- Page 1 INSTALLATION INSTRUCTIONS USER GUIDE INDUCTION COOKTOP with INTERGRATED RANGEHOOD 900MM BLACK 320295 To prevent the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time...
-
Page 2: Product Brief Introduction
1. Applicable model: This manual applies to the following models. Please check the models carefully. （The dimensions marked in the figure are for reference only. MAX is the maximum height that the range hood can be lifted or lowered） Model：320295... -
Page 3: Installation Instructions
Installation instructions 1.Instructions before installation Read the full instructions carefully. Remind the installer - Always leave the instructions with the consumer. Remind consumers - Save the instructions for later use. This product must be connected to the power supply by professional installation personnel. -
Page 4: Included Parts
2.Included Parts： Range Hood Oil cup(1 pcs) Vertical 90° elbow (2 pcs) Round to square right Angle joint (1 pcs) 1m long straight pipe (1 pcs) Joint screws (2 pcs) Plastic duct tape (1 pcs) - Page 5 3.Installation guide & Note: Please wear gloves during installation to prevent burrs from cutting hands 3.1 Refer to Figure 1 to open mounting holes on the stove. Figure 1...
- Page 6 3.2 This product has internal circulation and out-emission two discharge installation modes. a.Internal circulation installation mode： Note: If the cabinet needs to be taller and wider than the size shown in Figure 2 and Figure 3, you will need to purchase longer straight pipe. Figure 2 Figure 3...
- Page 7 Figure 4 Refer to FIG. 1, FIG. 2 and FIG. 3 to determine the size of the cabinet, as shown in FIG. 4. First connect the round-to-square right Angle joint (1) and the vertical 90° bend (3) together. The middle is connected with a straight pipe (2) (Note: the length required to cut a 1m long straight pipe to this point).
- Page 8 (1) Then put the cooker hood into the cabinet, and cut the remaining straight pipe into two sections of appropriate length (straight pipe (6) in figure 6 and straight pipe (8) in figure 7))，Connect the straight pipe (6), vertical 90° elbow (7) and straight pipe (8) to the pipe on the cooker hood in turn according to the instructions in Figure 6 and 7.
- Page 9 Figure6 Figure 7...
- Page 10 Figure 8 b. Out-emission Installation method： Note: Out-emission installation mode standard configuration of the exhaust pipe, some pipes need to be purchased by oneself. 图 9...
- Page 11 Figure 10 Figure 11...
- Page 12 1) Refer to FIG. 1, FIG. 9 and FIG. 10 to determine the size of the cabinet, as shown in FIG. 11. First connect the round-to-square right Angle joint (1) and the vertical 90° bend (3) together. The middle is connected with a straight pipe (2) (Note: the length required to cut a 1m long straight pipe to this point).
- Page 13 Figuer13 Figure 14...
- Page 14 Figuer 15...
- Page 15 EN - Instruction on mounting and use Strictly observe the instructions in this manual. No liability -In order to ensure the installation will be assumed for any problems, damage or fires caused by complies with current safety standards, a failure to comply with the instructions in this manual. The device is intended for domestic use only, to cook food and regular omnipolar switch is required that extract the fumes generated by cooking.
- Page 16 electric shock. relative zone. -The device is not intended to be run with - Never use aluminium foil to cook with, an external timer or a separate remote and never directly place products control system. packaged with aluminium on top of the cooking surface.
- Page 17 supervised have CAUTION: When the hob is on, received instructions regarding the accessible parts of the the safe use of the device and hood may become hot. provided they have a thorough Caution! Do not connect the understanding device to the electrical network associated risks.
- Page 18 Recommended pan bottom 2.1.2 2. Use diameters IMPORTANT: if the pots Using the hob are not correctly sized, the cooking The induction cooking system is zones will not turn on based on the physical phenomenon of For details of the minimum pot diameter magnetic induction.
- Page 19 Figure 16...
- Page 20 Figure 17...
- Page 21 3.Operation Control panel Note: To select the commands, simply touch (press) the symbols representing them Icon Button Name Button Type Definition Power switch Touch key-press Turn on and off the cooker hood Touch key-press Starting fan Gear Sliding bars control fan and induction Touch key-press adjustment cooker gears...
- Page 22 Boost function Touch key-press Start the boost function of the smoker Gear display LED digital tube Display fan and induction cooker gear Delay Display the set time of delay shutdown shutdown LED digital tube of the cooker hood 1-99 minutes time display Induction Touch key-press...
- Page 23 3.In the case of any burner working，press can enter the pause function, All burners will not be heated during the pause. If there is no operation to exit the pause for more than 30 minutes after entering the pause function, the whole machine will automatically shut down.
- Page 24 wind speed of the smoke machine on the stove will follow the principle that the wind speed of the smoke machine will increase by 1 gear when the induction cooker increases by 1 gear; For example, the induction cooker has two stoves at work, one of which is in the second gear, the other is in the fourth gear, then the wind speed of the smoke machine is in the sixth gear;...
-
Page 25: Troubleshooting
Troubleshooting Fault protection category Fault protection code Loss of synchronization High input voltage protection Low input voltage protection Pot sensor open circuit Short circuit in cooker sensor Pot sensor high temperature IGBT sensor open circuit IGBT sensor short circuit IGBT sensor high temperature Communication failure Customer service Before contacting Customer Service... -
Page 26: Care And Maintenance
Care and maintenance 1.It is recommended that you adjust the appliance for about 15 minutes before cooking to completely eliminate water vapor and peculiar smell 2.Wash filters, glass and other surfaces of the cooker hood regularly with a damp cloth stained with industrial alcohol or detergent. Suggestion: Wipe the surface of the range hood once every time you use it. - Page 27 Figure 18...
