MALÅ GeoDrone 600
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GeoDrone 600 and is the answer not in the manual?

Questions and answers

Related Manuals for MALA GeoDrone 600

Summary of Contents for MALA GeoDrone 600

  • Page 1 MALÅ GeoDrone 600 User Guide...
  • Page 2 Our Thanks... Thank you for choosing Guideline Geo and MALÅ as your Ground Penetrating Radar solution provider. The very core of our corporate philosophy is to provide our users with the very best products, support and services. Our development team is committed to providing you with the most technologically advanced and easy-to-use GPR products with the capability to meet your needs for efficiency and productivity now, and into the future.
  • Page 3 Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Guideline Geo. Your rights to the software are governed by the accompanying software license agreement. The MALÅ logo is a trademark of Guideline Geo registered in Sweden and other countries.

  • Page 4: Table Of Contents

    Preface ..................5 Safety and Compliance User Notices ..........6 Unpack. Inspect. Register .............. 8 MALÅ GeoDrone 600 ..............9 The MALÅ GeoDrone 600 unit ..............10 Safety wire....................11 Positioning ....................11 Power ......................12 System set up................13 Data acquisition ................

  • Page 5: Preface

    Preface About this Manual This manual is written for the end user of the product and explains how to set up and configure the product, as well as providing detailed instructions on its use. Additional Resources GPR Training https://www.guidelinegeo.com/training-gpr-resistivity-seismics-tem/ GPR Method https://www.guidelinegeo.com/ground-penetrating-radar-gpr/ GPR Applications https://www.guidelinegeo.com/application-areas/...

  • Page 6: Safety And Compliance User Notices

    Safety and Compliance User Notices This GPR-device is certified according to FCC, subpart 15, IC RSS-220 and ETSI EN 302 066- 1&2. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 7: Radiation Exposure Statement

    Cet instrument de Géoradar se devra d’être utilisé seulement par les agences chargées de l’application de la loi, les instituts de recherches scientifiques, les compagnies minières à buts lucratifs, les compagnies de construction et les organisations responsables pour le sauvetage et la lutte contre les incendies.

  • Page 8: Unpack. Inspect. Register

    Guideline Geo within fourteen (14) business days from the receipt of the equipment. Repacking and Shipping The Guideline Geo packing kit is specially designed for shipping the MALÅ GeoDrone 600 unit. The packing kit should be used whenever shipping is necessary. If the original packing kit is unavailable, pack the instrument in a box that is large enough to allow at least 80 mm of shock absorbing material to be placed all around the instrument.

  • Page 9: Malå Geodrone 600

    The MALÅ GeoDrone 600 is intended for use either in close proximity to and always within 1 meter of the ground (subject to ETSI and FCC/IC regulations).

  • Page 10: The Malå Geodrone 600 Unit

    The MALÅ GeoDrone 600 unit The MALÅ GeoDrone 600 is a one-piece GPR unit containing the transmitter (Tx) and receiver (Rx) antennas, as well as a control unit and power. On the MALÅ GeoDrone 600 unit the following items are found: •...

  • Page 11: Safety Wire

    The MALÅ GeoDrone 600 supports PPS (Pulse Per Second) for post-survey position synchronization with an external RTK-GNSS device. Connection for external GNSS antenna is found on the side of the GeoDrone 600 unit. The connection is marked GNSS.

  • Page 12: Power

    Power The MALÅ GeoDrone 600 is powered by a single battery. This is found under the hatch on the main unit (bottom side). A fully charged battery gives a measurement time of 1+ hours (depending on settings).

  • Page 13: System Set Up

    Make sure to attach the safety wire to a secure mounting point on the drone. To prevent damage to the equipment, make sure the MALÅ GeoDrone 600 is securely attached prior to flight and do not use the GeoDrone 600 as landing gear. A complimentary payload mounting kit is available for easy attachment to common drone models.

  • Page 14: Data Acquisition

    If collecting data in one single long file, make the turns outside the investigation area, to avoid artefacts in the data used for interpretation. • Slowing and speeding up of the drone will most likely make the antenna unlevelled/tilting. The GeoDrone 600 can be mounted a bit tilting to avoid some of these effects.

  • Page 15: Flight Direction

    Set the flight direction according to the arrows for these types of investigations. Restoring missing traces During remote operation (when the GeoDrone 600 antenna is out of Wi-Fi reach of the tablet), or if the Wi-Fi is disrupted when working locally, the in-built memory card in the GeoDrone 600 unit will store the GPR data and thus enabling the measurement to continue.
