IMPORTANT SAFETY
INSTRUCTIONS
Read
WARNING
instructions,
specifications provided. Failure to follow all
instructions listed below may result in serious
injury and/or property damage. Save all warnings
and instructions for future reference.
• Always use common sense and be cautious
when using the PACKOUT™ Cyclone Debris
Separator. It is not possible to anticipate every
situation that could result in a dangerous outcome.
Do not use this tool if you do not understand these
operating instructions or you feel the work is
beyond your capability; contact MILWAUKEE
or a trained professional for additional information
or training.
Do not transport the PACKOUT™ Cyclone
•
Debris Separator vertically on a vehicle wall
unless allowed according to the product's
operator's manual. If product is damaged during
transport, it could cause the tool to work
improperly. Always inspect PACKOUT™ Cyclone
Debris Separator before connecting to a vacuum.
• Replace clip-style fasteners immediately if
cracked, worn, or damaged. Do not attempt to fix
or mend damaged clip-style fasteners.
• If the accessory has received an impact or is
involved in an
recommends you replace the accessory before
future use.
Ensure PACKOUT™ is secured before vehicle
•
is in motion. Do not use, adjust or modify
PACKOUT™ while vehicle is in motion.
SPECIFICATIONS
Cat. No. .................................................... PODS-1
Multi-fit Hose Adaptor Diameter....... 63.5 mm (2.5")
Expandable Hose Diameter.........
Expandable Hose Length............... Up to 1.8 m (6')
Debris Capacity........................................ 9.5 Litres
Vacuum Compatibility .............
Vacuum Mounting Clips Compatibility
...............M18FVC23L, M18FVC34L, M18FVC45L
NOTE: This unit is compatible with PACKOUT™
mounting systems. It is also have clips to securely
mount the unit to the top of the M18FVC23L,
M18FVC34L, M18FVC45L M18™ Wet/Dry L Class
Dust Extractors.
PACKOUT™ CYCLONE DEBRIS SEPARATOR
Cat.No.: PODS-1
all safety warnings,
illustrations
accident, MILWAUKEE
47.6 mm (1-7/8")
Wet & Dry Vacuums
FUNCTIONAL DESCRIPTION
1
and
Tool
®
9
8
®
Vacuum hose
1.
connection
Application hose
2.
connection
Transparent
3.
debris door
Vacuum
4.
mounting clips
5. Back door latch
1
2 3 4
10
PACKOUT™ cleats
6.
47.6 mm (1-7/8")
7.
Expandable hose
8. Multi-fit hose adaptor
Front PACKOUT™
9.
latch
10. 47.6 mm (1-7/8")
DEK26 connector
5
6
7
