D Line DTBF200-DL Instruction Manual

Flat to Wall
TV Mount
DTBF200-DL
Features:
• Ultra-low-profile picture frame appearance for a clean modern look
• Mounts the TV just 15mm (0.6") away from the wall to save space in your room
• Slide on installation makes mounting the TV simpler and faster
• Shaped metal plate for extra strength to reliably support your screen
• Can be used to keep a TV or monitor away from children and pets
• Confidently mount your screen with a high 25kg maximum weight limit
• Suits 23" - 50" TVs, compatible with 75x75 - 200x200 VESA sizes
• Includes fixings for solid walls, stud walls and the TV, for convenience
• High quality steel construction with independent testing by SGS
• Reassurance of a 5 year warranty as standard
Packaging Information
Part Number Description
Flat-to-Wall
DTBF200-DL TV wall mount bracket,
23 - 50"
Weights & Dimensions
Product
Extended Folded
23.0 x 23.0 x 1.5 cm n/a
9.06" x 9.06" x 0.59" n/a
DTBF200-DL.Q1.2024
Product Packaging
Type Barcode
Colour retail box 5056335606429
Product Box
Net
Dimensions
Weight
0.53kg 24.5 x 24.5 x 3.2 cm
1.17lbs 9.65" x 9.65" x 1.26"
Specification Sheet
50"
VESA
200x200
23-
Max VESA
58-127cm
Screen Size
Compatible VESA Sizes
Type
Brown outer
with label
Gross
Cubic Dimensions
Weight
0.67kg 0.0019m3 26.5 x 26.5 x 34.0cm
1.48lbs 0.0678ft3 10.43" x 10.43" x 13.39"
VESA
25kg
15mm
Max Weight
Distance from
Size Capacity the wall
All dimensions are in mm
VESA
75x75
100x100
200x100
200x200
Outer Packaging
Qty in box Barcode
10 15056335606426
Outer Box
Gross
Cubic
Weight
8kg 0.0239m3
17.6lbs 0.8432ft3
www.d-line.com
