ICEBERG FRITS Quick Start Manual

LEVEL B SELECTION
RATE
DEPTH
FDB/LAG
Preset B Enable Footswitch
(hold for momentary)
Enable Left Channel *
RATE - Controls the speed of the modulation
DEPTH - Controls the depth of the modulation
LEVEL B - Sets the level of either RATE, DEPTH or
FDB/ when preset B is enabled (blue LED on).
LAG
What Level B controls depends on the setting of the
LEVEL B SELECTION toggle switch. Set Level B
higher than the RATE, DEPTH or FDB/LAG knob
FRITS
Manual version 1.1
9V center negative
Left Audio Right Audio
Output Output
External Level B Enable
* When used in Channel Direct Select Mode
Stereo Time
Modulator
125 mA
Left Audio Right Audio
Input Input (Mono)
External Bypass Port
MIX - Sets the the mix of the dry signal and the
modulated signal. All the way to the left is only dry
signal, all the way to the right only modulated signal.
FDB/ - Controls the amount of FEEDBACK when
LAG
the mode is set to Flanger or Delay/Reverb. Controls
the amount of
LAG
to horus/ ibrato
C V
ICEBERG
EFFECTS
MODE
Flanger
Chorus/Vibrato
Delay/Reverb
Modulation Shape
Bypass Footswitch
(hold for momentary)
Enable Right Channel *
(=delay time) when the mode is set
