Model shown is KX-TGB110
Before initial use, see "Getting Started"
on page 9.
Thank you for purchasing a Panasonic product.
Please read these operating instructions before using the unit and save them
for future reference.
Operating Instructions
Digital Cordless Phone
KX-TGB110HK
Model No.
KX-TGB112HK
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic KX-TGB110HK
Summary of Contents for Panasonic KX-TGB110HK
- Page 1 Digital Cordless Phone KX-TGB110HK Model No. KX-TGB112HK Model shown is KX-TGB110 Before initial use, see “Getting Started” on page 9. Thank you for purchasing a Panasonic product. Please read these operating instructions before using the unit and save them for future reference.
-
Page 2: Table Of Contents
Table of Contents Introduction Programming Accessory information ....3 Clock and Alarm ......22 Important Information Personal settings ......22 Base settings ........ 23 For your safety....... 4 Useful Information Important safety instructions..5 For best performance ....6 Voicemail ........27 Other information ...... -
Page 3: Introduction
Handset cover Charger See below for replacement battery information. The handset cover comes attached to the handset. Additional/replacement accessories Please contact your nearest Panasonic dealer for sales information. For enquiry, please call hotline 2313 0666. Accessory item Model number Rechargeable... -
Page 4: Important Information
Important Information ● Never touch the plug with wet For your safety hands. Danger of electric shock exists. To prevent severe injury and loss of life/ property, read this section Installation carefully before using the product to ● To prevent the risk of fire or ensure proper and safe operation of electrical shock, do not expose your product. -
Page 5: Important Safety Instructions
Important Information frequency) energy. (The product Battery operates in the frequency range of ● We recommend using the 1881.792 to 1897.344.MHz, and batteries noted on page 3. the RF transmission power is 250 USE ONLY rechargeable Ni-MH mW (max.).) batteries AAA (R03) size. ●... -
Page 6: For Best Performance
● The product should be kept free from excessive smoke, dust, high The base unit and other compatible temperature, and vibration. Panasonic units use radio waves to ● The product should not be communicate with each other. exposed to direct sunlight. -
Page 7: Other Information
Important Information ● When you leave the product Other information unused for a long period of time, unplug the product from the power ● CAUTION: Risk of explosion if outlet. battery is replaced by an incorrect ● The product should be kept type. -
Page 8: Specifications
Important Information Specifications ● Standard: DECT (Digital Enhanced Cordless Telecommunications) ● Number of channels: 10 Duplex Channels ● Frequency range: 1881.792 to 1897.344 MHz ● RF transmission power: Approx. 10 mW (average power per channel) ● Power source: 100-240 V AC, 50/60 Hz ●... -
Page 9: Getting Started
Connect the AC adaptor to the Setting up power outlet. Note: Connections ● Use only the supplied Panasonic AC adaptor S003AIB0600040. ■ Base unit Connect the AC adaptor plug to the unit until you hear a click. Connect the AC adaptor to the power outlet. -
Page 10: Note When Setting Up
T-adaptor. display. Note for battery installation ● Use the supplied rechargeable batteries. For replacement, we recommend using the Panasonic rechargeable batteries noted on page 3 and 5. Note for battery charging ● It is normal for the handset to feel warm during charging. -
Page 11: Navigating The Menus
Getting Started Note: Panasonic Ni-MH battery If no buttons are pressed for 30 performance (supplied batteries) seconds, the handset returns to standby automatically. Operation Operating time In continuous use 10 hours max.*1 Date and time Not in use (standby) 200 hours “CLOCK/... -
Page 12: Controls
Getting Started Speaker Controls During a call, press to increase Handset earpiece volume, page 15. When the phone is ringing, press to increase the handset ringer volume, page 15. Press to scroll through the menu options, redial list, calls list and phonebook entries. -
Page 13: Display Icons
Getting Started Phonebook/Delete/Back Base unit In standby mode, press to open the phonebook list. In editing mode, press to delete characters and digits. Go back to the previous menu level. End Call/Exit/Handset on/off Press to end a call. When viewing the redial / calls list / phonebook or when in the menu, press to exit and return to standby. -
Page 14: Menu Map
Getting Started Signal icon Menu Map Steady when registered and in range. Flashes when PHONEBOOK - VIEW out of range of the base or - ADD NEW searching for the base.* - EDIT Eco mode is ON - DELETE* Zero Emit is ON - DELETE ALL* CLOCK/ALARM - DATE &... -
Page 15: Making/Answering Calls
Making/Answering Calls Note: Making calls ● A 3 second pause is inserted each time you press and hold (Pause) on the handset. When there is a the dial tone, dial the number. Answering calls When you finish talking, press or place the handset on the When an external call is received, the base unit or charger. -
Page 16: Intercom, Transferring Calls And Conference Calls
Making/Answering Calls to answer the call. For call waiting or Call Waiting Caller ID service users Transferring calls To use call waiting or Call Waiting Outside calls can be transferred or a Caller ID, you must first subscribe conference call with an outside party with your service provider/telephone can be made between 2 handsets. -
Page 17: Redial
Making/Answering Calls Edit the number if necessary, Redial then press . The number is stored. Making a call using the redial Note: list See ‘Entering names and Writing tips’ The last 10 phone numbers dialled on page 18. are stored in the redial list (each 24 digits max.). -
Page 18: Phonebook
Phonebook View or dial an entry Phonebook icon is displayed. The phonebook can store up to 50 : Select the required entry. names and numbers. Names can be up to 12 characters long and Enter the first letter of the name numbers up to 24 digits. - Page 19 Phonebook Delete an entry . “PHONEBOOK”. “DELETE”, press : To the entry that needs to be deleted, or search alphabetically, press to confirm or to cancel. Delete all entries . “PHONEBOOK”. “DELETE ALL”, press to confirm or to cancel. Store a quickdial number Your phone can store 2 quickdial numbers for key 1 and 2.
