  • Page 1 SuperGuard GPS Vehicle Security System Operation Manual ---------- ----------...
  • Page 2 Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. The Yield Technology Co., Ltd. (YTC) warrants to the purchaser that this product, under Connect the equipment into an outlet on a circuit different from normal use and conditions, will be free from defects in materials and workmanship for a that to which the receiver is connected.
  • Page 3: Table Of Contents

    Table of Contents 1. Parts & Accessories On receipt of your SuperGuard system, please check that all contents Parts & Accessories page 4 are complete and correct. SuperGuard Vehicle Unit - Features page 6 Preparations page 7 Installation page 8 Vehicle Unit –...
  • Page 4: Superguard Vehicle Unit - Features

    2. SuperGuard Vehicle Unit – Features 1. SuperGuard GPS/GPRS Main Unit The SuperGuard SG-VT02 is equipped with a variety of basic anti-theft or 2. GPS Aerial car alarm features. 3. GSM Antenna 4. 10-PIN Wiring Harness (CON 1) Apart from the supplied remote control, you can activate or disarm 5.
  • Page 5: Preparations

    3. Preparations 4. Installation In order to install the SuperGuard Vehicle Unit properly, the NOTE: Please note that installation methods may following preparations should be carried out: vary between vehicle models. For expert wiring and connecting please contact a professional car Prepare one operational GSM SIM card.
  • Page 6 Connecting The Vehicle Unit: CON 1: Cable Description and Colors NOTE: Finish all wiring and connections to the correct vehicle outputs and inputs before you apply Cable Description Color the connectors to the Vehicle Unit !!! Optional (free) Black/White To obtain maximum functionality of your Vehicle Unit you should Optional (free) Red/White locate and connect the following electrical output and input wires from...
  • Page 7 CON 1 Wiring Diagram (CON 2 see opposite side) Installation of SOS Emergency Push Button When laying the wiring loom • Try to ' bury' all wiring SOS Push Button • Avoid abrasive corners and sharp edges • Avoid sharp folding and pinching the cables Make sure that the connections have been made correct before you connect the Main Connector to the Vehicle Unit.
  • Page 8: Finish The Installation

    Finish the Installation o To ensure that the Vehicle Unit is able to operate even without vehicle battery support, you will need to connect the supplied spare battery to the device. o Insert the battery into the battery compartment connect both connectors. Close the top cover of the device and fasten it to the unit with the supplied screws.
  • Page 9: Vehicle Unit - Led Indicators

    5. Vehicle Unit – LED Indicators NOTE: Please note that adhesive sun absorber screens may consist of metal. This can distract or block the GPS signal. In that case the GPS aerial should be mounted outside of the vehicle. Power LED (green) If LED flashes: Device is powered on GPS/ GPRS LED (red)
  • Page 10: Getting Started

    6. Getting Started 7. Activate/ Disable Vehicle Security After plucking the Main Connector into the Vehicle Unit, the device will power up and automatically attempt to register to GSM network. As an authorized Contact person, you are Provided that your vehicle and the Vehicle Unit’s GPS antenna is able to activate and disable the vehicle positioned in an area with clear un-obstructed view of the sky, the security system either through supplied...
  • Page 11 Alternately, you are able to activate or disarm the Vehicle Unit or Additional Control Commands query its location and status over Internet Website or GPRS enabled cell phones. Please refer to the Software or Web User Car Owners and Contact persons can use their authorized mobile manuals to do this.
  • Page 12: Car Alarm/ Anti-Theft Features

    8. Car Alarm/ Anti-Theft Features Vehicle is Moving If the car has been moved in armed status (for example, in case of tow-away), the following car alarm features will come into effect: The alarm siren will sound for 30 seconds. As soon as the Security of the SuperGuard The Vehicle Unit will send an alarm message with updated Vehicle Unit has been activated, the following car...
  • Page 13: Emergency Alarms

    9. Emergency Alarms Peter’s truck is in Gatwick Parkway., near intersection Madison; GPS Car Alarm: Main Power Cut The SuperGuard security system includes special NOTE: If the vehicle battery has been removed, safety features that can save your life in case of you will not be able to remote control door locks.
  • Page 14: Monitoring Activities

    Users in the car can hang up the automatic SOS phone call 10. Monitoring Activities by pressing the SOS button again. After placing the SOS phone call, the vehicle unit will automatically start tracking and update GPS positions to the Control Base every 60 seconds over a period of 30 minutes.
  • Page 15: Battery-Low Warning

    The Vehicle Unit will send an alarm message and GPS 11. Locating and Tracking coordinates to the Control Base. The Control Base software will find the street name and closest intersection from a map server and send these details through SMS short messages to all Contact numbers, with the text: Authorized users can interrogate the Vehicle Unit to receive locations, street names and details.
  • Page 16: Vehicle Tracking

    From the GSM phone, use SMS text message to configure the Vehicle Unit with a local time zone, used for Quick Vehicle Tracking Locator function (example for GMT –11 hours): From the Control Base software, over Internet from the Tracking $TIME,-11 Enter Vehicle Unit Number Send...
  • Page 17: Retrieving Device Imea Number

    13. Retrieving Device IMEA Number 14. Technical Specifications If the product key (IMEA number) printed on the device cover has SIZE (L/W/H): 144.5 x 71 x 38 mm been scratched or otherwise became illegible during installation or use, you will be able to retrieve this number through SMS POWER SUPPLY: DC 11V ~ DC 25V command sent from one of the Contact Numbers or Control Base application.
  • Page 18 Sensitivity: > -140 dBm o Protocol: NMEA-0183 V3.0 o Projection: WGS-84 GPS ANTENNA: o Frequency band: 1575.42 ± 2 Mhz Yield Technology Co., Ltd. o Gain: +24 dBi No. 5-7 Shia Shin Nan, Chungli Taoyuan, TAIWAN R.O.C. TEL: (+886) 3-4533655...
