- Page 1 OWNER’S MANUAL AIR CONDITIONER (MULTIPLE TYPE) For general public use Indoor unit RAS-M10, 13, 18S4KCVRG-SG 1129850215...
-
Page 2: Precautions For Safety
PRECAUTIONS FOR SAFETY Read the precautions in this manual carefully before This appliance is filled with R32. operating the unit. ■ Warning indications on the air conditioner unit Warning indication Description CAUTION CAUTION BURST HAZARD BURST HAZARD Open the service valves before the operation, Open the service valves before the operation, otherwise there might be the burst. - Page 3 PRECAUTIONS FOR SAFETY ● This appliance is not intended for use by person (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. ●...
-
Page 4: Remote Controller
REMOTE CONTROLLER INDOOR UNIT DISPLAY 1 Infrared signal emitter 1 ECO (White) 2 Start/Stop button 2 Wi-Fi access (White) 3 Mode select button 3 PURE (White) 4 Temperature button 4 Timer (White) 5 Fan speed button 6 Menu select button 5 Operation Mode - Cool (Blue) 7 Set louver Up-Down button... -
Page 5: Menu Setup
MENU SETUP Louver Swing and HADA Care Flow Operation Setting For select more setting of Air conditioner such as Louver select ,Hi POWER, 1. Press MENU button for enter menu selection. MENU OFF Timer and other use MENU button Blink only triangle During triangle mark blink can select menu by press TEMP. button. 2. Enter Louver set by press MENU button again. triangle mark will stop blink and setting feature will be blink instead. Blink only feature 3. Select Louver Swing or HADA Care Flow by press TEMP. button. -
Page 6: Hi Power Operation
Hi-P 8.2 SILENT OPERATION (Outdoor Unit) 8.3 Hi POWER OPERATION To automatically control room temperature and airflow for faster cooling Keep outdoor unit operating silently to ensure either yourself or neighborhood operation (except in DRY and FAN ONLY mode) will have a tight sleep in nighttime. By this feature, the cooling capacity will be optimized to deliver such silent experience. The silent operation can be 1. Press MENU button for enter menu setting and press TEMP. button to selected from one of two purposes (Silent 1 and Silent 2). select Hi POWER. There are three setting parameters: Standard level > Silent 1 > Silent 2 Silent 1: Blink both triangle and ● Though operating silently, the Cooling capacity is still prioritized to ensure feature mark Feature not having sufficient comfort inside the room. yet set ● This setting is a perfect balance between the Cooling capacity and the Sound level of outdoor unit. 2. Confirm selected feature by press MENU button again. Silent 2: ● Compromising the Cooling capacity to the Sound level in any circumstance where the outdoor unit’s sound level is highly prioritized. Blink only triangle ● This setting has a purpose to reduce the maximum sound level of outdoor Feature already set unit by 4 dB(A). -
Page 7: Power-Selection Operation
PURE 8.5 TIMER OFF OPERATION 8.6 PURE (IONIZER) OPERATION To set the timer OFF when the air conditioner is operating. Capture efficiency of floating impurities in the air is accelerated by Ionizer contaminates such as bacteria, odor, smoke, dust and virus are caught and 1. Press MENU button for enter menu setting and press TEMP. button to deactivated by Ionizer. select TIMER OFF. 1. Press MENU button for enter menu setting and press TEMP. button to select PURE. Blink both triangle and feature mark Feature not yet set Blink both triangle and feature mark Feature not yet set 2. Enter TIMER set by press MENU button. 2. Confirm selected feature by press MENU button again. triangle mark will stop blink and setting feature will be blink instead. Blink only hrs Blink only triangle Feature already set When feature had selected will return to menu selection display triangle mark will blink 3. Select TIMER OFF by press TEMP. button. Can select TIMER OFF from 0.5 - 12hrs. 3. Leave from menu setting display by select EXIT and press MENU button. Note: 4. - Page 8 5. Leave from menu setting display by select EXIT and press MENU button. REMOTE CONTROL A-B SELECTION To separate using of remote control for each indoor unit in case of 2 air conditioners are installed nearly. Remote Control B Setup. 1. Press RESET button on the indoor unit to turn the air conditioner ON. 2. Point the remote control at the indoor unit. 3. Push and hold button on the back side of Remote Control “00” will Note: be shown on the display. (Picture 1 ). ● Due to the reason that POWER-SELECTION function limits the maximum 4. Press during pushing . “B” will show on the display and current, inadequate cooling capacity may occur. “00” will disappear and the air conditioner will turn OFF. The Remote Control B is memorized. (Picture 2 ).
-
Page 9: Wireless Lan Connection
Android : Version 5.0 or later. About Toshiba Home AC Control 1. Toshiba Home AC Control can control AC operation by Smartphone or tablet (mobile device) via internet connection. 2. Everywhere control, control software run on Cloud system and mobile device can set and monitor AC operation via internet connection. - Page 10 Open application and select Log in. Enter user name and Login successful. password. Add Wireless adapter for control by Toshiba Home AC Control application. Wireless adapter Built-in Active Wireless adapter by remote controller and Auto login. Select “Add AC (Adapter)” from both display above.
- Page 11 Add Wireless adapter for control by Toshiba Home AC Control application. AC (adapter) connect. Active Wireless adapter by Remote controller. Press and hold MODE button 5 seconds Wireless LED mark will blink when AP mode active MODE MENU WPS mode...
- Page 12 Toshiba Home AC Control application Home screen Weekly schedule Setting Menu Add AC Sub menu all AC · All AC On/Off Add Group · Delete Group Group AC On/Off · Operation Setting Each AC On/Off Sub menu group · Select AC ·...
- Page 13 Mode and Condition setting. Enter operation mode of All AC Enter operation mode of Group AC Enter operation mode of each AC Mode select for Toshiba Home AC Control application. Provide for 5 operation modes Auto Cool Heat* Fan only * This “Heat mode”...
- Page 14 Setting in operation mode. Tab for select AC Weekly schedule OFF-ON timer set 0.5-12hrs. Mode select OFF-ON Timer set Temperature set Indoor temperature Outdoor temperature ON timer set from Off mode only Fan speed set Louver set Special feature Off mode...
- Page 15 Group operation. Maximum 3 groups 1 Group maximum = 10 units. Add group Add AC in group Delete AC in group Please make sure Factory Reset is performed before deleting AC from mobile application. (See owner manual ʺPress and hold MODE button on remote control for 5 second and active dL functionʺ)
- Page 16 Weekly schedule set. Day select Monday - Sunday Weekly schedule of all AC unit Weekly schedule of all AC unit Time select Weekly schedule set for each unit Mode select Select program for active by tick at select box Weekly schedule cancel. Weekly schedule not set Weekly schedule...
- Page 17 Energy monitoring Select Room for Energy monitoring Select Energy monitoring Energy monitoring display Set cost calculate and currency Select Energy monitoring display Export data and send by Email ● The power consumption displayed is just an estimate as it is calculated simply. It may sometimes differ from the result measured by the power meter.
- Page 18 In case of have some problem can check from Help menu. Note: ● The Wireless Adapter must be installed, maintained, repaired and removed by a qualified installer or qualified service person. ● Contact dealer and/or service center when equipment is malfunction. DECORATIVE FABRIC INSTALLATION The decorative fabric for cover on the air inlet grille of indoor unit was put in the accessories.
- Page 19 MEMO...
- Page 20 MEMO...
- Page 21 MEMO...
- Page 22 MEMO...
- Page 24 1129850215...
