Contents
Important User Information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Safety Precautions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
Required Tools� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Supplied Hardware � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
Parts List � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Visit the Nota Chairs web page at wengercorp.com for more information.
Note: Please read and understand these instructions before proceeding�
Note: If you need additional information, contact Wenger Corporation using the information below�
©Wenger Corporation 2024
Wenger Corporation, 555 Park Drive, P�O� Box 448, Owatonna, Minnesota 55060-0448
Questions? Call�����USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp�com
Sousaphone Holder Accessory
Assembly � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
Adjustment� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
Adjustment Notes � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
Routine Maintenance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
Printed in USA 2024-10
Assembly Instructions
for Nota
Sousaphone Holder
Accessory
on a Nota Standard Chair
Chairs
®
Part #190A185-02
Advertisement
Table of Contents
Related Manuals for Wenger Sousaphone Holder Accessory
Summary of Contents for Wenger Sousaphone Holder Accessory
-
Page 1: Table Of Contents
Visit the Nota Chairs web page at wengercorp.com for more information. Note: Please read and understand these instructions before proceeding� Note: If you need additional information, contact Wenger Corporation using the information below� ©Wenger Corporation 2024 Printed in USA 2024-10 Part #190A185-02 Wenger Corporation, 555 Park Drive, P�O�... -
Page 2: Important User Information
Wenger Corporation� Wenger Corporation does not assume any responsibility for any errors that may appear in these instructions� In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of these instructions�... -
Page 3: Required Tools
Required Tools • Electric drill with 1/2" socket or 1/2" socket wrench • In-Lb torque wrench is recommended Supplied Hardware 5/16-18 x 1-1/4" 5/16" ID 5/16 x 3/4" Hex Head Capscrew Flat Washer Hex Head Self Tapping Screw... -
Page 4: Parts List
Parts List Item Qty Description Item Qty Description Base Assembly Adapter Bracket Lower Support Arm 5/16 x 3/4" Hex Head Self-tapping Screw Lower Handle and Bracket Assembly 5/16-18 x 1-1/4" Hex Head Capscrew Upper Support Arm 5/16" ID Flat Washer Upper Handle and Bracket Assembly... -
Page 5: Assembly
Assembly 1. Place the Nota chair upside down on a table, bench, or floor surface covered with a pad or blanket to protect the seat and back surfaces� Bottom View of 2� Pre-cut the adapter bracket mounting hole threads in the Adapter Bracket pre-punched holes of the chair frame using the 5/16 x 3/4"... - Page 6 Assembly (continued) 5� Place the Nota chair upright� Upper Handle and 6� Slide the upper handle and bracket assembly over the Bracket Assembly straight side of the frame� 7� Slide both of the lower handle and bracket assemblies over the bent side of the frame� Align the holes in each lower handle and bracket assembly with the holes in the frame�...
-
Page 7: Adjustment
Adjustment NOTICE Two people are required to properly adjust the sousaphone holder. 1� As a starting point: a� Position the upper handle and bracket assembly about 2" (51 mm) from the end of the frame� b� Position both lower support arms so they extend about 2" (51 mm) below the lower handle and bracket assemblies�... -
Page 8: Adjustment Notes
Adjustment Notes • When the holder is adjusted properly, the sousaphone will assume a natural balanced position� • When you look at the sousaphone from the back, the large tapered tube (bell bow) just below the bell should be vertical� The upper instrument support on the holder should be positioned against the bell bow� •...
