Function Code; Parameter Description - CHINT NVF2G Series User Manual

Name

Function code

Phase 1 Setup
FA.01
FA.02
Phase 1 run time
FA.03 Phase 2 Setup
FA.04
Phase 2 run time
Phase 3 Setup
FA.05
FA.06
Phase 3 run time
FA.07 Phase 4 Setup
FA.08
Phase 4 run time
FA.09 Stage 5 Setup
FA.10 Phase 5 run time
FA.11 Stage 6 Setup
FA.12 Phase 6 run time
Stage 7 Setup
FA.13
FA.14 Phase 7 run time
Stage 8 Setup
FA.15
FA.16 Phase 8 run time
Stage 9 Setup
FA.17
FA.18
Phase 9 run time
FA.19 Stage 10 Setup
Stage 10 run time
FA.20
Stage 11 Setup
FA.21
FA.22
Phase 11 run time
Stage 12 Setup
FA.23
FA.24 Phase 12 run time
Stage 13 Setup
FA.25
FA.26 Phase 13 run time
Stage 14 Setup
FA.27
FA.28 Phase 14 run time
Phase 1 5 Setup
FA.29
Stage 15 run time
FA.30
Figure 8-2-2 Schematic diagram of simple PLC as main frequency
the simple PLC function of the inverter includes 3 types: stop after a single cycle, maintain the final value
after a single cycle, and continuous cycle . Show:
● Shutdown after a single loop:
NVF2G Series Inverter User's Guide
Default value Predetermined area
0x0000 0x0000 ~ 0x0315
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0
0x0000
Same as FA.01
0.0 0.0～6500.0

Parameter Description

Units: frequency source
0: multi-band frequency N
1-5: Reserved
Tens place: running direction
0: Forward rotation
1: reverse
Hundreds place: Acceleration and
deceleration time
0: Acceleration and deceleration time 1
1: Acceleration and deceleration time 2
2: Acceleration and deceleration time 3
3: Acceleration and deceleration time 4
