- Page 1 ELECTRONIC HANDLE WITH ACCESS CONTROL ELH-02H4 CARD Operating Manual...
-
Page 2: Table Of Contents
CONTENTS 1. GENERAL CHARACTERISTICS AND INTENDED USE ................ 4 2. SET CONTENTS ............................ 4 3. STRUCTURE ............................5 4. PRINCIPLE OF OPERATION .........................5 5. FITTING THE ELECTRONIC DOOR HANDLE IN A DOOR ..............6 5.1. HANDLE ORIENTATION SETTING (LEFT/RIGHT-SIDED DOOR) ..........7 5.1.1. - Page 3 INITIAL NOTES Please read these operating instructions carefully before installing, connecting and using the unit. In the case of any problems with understanding the content of this document, please contact the device seller. Installation and start-up of the device by the user are possible if adequate tools are used. Ne- vertheless, it is recommended to have the device installed by qualified personnel.
-
Page 4: General Characteristics And Intended Use
1. GENERAL CHARACTERISTICS AND INTENDED USE An electronic door handle with access control restricts access to secured rooms for unautho- rized individuals in a straightforward manner. It is designed for both left and right doors, and the universal screw hole spacing of 40-45mm allows for the use of an existing embedded lock in most cases. -
Page 5: Structure
3. STRUCTURE Inner side External side Touch-sensitive keypad Battery CARD with key fob reader compartment cover Electronic lock Fingerprint reader Fig. 2. Structure CARD 140 mm 47 mm 24 mm 73 mm 158 mm 73 mm Fig. 3. Dimensions 4. PRINCIPLE OF OPERATION After receiving a signal from the electronic access control module, the servo motor unlocks the mechanical transmission, allowing the door to be opened by simply pressing the handle on the outside. -
Page 6: Fitting The Electronic Door Handle In A Door
5. FITTING THE ELECTRONIC DOOR HANDLE IN A DOOR The kit includes pins, bushings, and screws that enable the installation of handles on doors with a thickness of 35~65 mm. During installation, it is necessary to select the appropriate length of the included components. Caution! For increased security, it is recommended to install electronic access control handles in mor- tise doors. -
Page 7: Handle Orientation Setting (Left/Right-Sided Door)
Caution! It is recommended to install the handle using a lock with a distance of 90 mm or 92 mm. In the case of installing the handle in a lock with a distance of 72 mm, it is possible to cover part of the opening dedicated to the patented lock insert by using the appropriate mounting washer. -
Page 8: Orientation Setting - Handle Front
5.1.1. ORIENTATION SETTING - HANDLE FRONT To determine the direction of opening for a handle with built-in access control, follow these steps: - Unscrew the 4 screws from the base of the plate holding the cover (fig. 6) - Remove the cover (fig. 6 position 1-A) - Unscrew the locking screw (fig. -
Page 9: Battery Installation
PREPARATION OF A REPLACEMENT PIN If you wish to use a different pin than the one included in the kit, you should: obtain a pin with dimensions of 8 x 8 mm, then measure the appropriate length and cut the pin. -
Page 10: Installation Diagram
5.4. INSTALLATION DIAGRAM In order to install the electronic handle in the door: Use existing holes or prepare mounting holes accor- ding to the template included in the set. To make the mounting holes, remove the lock from the door, make sure it complies with the standard indicated in Fig. - Page 11 j. connect the wires that connect both sides of the handle. k. remove the cover of the battery compartment, then attach the rear body to the mounting base. Fig. 13 l. insert 4 AA alkaline batteries into the power com- partment with a voltage of 1.5V, m.
-
Page 12: Emergency Entry
5.5 EMERGENCY ENTRY Micro USB port - Emergency power supply of the door plate Patented emergency exit insert Fig. 16. In case of need to enter the premises using the emergency key, insert the emergency key into the insert located at the bottom of the device from the access control side and turn the key to the right until a noticeable resistance is felt. -
Page 13: Handle Reset
8. PROGRAMMING AND OPERATION OF THE ELECTRONIC HANDLE WITH ACCESS CONTROL To program the ELH-02H4 electronic handle with access control, download the TTLock or TTHotel applications from GooglePlay for Android system devices or from AppStore for iOS system devices. -
Page 14: Technical Specification
9. TECHNICAL SPECIFICATION PARAMETR Supply voltage 6 V DC Power supply type Alkaline batteries (4 x AA 1.5 V) Current consumption - standby mode / <18 uA / 200 mA operation Max. number of users Cards - 200, fingerprint - 200, PIN codes - 200, E-Key - no limit Intended use in doors left-/right-sided Housing material... -
Page 15: Warranty
WARRANTY As the only distributor of the Eura products, Eura-Tech is obliged to ensure efficient war- ranty and post-warranty service. In the countries where Eura-Tech has neither its own service network, nor DOOR-TO-DOOR service, the quality claims are dealt with by autho- rised distributors of the Eura products on the basis of the signed distribution agreements. - Page 16 Reproduction, dissemination and publication of the entire manual or parts thereof is prohibited without the permission of the author! Eura-Tech Sp. z o.o. reserves the right to change technical parameters and modify the operating manual without notice. It would also like to inform that the most recent version of the operating manual is available on the www.eura-tech.eu website,...
