Eastern Times Technology MX01 User Manual

Product Description ............................................................................................................ 1
Settings................................................................................................................................ 1
Join A Network ................................................................................................................... 2
P D
RODUCT ESCRIPTION
The MX01 is a low power sensor for use in retail monitoring applications. MX01 leverages the industry
standard wireless IEEE 802.15.4 to seamlessly integrate with other retail solutions. By using industry
standards and a modular sensor scheme, MX01 enables a wide range of sensing applications and network
capabilities. With MX01, real time knowledge of the retail environment becomes possible.
Figure 1a: MX01 Assembly.
S
ETTINGS
Properly assembled, the MX01 will monitor the ground loop antenna; connect to the modem or Ethernet
board, battery or wall power supply, and the radio which can be seen in figure 1a and figure 1b. The
locations of the DIP switches and the RESET, JOIN, and SW B buttons are also shown in figure 1b. Select
the appropriate DIP settings for desired functionality using the following table:
MX01 USER MANUAL
Table of Contents
Figure 1b: Assembled MX01 Board.
DIP
Switch,
SW4
Reset, Join,
SW B
Buttons
