  • Page 1 VILSTA...
  • Page 2 ENGLISH For the IKEA appointed Authorized Service Centre, please refer to www.IKEA.com and select your local store for phone numbers and opening times.
  • Page 3 TW ENGLISH LANGUAGE COUNTRY...

  • Page 4: Table Of Contents

    Technical data Electrical connection Energy saving Product description Environmental concerns Daily use IKEA GUARANTEE Cooking table Cookware guidance Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage.

  • Page 5: General Safety

    ENGLISH Children shall not carry out cleaning and user maintenance • of the appliance without supervision. General Safety This appliance is for cooking purposes only. • This appliance is designed for single household domestic • use in an indoor environment. This appliance may be used in offices, hotel guest rooms, •...

  • Page 6: Safety Instructions

    ENGLISH If the glass ceramic surface / glass surface is cracked, switch • off the appliance and unplug it from the mains. In case the appliance is connected to the mains directly using junction box, remove the fuse to disconnect the appliance from power supply.
  • Page 7 ENGLISH • Make sure that the parameters on the rating plate are compatible with the Warning! Risk of injury, burns electrical ratings of the mains power and electric shock. supply. • Make sure the appliance is installed • Do not change the specification of this correctly.

  • Page 8: Installation

    ENGLISH • Do not put flammable products or items pads, solvents or metal objects, unless that are wet with flammable products in, otherwise specified. near or on the appliance. Service Warning! Risk of damage to the appliance. • To repair the appliance contact the Authorised Service Centre.

  • Page 9: General Information

    ENGLISH General information min. 520 mm 590 mm 500 mm 560 ±1 490 ±1 min. min. 28 mm min. 100 mm 55 mm min. 5 mm max. R 5 mm min. 28 mm • If there is no oven beneath the hob, Installation process must follow install a separation panel under the the laws, ordinances, directives...

  • Page 10: Connection Diagram

    ENGLISH cable 4x1.5 mm². Please respect specific • Secure the connecting cable with cable national regulations in the first priority. clips or clamps. • You must have the means for • The appliance works either at 50 Hz or 60 disconnection incorporated in the fixed Hz and does not require any additional wiring.

  • Page 11: Product Description

    ENGLISH Product description Cooking surface layout Single cooking zone (180 mm) 1700 W, with Plus Power 1800 W Single cooking zone (145 mm) 1400 W, with Plus Power 1500 W Control panel Single cooking zone (210 mm) 2200 W, with Plus Power 2400 W Single cooking zone (145 mm) 1400 W, with Plus Power 1500 W Control panel layout...

  • Page 12: Daily Use

    ENGLISH Power setting displays Display Description The cooking zone is deactivated. The cooking zone operates. Plus Power operates. There is a malfunction. Refer to "Troubleshooting". + digit A cooking zone is still hot (residual heat). Lock / Child Lock / Cleaning mode operates. Incorrect or too small cookware or no cookware on the cooking zone.

  • Page 13: Adjusting The Power Setting

    ENGLISH Use the function to clean the Power setting Automatic switch off surface of the hob during the after cooking session, if needed. 6 hours First set the power setting. 5 hours To start the function touch . The symbol comes on for 4 seconds.

  • Page 14: Power Exchange Function

    ENGLISH 1. Switch off the appliance. the hob. Each phase has a maximum electricity loading. If the hob reaches the 2. Touch for 3 seconds. The display limit of maximum available power within comes on and goes out. one phase, the power of the cooking 3.

  • Page 15: Cookware Guidance

    ENGLISH Heat setting Use to: Time Hints (min) 1 - 2 Solidify: fluffy omelettes, baked 10 - 40 Cook with a lid on. eggs. 2 - 3 Simmer rice and milk-based 25 - 50 Add at least twice as much liq‐ dishes, heat up ready-cooked uid as rice, mix milk dishes meals.
  • Page 16 ENGLISH To ensure optimum efficiency, always use causes considerable disturbance, it might pots and pans with a flat bottom that help to change the cookware. distributes the heat evenly. If the bottom is Normal operating noises of the induction uneven, this will affect power and heat conduction.

  • Page 17: Care And Cleaning

    ENGLISH • Rhythmic sounds, similar to the ticking noises described are a normal element of sound of a clock: this noise occurs only the described induction technology and when at least three cooking zones are should not be regarded as defects. operating and disappears or weakens when some of them are switched off.
  • Page 18 ENGLISH Problem Possible cause Remedy The fuse is blown. Make sure that the fuse is the cause of the malfunction. If the fuse is blown again and again, contact an authorised installer. You did not set the power Switch on the hob again and setting in less than 10 sec‐...

  • Page 19: Technical Data

    IKEA store or the After Sales Service. You can installer, the visit from the After find a full list of IKEA appointed contacts at Sales Service technician or dealer the end of this user manual.

  • Page 20: Environmental Concerns

    ENGLISH • Put the cookware directly in the centre of • Use the residual heat to keep the food the cooking zone. warm or to melt it. Environmental concerns appliances marked with the symbol with Recycle materials with the symbol .
  • Page 21 ENGLISH...

  • Page 22: Ikea Guarantee

    Replaced parts become the property of IKEA. original parts have been used. What will IKEA do to correct the problem? • Repairs caused by installation which is faulty or not according to specification. IKEA appointed Service Provider will examine •...
  • Page 23 • ask for clarifications on installation of the IKEA appliance in the dedicated IKEA kitchen furniture; • ask for clarification on functions of IKEA appliances. To ensure that we provide you with the best assistance, please read carefully the Assembly Instructions and/or the User Manual before contacting us.
  • Page 24 21552 © Inter IKEA Systems B.V. 2024 AA-2487486-1...

This manual is also suitable for:

405.577.23
