- Page 1 GREYSTONE ® INSTRUCTION MANUAL Gas Range Models: CF-RV17/CF-RV17B/ CF-RV17BB CF-RV21/CF-RV21B/ CF-RV21BB CCD-0007530 Rev. 01.06.23...
-
Page 2: Table Of Contents
Table of Contents Getting Started ................. 3 Safety Precautions ................4 Safety Instructions ................5 Installation ..................10 Operation ..................15 Range Features ................21 Troubleshooting ................22 Cleaning and Maintenance ............. 23 Exploded-View Drawing..............24 Warranty ..................26 Contact Information ............... 28 P a g e CCD-0007530 Rev. -
Page 3: Getting Started
Getting Started We appreciate your purchase of the GREYSTONE Gas Range for RVs. Prior to operating your new appliance, please read this manual carefully. This instruction manual contains information for safe use, installation and maintenance of the appliance. You will want to keep this manual handy for future reference. -
Page 4: Safety Precautions
Safety Precautions WARNING Warning: If the instructions in this manual are not followed exactly, a fire or explosion may result causing property damage, personal injury or death. Do not store or use gasoline or other flammable vapors or liquids near this or any appliance. WHAT TO DO IF YOU SMELL GAS: •... -
Page 5: Safety Instructions
Caution Caution: Hazards or unsafe practices COULD result in minor personal injury Read the follow all instructions before using this application to prevent the potential risk of fire, electric shock, personal injury or damage to the appliance as a result of improper usage of the appliance. - Page 6 • Your appliance should be installed by a qualified technician in accordance with state and locals laws. • Never modify or alter the construction of a range by removing leveling legs, panels, anti-tip brackets/screws, or any other pant of product. Do not use the oven or warmer drawer (if equipped) for storage.
- Page 7 During and after use, do not touch or let clothing or other flammable items touch these areas until they have sufficient time to cool down. Both surface burners and oven burners and oven vent (if equipped) may be hot even though flames are not visible and may be hot enough to cause burns.
- Page 8 If you will be storing the range or throwing it away, remove the oven door beforehand. IMPORTANT: Do not attempt to operate the appliance during a power failure. If the power fails, always turn off the oven because the oven may begin to operate again when power resumes, even if nobody is present.
-
Page 9: Important Instructions For Using Your Oven
• Protective liners: Do not use aluminum foil to line surface burner pans or oven bottom, except as suggested in this manual. Improper installation of these liners may result in risk of electric shock or fire. • Do not use searing grill on the cooktop. Searing grills are not designed for use on the cooktop. -
Page 10: Cleaning Instructions
Recreational Vehicles (AN51/NFPA 1192). WARNING Installation of this appliance must adhere to the written instructions in this manual. No agent, representative or employee of the manufacturer of GREYSTONE appliances or 10 | P a g e CCD-0007530 Rev. 01.06.23... -
Page 11: Cabinet Cutout Instructions
other person has the authority to change, modify or waive any provision of the instructions this manual. Cabinet Cutout Instructions To ensure proper operation of your range, suitable cabinets must be used, and cabinets must be leveled, with the bottom of the range supported. -
Page 12: Oven Installation
Cabinet and counter cutout: Model 17” RV 173/4” 201/4” 161/8” 15/16” 19/16” 2" min Range 451mm 514mm 410mm 23mm 40mm 51mm max. max. min. 201/16” 15/16” 21" RV 173/4” 201/4” 19/16” 2" min Range 451mm 514mm 510mm 23mm 40mm 51mm max. - Page 13 2. Push back the top glass cover assembly a little and lift up to remove it from the range oven. (Fig. 2) 3. Slide the range oven into the cabinet opening. Verify the oven is level from side to side and front to rear. (Fig. 3) Connect a copper gas supply line with a shut-off valve and 5/8-18UNF connection to the range oven through gas cavity on the upper Left-rear corner of the cabinet.
