Summary of Contents for PAVONI ITALIA Dosiplus Pro
- Page 3 ITALIANO pag. 04 ENGLISH pag. 10 FRANÇAIS pag. 16 DEUTSCH pag. 22 ESPAÑOL pag. 28...
- Page 4 Dosiplus PRO has a special feature: it is a machine with very low operating costs. During the design stage, PAVONI-ITALIA technicians have taken into consideration the aspect of energy consumption, equipping the machine with high performance components with low consumption.
- Page 5 Mounting of the machine The machine is assembled by inserting the hopper unit in the two threaded rods (1.1) protruding from the base, tightening, but not fully, the two red knobs (1.2). HOPPER UNIT BASE BODY Switching the system on Before switching the machine on, make sure that the mains voltage (volt) available is equal to the value of the voltage stated on the machine data plate.
-
Page 6: Cycle Programming
PROGRAMMING The machine has three operating possibilities, which are Operation in AUTOMATIC cycle Operation in MANUAL cycle Operation in CONTINUOUS cycle CONTROL KEYPAD AUTOMATIC OPERATING CYCLE The machine automatically dispenses the quantity of product set, with a pause set between one dose and another. CYCLE PROGRAMMING Press the selection key (SELEZIONE) on the keyboard and the “LED”... -
Page 7: Manual Operating Cycle
To stop (work end), the lever must be pressed again. Note: A feature of the Dosiplus PRO machine is to have, within the total time of the scale of numbers to input, from 01, 02, 03 to the number 99, constant time intervals between one number and the next. -
Page 8: Speed Programming
SPEED PROGRAMMING With the machine on and dispensing off, press the speed key (VELOCITÀ) on the keyboard and the LED incorporated in the key will light up. By pressing the + and – keys, the speed of dispensing can be increased or decreased. V01 100 TURN/1°... -
Page 9: Maintenance
MAINTENANCE (to be carried out frequently) The base does not require maintenance work except periodically proper cleaning of all outer parts. We recommend, at each change of the product to be dosed, washing the hopper unit components with hot water or in a dishwasher. The parts to be washed should be removed from the hopper unit in the following way (the numbers refer to the exploded diagram supplied with the machine): •...
