ACCESS CONTROL
AC-30C7
User manual
and guarantee card

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC-30C7 and is the answer not in the manual?

Questions and answers

Related Manuals for EURA AC-30C7

Summary of Contents for EURA AC-30C7

  • Page 1 ACCESS CONTROL AC-30C7 User manual and guarantee card...

  • Page 2: Table Of Contents

    Table of conTenTs 1. Device characteristics ........................4 2. set content ............................4 3. Device construction ........................4 4. Device installation anD connection Diagram..............5 5. Device operation ..........................7 5.1. entrance ............................7 5.2. Door inDicator .......................... 7 5.3. aDDitional functions ......................8 5.3.1.
  • Page 3 InITIal remarks Before assembling, wiring and setting up of device the user should carefully read given manual. In case of any troubles with understanding the content the user should contact the producer. Unassisted assembling and start of the device can be done only with the use of proper tools. However, it is highly advised to set up a device by qualified personnel.

  • Page 4: Device Characteristics

    1. DevIce characTerIsTIcs Access control AC-30C7 is used in security system. The device is equipped with two relay outputs than can be used to release the lock. All functionas are programmed with a use of numerical mechanical keypad. After programming of device there is a possibility to activate...

  • Page 5: Device Installation And Connection Diagram

    (NO/COM joints) or reversed locks (NC/COM). 4. DevIce InsTallaTIon anD connecTIon DIagram AC-30C7 should be surface mounted. Before installation, position the location where the controller unit is to be mounted, then go through the following steps: 1.
  • Page 6 15. Shielding line Shield ground Fig. 4. Wiring diagram of AC-30C7 5. Use the screws provided to mount the back case on the wall, be sure to draw the wiring through the large canter hole in back case, and keep it level.

  • Page 7: Device Operation

    NOTES All additional components shown on wiring diagram (lock, door bell, button) are not in- cluded in the set. Diode D1 should be connected only when lock is DC power supplied. All wires that are not used during installation should be isolated. 5.

  • Page 8: Additional Functions

    5.3. aDDITIonal funcTIons 5.3.1. egress buTTon It is possible to connect additional egress button to both zones 1 and 2. The details are given on the wiring diagram (fig. 4). 5.3.2. Door magneT The device can detect the closed door – after opening and closing the door the device blocks the lock even if the set unlocking time is longer.

  • Page 9: Master Code Modification

    Access with the use of proximity card Access with the use of proximity card or code Access with the use of proximity card and code After typing proper combination of keys the mode indicator will turn red and a long beep will be heard –...

  • Page 10: Adding User Cards And Codes To Zone 1

    6.5. aDDIng user carDs anD coDes To zone 1 6.5.1. aDDIng user carD + coDe To zone 1 To enter the setting mode the user must double type master code. Mode indicator will turn red and long beep will be heard informing about operation success. Then to add the new user to zone 1 the number from the range should be typed –...

  • Page 11: Adding User Cards And Codes To Zone 2

    6.6. aDDIng user carDs anD coDes To zone 2 6.6.1. aDDIng user carD + coDe To zone 2 To enter the setting mode the user must double type master code. Mode indicator will turn red and long beep will be heard informing about operation success. Then to add the new user to zone 2 the buttons should be pressed –...

  • Page 12: Unlocking Time Setting

    6.8. unlockIng TIme seTTIng 6.8.1. unlockIng TIme seTTIng for zone 1 To enter the setting mode the user must double type master code. Mode indicator will turn red and long beep will be heard informing about operation success. Then to change the unlocking time for zone 1 buttons should be pressed - mode in- dicator flashes red.
  • Page 13 7. Table wITh programmIng commanDs summary unlocking with the use of proximity card only unlocking with the use of proximity card or user code unlocking with the use of proxi- mity card and user code changing unlocking time for XX (00-99) zone 1 [new master code] [new...

  • Page 14: Technical Data

    8. TechnIcal DaTa AC-30C7 Power supply 12-16V AC or DC Current (standby / work) 30mA / 160mA Proximity card, code + proximity card, Methods of access control code or proximity card Effective distance 5 cm Maximum numer of users – zone 1 1000 codes / cards / codes + cards Maximum numer of users –...

  • Page 15: Warranty

    As the only distributor of the Eura products, Eura-Tech is obliged to ensure efficient warranty and post-warranty service. In the countries where Eura- -Tech has neither its own service network, nor DOOR-TO-DOOR service, the quality claims are dealt with by authorised distributors of the Eura products on the basis of the signed distribution agreements.
  • Page 16 +48 58 678 81 00, service: tel. +48 58 678 81 20, fax +48 58 678 81 01 www.eura-tech.eu All rights reserved. Pictures, graphs and texts are the property of “Eura-Tech” Sp. z o.o. Copying, distributing and publication without permission of author is forbidden.
