TCi -153CP Quick Start Manual

D
Model: TCI-153CP
Power Supply:
DC3V or Phantom Power 48V
Package Contents：
Microphone Base ............................................................
Gooseneck (41cm)...........................................................
Connection Cable (8m)...................................................
Foam Filter .......................................................................
XLR to 6.35mm (1/4") plug adapter...............................
User Manual ....................................................................
Descriptions：
This desktop microphone is an ideal solution for meetings,conferences,and public address
needs.
It features a sophisticated switch ON/OFF to support push-to-talk and push-to-luck,
and features a flexible gooseneck,which allows you to angle it to an ideal speaking
position,a removable foam pop filter included.
The 8m cable with female XLR plug ready for connection with the microphone base,
at the other end there is a male XLR plug ready for connection with the amplifier,
and a XLR to 6.35mm (1/4") plug adapter is provided.
The microphone is powered using DC3V batter y in the base or by connecting to an
XLR jack with +48V Phantom Power.
Specifications：
Model No.:
Capsule Type:
Frequency Response:
Polar Pattern:
Output:
Sensitivity:
Sound Pick-up Distance:
Base Dimension (WxDxH):
Gooseneck Length:
Batter y Working Time:
Power Supply:
Indicator :
Net Weight:
Page 1
TCI-153CP
TCI-153CP
Condenser
30Hz-20kHz
Cardioid
200Ω / Balanced
-42±2dB
45cm
114x168x57mm
410mm
24hrs (3V batter y)
DC3V batter y or 48V Phantom Power
Base OLED, Mic. LED
0.60kg
x1
x1
x1
x1
x1
x1
