CommFront USB-Serial-3 Manual

Industrial USB
Opto-isolated Converter
(Part Number: USB-Serial-3)
Http://www.CommFront.com
Revision: 1.7 www.CommFront.com
RS-232/485/422
Page 1 of 4
Industrial USB RS-232/485/422
Opto-Isolated Converter
Part Number: USB-Serial-3 (DIN-Rail/Wall-Mount)
■ INTRODUCTION
The USB-Serial-3 is a rugged, industrial-grade, optically-isolated USB to RS-232/485/422
converter, which can be used to convert any standard USB port into a three-wire RS-232
port, a two-wire RS485 port, or a four-wire RS422/RS485 port and vice versa. This product
features opto-isolation circuitry, which effectively protects your USB devices from transient
surges, noise problems, ground loops, remote lightning and spikes. The unit is powered from
the USB port and it features data format auto-sensing and self-adjusting; therefore, no DIP
switch or jumpers are required. The unit can be used to communicate with one loop of up to
128 units of RS485/RS422 devices. When working with RS-485 signals, the CommFront's
auto-turnaround feature eliminates the need for flow control. The unit uses the latest chipset
from Silicon Labs and is fully compatible with Windows 10/8/7/Vista/XP/Server2003/2000
(32-bit), Windows 10/8/7/Vista (64-bit), Win CE (5.0, 6.0), Mac OSX, and Linux (2.6x,
2.4.36). Note: the latest drivers (chipset: Silicon Labs' CP210x) are available at
https://www.silabs.com/developer-tools/usb-to-uart-bridge-vcp-drivers.
FEATURES
■
Industrial grade enclosed in a rugged, rustless ABS housing.
•
Direct DIN-Rail or wall/panel mounting without using any unsecured brackets or adapters.
•
Adds one RS-232, RS-485 or RS-422 port to your USB port.
•
Optical isolation effectively protects USB devices from ground loops, transient surges,
•
remote lightning and spikes. It also eliminates ground loop and noise problems.
Communicate with one loop of up to 128 units of RS485/RS422 devices.
•
Supports high-speed data rates: 300 to 115,200 bps.
•
Operating temperature: -40ºF to 185ºF (-40ºC to 85ºC).
•
Built-in 600W surge protection, 15kV static protection and circuit protection.
•
Built-in 120Ω end-of-line terminators (selectable) for system reliability and easy installation.
•
USB port powered, no external power is required.
•
RS485/RS422 auto-detection, no jumper setting is required.
•
Plug and play; Data direction auto-turnaround, no flow control is required.
•
Surface Mount Technology manufactured to RoHS and ISO-9001 standards.
•
Safety: Strictly certified by TUV (Cert No. SG-CE-100004; SG-FCC-100001).
•
5-year manufacturer's warranty.
•
■ SPECIFICATIONS
Compatibility: USB 2.0, EIA/TIA RS-232/485/422 standards
Power Source: From USB port
Current Consumption: Less than 200mA
Baud Rates: 300 to 115,200 bps (auto-sensing and self-adjusting)
Optical Isolation: 2500Vrms (AC, 1 min)
Distance: USB: 10ft (3m); RS232: 16ft (5m); RS485/422: Depending on
the power from USB port, will transmit up to 4000ft (1.2km) at
19,200 bps
Connectors: USB: Type B male; RS-232/485/422: 10-way terminal block
Accessories: 1x 5ft (1.6m) USB extension cord (Type B female to Type A
female)
Maximum Number of Drops: RS-232: 1; RS-485/422: 128
Surge Protection: 600W
Static Protection (ESD): Up to 15kV
End-of-line Terminators: 120Ω (Built-in)
Dimensions (H x W x D): 4.5 x 3.6 x 0.9 in (115 x 73 x 33 mm)
Weight: 4.2 oz (120 g) (with terminal block)
Operating Temperature: -40ºF to 185ºF (-40ºC to 85ºC)
Operating Humidity: Up to 90% RH (no condensation)
