INSTALLATION INSTRUCTIONS FOR DROPSPOT™
Sloan Valve Company ("Sloan"), warrants its products against defects in materials and workmanship, excluding damage caused by matters beyond Sloan's
reasonable control. Instructions for filing claims can be found in the Limited Warranty which can be obtained at www.sloan.com or by requesting a free copy by
telephone at 888.756.2614. Sloan will repair or replace your defective product, or provide a refund, as your exclusive remedy. This is only a general summary of
Sloan's Limited Warranty so it is important to note that the specific terms, conditions, limitations and exclusions, including the duration of warranty coverage for
your particular Sloan product, are contained in the actual Sloan Limited Warranty. The Limited Warranty is subject to applicable laws in your country, state, province
or other jurisdiction—and disputes arising under the Limited Warranty are to be resolved by binding arbitration unless you provide Sloan with an opt-out notice no
later than 30 days after your purchase date. In case of a conflict with this summary, the terms and conditions set forth in the complete Limited Warranty will prevail.
IMPORTANT INFORMATION
Some options may slightly alter installation. To ensure proper installation, review this document thoroughly and verify rough-ins before beginning any
work. File this document with the owner or maintenance personnel upon completion of installation.
Sloan products are designed in accord with applicable National Codes and Standards, which may include UPC, ANSI, and ASSE. Installers should use industry
standard practice for details not covered within this document. ANSI, UFAS or ADA compliance is subject to the interpretation and requirements of the local code
authority and is the responsibility of the installer for verification.
Prior to installation, supply lines must be flushed of all foreign material such as pipe dope, chips, or solder. Debris or foreign material in water supply
may damage valve. An appropriate thread sealant is recommended on all MPT threaded waste and supply connections to reduce the possibility of leaks. Thread
sealant NOT recommended for slipjoint or gasketed connections.
Industry standard wall backing substrate, for wall hung fixtures, is required. Installer provided wall anchors and wall anchoring hardware must be appropriate for
wall construction and be able to support three (3) times the weight of the unit.
Electrical receptacle(s) must be wired to a GFCI protected circuit. Fixture must be earth grounded per NEC (National Electrical Code). This fixture is intended to
dispense water that has been lowered in temperature, but otherwise remains unchanged by the materials in the water cooler. It is common for electrical equipment
to be grounded to water lines either within a structure or away from it. Every attempt should be made to prevent this kind of grounding from generating electrical
feedback into the water cooler creating electrolysis. Electrolysis will cause a metallic taste or cause water metal content to increase.
NOTICE: A dielectric coupling must be used to connect the water cooler to the water supply. A nonmetallic coupler is furnished with this water cooler to meet this
requirement.
ON-WALL BOTTLE FILLERS
DRS-120
Bottle Filler with Bi-Level Cooler
®
SLOAN
LIMITED WARRANTY SUMMARY
1
Code No. 68160072
Rev. 2 (09/24)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DropSpot DRS-120 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sloan DropSpot DRS-120

  • Page 1 Sloan Valve Company (“Sloan”), warrants its products against defects in materials and workmanship, excluding damage caused by matters beyond Sloan’s reasonable control. Instructions for filing claims can be found in the Limited Warranty which can be obtained at www.sloan.com or by requesting a free copy by telephone at 888.756.2614.
  • Page 2: Prior To Installation

    • Fixture operates within water pressure range of 20 psi (138 kPa) to 105 be present. psi (724 kPa). Sloan will not warranty product damaged when connected • Water supply service stop valve, water connections and electrical to supply lines with flow pressure lower than 20 psi (138 kPa) or higher connections (not provided) must be in accordance with local codes.
  • Page 3 ROUGH-IN Prior to roughing in, consult local, state, and federal codes for proper mounting height. STANDARD CONFIGURATION – Left Unit High, Right Unit Low For alternate configurations, visit sloan.com. FINISHED WALL 19-1/8” 18-15/16” (486 mm) (481 mm) 4” (102 mm) 6-3/8”...
  • Page 4: Electrical Requirements And Connections

    WASTE CONFIGURATION STANDARD WASTE CONFIGURATION ALTERNATE WASTE CONFIGURATION FILLER PLATE FILLER PLATE TUBING AND WATERPATH INLET OUTLET SOLENOID BOTTLE FILLER SHUT-OFF SPOUT VALVE, WATER TO BUILDING ACTIVATED WATER SUPPLY PRIMARY BUBBLER SECONDARY BUBBLER WATER FILTER LOCATION IF USED PUSH VALVE PUSH VALVE EVAPORATOR...
  • Page 5: Installation Preparation

    DISCONNECTING THE TUBE To disconnect the tube from the fitting, ensure that the water line is depressurized. Use the Sloan Universal Maintenance Tool to push collet square/evenly towards the push-in fitting body and hold. While holding the collet in, pull on the tubing to remove from the push-in fitting.
  • Page 6 2 – INSTALL COOLERS Anchor the units to the wall at the lower mounting points in each back Choose configuration. panel. Shim lower mounting points between the wall and mounting For alternate mounting configuration, remove and reinstall filler plate plates to level units if necessary. and reverse drain assembly.
  • Page 7 3 – INSTALL BOTTLE FILLER Remove bottle filler assembly and power supply from packaging. Be Push free end of tubing from the bottle filler mounting plate down careful to avoid damage to unit and subassemblies. Set power supply through the grommet. aside in a secure location.
  • Page 8 UNTIL STEP 4D. If needed, refer to the Adjustments & Settings section in the Repair Parts & Maintenance Guide for instructions: sloan.com/commercial- With bottom cover removed, and water supply thoroughly flushed of bathroom-products/bottle-fillers/dropspot/drs120 debris and air, turn on fixture water supply and check all connections for leaks.
  • Page 9: Troubleshooting Guide

    If any strainer components are damaged, replace as necessary. Reinstall strainer on strainer housing. Install When assistance is required, please contact Sloan strainer housing, gasket, water line fitting, and cap onto solenoid valve Technical Support at 1.888.SLOAN.14 or 1.888.756.2614.
  • Page 10: Preventative Maintenance

    Use only a mixture of clean water and a mild detergent to clean unit weekly or more often as needed. For best results, always rinse well with fresh water and wipe completely dry with a clean soft cloth. DO NOT USE harsh chemicals, abrasive, or petroleum based cleaners. Use of these will void the Sloan warranty. To remove stubborn water marks or minor scratches, apply a stainless steel cleaner/polish to a synthetic abrasive pad and carefully rub the panel with the grain.
  • Page 11 PARTS LIST — COOLERS Item Item Code No. Part No. Description Code No. Part No. Description 33830015 BFS-1 Universal Maintenance Tool — — #8 x 3/8” Hex Washer Head Screw, Zinc, Slotted (Qty 30) 33830035 BFS-18 Drinking Fountain Basin Assembly (Qty 2) 33830002 FA3000- Optional PFAS Water Filter Upgrade Kit...
  • Page 12 The information contained in this document is subject to change without notice. SLOAN • 10500 SEYMOUR AVENUE • FRANKLIN PARK, IL 60131 Phone: +1.800.9.VALVE.9 or +1.800.982.5839 • Fax: +1.800.447.8329 • www.sloan.com Copyright © 2024 SLOAN VALVE COMPANY...
