CommFront USB-232-1+CVT-485 422-1 Quick Start Manual

USB RS-422/RS-485 Converter
Part Number: USB-232-1+CVT-485_422-1

INTRODUCTION

■
This USB RS422/RS485 converter is a port-powered bi-directional USB to RS422 or RS485
converter, which can be used to convert any standard full-duplex USB port into a four-wire
RS422/RS485 port or a two-wire half-duplex RS485 port and vice versa. The unit can be used to
communicate with one loop of up to 128 units of RS422/RS485 devices. The unit is powered from the
USB port and it supports data auto-sensing & self-adjusting, no baud rate setting is required. And
with the data direction auto-turnaround technology, no external power or flow control is required.
The unit uses the latest FTDI chipset and is fully compatible with Windows 7/Vista/XP/Server2008
/2003/2000/98 (32-bit), Windows 7/Vista/XP/Server2008/2003 (64-bit), Win CE, Mac, and Linux.
Note: the latest drivers (chipset FT232B) are available at http://www.ftdichip.com/Drivers/VCP.htm.

FEATURES

■
Adds one RS-422 or RS-485 port to your USB port.
•
Communicate with one loop of up to 128 units of RS422/RS485 devices.
•
Built-in 120Ω end-of-line terminator for reliability and easy installation.
•
Data direction auto-turnaround, no flow control is required.
•
Supports 300 to 115,200 baud (auto-sensing and self-adjusting).
•
Supports Windows 7/Vista/XP/Server2008/Server2003/2000/98 (32-bit), Windows 7/Vista/XP/
•
Server2008/Server2003 (64-bit), Win CE, Mac, and Linux.
Supports remote wakeup and power management.
•
Plug and play (hot-pluggable, data format auto-sensing and self-adjusting).
•
Port-powered, no external power required.
•
No IRQs required, no IRQ conflicts.
•
Surface Mount Technology manufactured to RoHS and ISO-9001 standards.
•
Safety: Strictly certified by SGS/TUV; 5-year manufacturer's warranty.
•

SPECIFICATIONS

■
Compatibility:
Power Source:
Current Consumption:
Baud Rates:
Distance:
Connectors:
Maximum Number of Drops:
End-of-line Terminator:
Dimensions (HxWxD):
Cable Length:
Weight:
Operating Temperature:
Operating Humidity:

PIN ASSIGNMENT

■
RS-485/422 side (DB-9 Male Connector / Termination Board):
DB-9 Pin: 1
Jumper:
(default: ON)
RS-485: A+ (J2 ON)
RS-422: (J2 OFF)
TX+
Revision: A1.1 The design and specifications are subject to change without notice for improvement
USB 2.0 (backward compatible), EIA/TIA RS422/RS485 standards
From USB port
Less than 100mA
300 to 115,200bps (auto-sensing and self-adjusting)
USB side: 10ft (3m); RS-485/422 side: Depending on the power
from USB port, will transmit up to 4000ft (1.2km) at 19,200bps
USB side: Type A female; RS-422/485 side: DB-9 male;
Termination board: DB-9 female and a 6-way terminal block
128
120 (Built-in)
0.63 x 1.3 x 5.5 in (16 x 32 x 140 mm) (excluding cable)
3.3 ft (1 m)
4.3 oz (123 g)
32ºF to 95ºF (0ºC to 35ºC)
Up to 90% RH (no condensation)
2 3 4
J2 J3
(default: ON)
B- (J3 ON)
(J3 OFF)
RX+ TX- RX-
5 6 7
J1
(default: ON)
GND (J1 ON)
GND (J1 OFF)
Communications made easy
8
J4
(default: ON)
Terminate/remove Jumper J4
to turn ON/OFF the 120
end-of-line terminator
www.CommFront.com