- Page 14 5. Use four tapping screws on both left and right to secure the range oven (Fig. 5) 6 & 7. Check the pipe fittings for leaks using a soapy solution. Never use a flame. Push to insert the top glass cover assembly into the metal dip and place it into the range oven, then pull front a little to lock into place.
-
Page 15: Operation
Electrical Connection Model with LED light: Connect the light wires to a 12V DC circuit with a fuse protected and a max rating of no more than 15 amps. Wiring Diagram Wiring Diagram Operation Lighting Oven Match Lighting: 1. Before lighting, check to make sure all the control knobs are turned to OFF position. - Page 16 5. Continue to push and hold in the oven control knob, then open the oven door and insert a lit, long wooden match or a butane lighter with extension) through the spaces in the grate near the ports of the burner to light the oven burner. (Fig. 15) 6.
-
Page 17: Lighting Top Burners
1. Before lighting, check to make sure all the control knobs are turned to OFF position. 2. Make sure the main gas tank valve is open. 3. Push and turn the oven control knob counterclockwise to LIGHT position. (Fig. 14) 4. - Page 18 4. IMMEDIATELY strike and place a lit, long wooden match or a butane Lighter with extension) through the spaces in the grate near the ports of the burner to light the burner. Repeat steps 3 & 4 to light all burners (Fig. 10) Push and turn the burner control knob to adjust the flame level.
- Page 19 To Turn Off: To extinguish the oven or top burner flame, push and turn the oven control knob clockwise to OFF position. Always turn off the gas tank valve when refueling or traveling. 19 | P a g e CCD-0007530 Rev. 01.06.23...
- Page 20 The Burner Flame: Keep your arms and face away from above the cooking area. Flames should appear similar to the good flame shown in diagram below. A good flame should be blue with a yellow tip. Some yellow tips on flames up to 1 inch in length are acceptable as long as no carbon or soot deposits appear.
- Page 21 4. To stop the leak, tighten the loose joint, or replace the faulty part with a replacement part recommended by dealer. WARNING PRODUCT DAMAGE HAZARD DO NOT cook with the control knob set in the LIGHT position. Damage to the ignition module and burner electrodes may result. DO NOT use oversized cookware.
-
Page 22: Range Features
Range Features This appliance conforms to the directive: ANSI Z21.57a- (2012) Rec/ CAN1- 1.16-M791R2011 22 | P a g e CCD-0007530 Rev. 01.06.23... -
Page 23: Troubleshooting
Troubleshooting PROBLEM/SYMPTOM POSSIBLE CAUSE/SOLUTION Surface burners do not Surface control knob has not been light or do not burn fully rotated to the LIGHT position. evenly Check to see if gas valve is open. If not, open it. Burners are clogged. Make sure burner is off. -
Page 24: Cleaning And Maintenance
Cleaning and Maintenance • Make sure all controls are OFF and the range or cooktop is cool before cleaning. • DO NOT use oven cleaners, bleach, steel wool or rust removers on the cooktop or burner grates. Only use nonabrasive pads. •... -
Page 25: Exploded-View Drawing
Exploded-view Drawing 25 | P a g e CCD-0007530 Rev. 01.06.23... - Page 26 26 | P a g e CCD-0007530 Rev. 01.06.23...
-
Page 27: Warranty
Warranty Your GREYSTONE appliance is covered by a one-year limited warranty. For one year from your original date of purchase of the original purchaser, GREYSTONE will pay costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, using and maintained in accordance with the provided instructions. - Page 28 GREYSTONE shall not be liable for consequential or incidental damages such as property damage and incidental expenses resulting from any breach of this written limited warranty or any implied warranties, so these limitations or exclusions may not apply to you.
- Page 29 The contents of this manual are proprietary and copyright protected by Lippert. Lippert prohibits the copying or dissemination of portions of this manual unless prior written consent for an authorized Lippert representation has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert.
