come with this U-shaped Horizontal support Upper Brackets instead of the 3rd Horizontal Qty 4...
- Page 4 Fasten two Horizontal Supports (B) to the left and right Horizontal Tracks (A). Use 8 Small Hex Bolts (K), 16 Small Washers (O), and 8 Hex Nuts (N) for this step. Take note of the orientation in the picture. Typical Hardware Configuration Fasten each Lower Vertical Track (C) to the Base (A).
-
Page 5: Other Kits
Assemble a Horizontal Support (B) to both of the Lower Vertical Tracks (C) as seen below. Use 4 Small Hex Bolts (K), 8 Small Washers (O), and 4 Hex Nuts (N) for this step. For Bike kits, use the U-shaped bar. For other kits, use the same Horizontal Supports as the Base. OTHER KITS BIKE KITS Fasten the Upper Brackets (D) onto both Lower Vertical Tracks (C) by aligning the bottom two holes... - Page 6 Assemble the Upper Vertical Tracks (E) by aligning the two END CAP bottom holes to the remaining two holes on the Upper Bracket (F). Use 4 Large Hex Bolts (M), 8 Small Washers (O), and 4 Hex Nuts (N) for this step. Do not forget to tighten the hardware from last step as well.
- Page 7 Add attachments as desired by aligning the through hole on the Attachments (G) with the through hole on the Attachment Bar (F) and insert a Quick Release Pin (H). Ensure the pin extends through both sides of the attachment mount. Reference the example below. Notice: You should be able to see the Quick Release Pin pass through the bottom...
