Quick Guide
MALÅ GeoDrone 80
Assembly and Connections
1) Make sure batteries are fully
charged. One battery at time can be
changed even if the unit is on.
2) Assemble and connect the two
antenna tubes to the main unit.
3) For better reception, use the GPS
antenna extension cable (included).
4) Attach the MALÅ GeoDrone 80 to
the drone. Make sure this is firmly
made, so you do not drop the
GeoDrone 80 during flight.
Note: Land the drone smooth and care-
fully so you do not harm the equipment.
5) Ready to power up the MALÅ
GeoDrone 80 and the Controller!
The batteries are found under the hatch
The two antenna tubes assembled and connected to the radar unit.
Connections for external GPS antenna and data cable together
with Power On/Off on the main unit