-
Page 20: Caller Id And Calls List
Caller ID and Calls list View the Calls list Caller ID and Calls list to open the Calls list. If there IMPORTANT are no calls in the list, the display To use Caller ID, first subscribe to the shows “LIST EMPTY”. service from the network provider. - Page 21 Caller ID and Calls list Delete an entry to open the Calls list. : To the required entry. “DELETE”. , “CONFIRM ?”. to confirm or to cancel. Delete the entire Calls list to open the Calls list. “DELETE ALL”. , “CONFIRM ?”. to confirm or to cancel.
-
Page 22: Programming
Programming Clock and Alarm Personal settings Setting the date and time Handset ringer volume If you have subscribed to Caller ID The handset ring volume can be set Service, the date and time will be set to different volume level. Choose on your handset whenever a call is from 5 volume levels or Off. -
Page 23: Base Settings
Programming “AUTO ANSWER”, press Key tones “PERSONAL : Select “ON” or “OFF”. SET”, press to confirm or to return “HANDSET TONE”, press to the previous menu. : Select “KEY TONE”, press Language : Select “ON” or “OFF”. “PERSONAL SET”, press to confirm or to return to the previous menu. - Page 24 Programming Zero Emit Recall Time When Zero emit is activated and the This setting is useful to access unit has been idle for about 1 minute, certain network and PBX/switchboard the transmitted power between the services. handset and the base will stop, an The default recall time is suitable for incoming call or pressing any key will your country and network operator.
- Page 25 Programming When entering a PIN, the digits are to a base, press shown as ****. “ADVANCED SET”, press “ADVANCED “REGISTER”, press SET”, press Enter the 4 digit PIN code (default “CHANGE PIN”, press = 0000), press If the PIN is already changed A beep will be heard if the registration from default setting, enter the is successful.
- Page 26 Programming Restore default settings Default settings by reset The phone can be restored to its Key tone default (original) settings. All the Auto answer handsets that are registered to the Ringer melody base will be retained. Ringer volume IMPORTANT Receiver volume 3 Resetting the phone to its default Language ENGLISH...
-
Page 27: Useful Information
Useful Information Voicemail Troubleshooting Voicemail is an automatic answering No dial tone service offered by your service ● Use only the telephone line cord provider/telephone company. supplied. After you subscribe to the service, your service provider/telephone ● Check that the telephone line cord company’s voicemail system is connected properly. - Page 28 Useful Information Keypad does not seem to work Cannot register a handset to the base ● Check that the keypad lock is not on, see page 17. ● Check that correct PIN code (default = 0000) has been entered. icon is not scrolling during ●...
-
Page 29: Index
Index Intercom: 16 Index Keypad lock: 17 Key tones: 23 Alarm: 22 Language: 23 Answering calls: 15 Auto answer: 23 Making calls: 15 Auto Prefix: 24 Menu Map: 14 Mute: 15 Base unit controls: 13 Pause: 15 Battery: 3, 5 Phonebook: 18 Battery charging: 10 PIN code: 24... - Page 30 Notes...
- Page 31 Notes...
- Page 32 Block B, 9/F., Peninsula Centre 67 Mody Road Tsimshatsui East Kowloon, Hong Kong Tel: 2313 0888 Hotline: 2313 0666 Fax: 2368 8068 Email address: shtec@panasonic.oa.hk 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan © Panasonic System Networks Co., Ltd. 2015 Version 7 (EN_HK)
