WALDENT W-145 Operation Manual

Introduction
Dear Dentist,
Your trust in our products is of utmost importance to us, and we are excited to introduce you to our
latest innovation, the Waldent 10:1 Contra Angle Handpiece for Hand Files (W-145). This exceptional
addition to our lineup has been meticulously crafted to elevate your dental practice.
With a gear ratio of 10:1, this handpiece o ers precise and controlled performance, making it the
perfect companion for endodontic procedures. Crafted from high-quality stainless steel and
equipped with Japanese bearings, it ensures durability and reliability that you can count on. The
push-button chuck simpli es le changes, enhancing your work ow e ciency.
TECHNICAL SPECIFICATIONS
Material: Stainless Steel
Bearing: Japanese bearing
Maximum Speed Range: Upto 4,000rpm
Gear Ratio: 10:1
Bur Compatible: Endo Hand Files
PACKAGE CONTENTS
1 x Waldent 10:1 Contra-Angle Handpiece
1 x Manual
1 x Oiling Mouthpiece
1 x Wrench
INSTALLATION
Connection and Disconnection of Units
Connection of Units
• Ensure that the connection of the handpiece is compatible with that of the micromotor.
• In order to couple it, press the handpiece on the coupling of the micromotor until it is fastened.
Disconnection of Units
• To uncouple, pull out the handpiece in parallel.
• Never place or remove the handpiece when the micromotor is functioning.
Mounting & Dismounting the Bur
Mounting the Endo Hand Files
• Press the button to insert the le into the handpiece head.
• Release the button once the le is securely in place.
Dismounting the Endo Hand Files
• Press the push button securely and then remove the le.
CAUTIONS
• Do not insert or remove the le while the handpiece is rotating.
• Do not use non-ISO standard les.
• Avoid applying excessive pressure on the le, as it may break and become di cult to remove.
• Ensure that the shank of the le is free from dirt and debris before inserting it into the handpiece
to prevent damage.
LUBRICATING THE HANDPIECE
Lubricate handpiece with Waldent Unispray Universal Handpiece Spray after each use or before
autoclaving.
10:1 Contra Angle
Handpiece
Connection: E-type
Rotation Mode: 30° Left & Right Reciprocation
Autoclavable: Upto 135 °C
Chuck Type: Push Button
Noise: ≤60dB
for Hand Files
OPERATION MANUAL
W-145
