TCi -152C Operating Instruction

DESKTOP MICROPHONE TCI-152C
Model: TCI-152C
Power Supply:
DC9V or AC Power with adapter
Package Contents：
Microphone Base ............................................................
Gooseneck (42cm)...........................................................
Connection Cable (10m).................................................
AC Power Adapter............................................................
Foam Filter .......................................................................
User Manual ....................................................................
Descriptions：
This desktop microphone has built-in pre-paging chime of 2-tone up at the beginning and
post-paging chime of 2-tone down at the end. It is an ideal solution for
meetings,conferences,and public address needs.
It features a sophisticated switch ON/OFF to support push-to-lock and push-to-talk,
and features a flexible gooseneck,which allows you to angle it to an ideal speaking position,a
removable foam pop filter included.
The 10m cable with female XLR end ready for connection with the microphone base,at the
other end there is 6.35mm (1/4") plug ready for connection with the amplifier.
The microphone is powered using DC9V batter y in the base or by connecting to AC power with
an adapter.
Specifications：
Model No.:
Chime:
Capsule Type:
Frequency Response:
Polar Pattern:
Output:
Sensitivity:
Sound Pick-up Distance:
Base Dimension (WxDxH):
Gooseneck Length:
Batter y Working Time:
Power Supply:
Indicator :
Net Weight:
Page 1
(2-tone chime)
TCI-152C
2-tone chime (up/down)
Condenser
40Hz-16kHz
Cardioid
200Ω / Unbalanced
-38±2dB
40cm
126x150x39mm
420mm
18hrs (9V batter y)
DC9V batter y or AC110-240V with adapter
Base indicator, Mic. LED
0.68kg
x1
x1
x1
x1
x1
x1
