OWNER'S MANUAL
MEDICAL MONITOR
Please read this manual carefully before operating your set and retain it for future reference.
Model name : AR-3250-3212
www.arthrex.com
Copyright
2023 Arthrex, Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AR-3250-3212 and is the answer not in the manual?

Questions and answers

Related Manuals for Arthrex AR-3250-3212

Summary of Contents for Arthrex AR-3250-3212

  • Page 1 OWNER’S MANUAL MEDICAL MONITOR Please read this manual carefully before operating your set and retain it for future reference. Model name : AR-3250-3212 www.arthrex.com Copyright 2023 Arthrex, Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    CONTENTS ON CLEANING ............3 LICENSE ..............4 OPEN SOURCE SOFTWARE NOTICE INFORMATION ..4 ASSEMBLY AND PREPARING ........5 USER SETTINGS ............15 TROUBLESHOOTING ..........29 PRODUCT SPECIFICATIONS ........31 EXTERNAL CONTROLLER SETUP ......... 40...

  • Page 3: On Cleaning

    Cleaning guidelines for displays must only be carried out by medical professionals (Doctors or Nurses), cleaners must not be handled by patients. • Firmware update should be performed through Arthrex or its distributor. • If Arthrex or its distributor instructs to update the firmware, update it immediately.

  • Page 4: License

    LICENSE OPEN SOURCE SOFTWARE NOTICE INFORMATION The terms HDMI, HDMI High-Definition Multimedia To obtain the source code that is contained in this product, under GPL, LGPL, MPL, and other open source Interface, HDMI trade dress and the HDMI Logos are licenses that have the obligation to disclose source code, and to access all referred license terms, copyright trademarks or registered trademarks of HDMI Licensing notices and other relevant documents, please visit https://opensource.lge.com .

  • Page 5: Assembly And Preparing

    ASSEMBLY AND PREPARING Product Composition Please check whether all the components are included in the box before using the product. If there are any missing components, contact the retailer where you purchased the product. Note that the product and related components may look different from those shown here. Owner's Manual/Regulatory Manual/Cards Power Cord AC/DC Adaptor...

  • Page 6: Supported Software

    • It is recommended to use the supplied components. • If you use generic cables not certified by Arthrex, the screen may not display or there may be image noises. Drivers and Software Installation Priority • Only use components listed below that meet the listed standard. Unauthorized components may cause...
  • Page 7 Product and Control buttons Front Bottom...

  • Page 8: Control Button Functions

    Control button Functions • Selects the input mode. • Adjusts display mode for 2 or more screens. • Opens the [Hot key Settings] menu. • Adjusts the screen brightness. • Selects and confirms menus or options • Adjusts the screen contrast. •...
  • Page 9 Connectors Back...
  • Page 10 SDI IN/SDI OUT, SFP DC-IN • Receives or transmits digital video signals. • Connect an AC/DC adapter. • Supported SDI(Serial Digital Interface signals) format is SMPTE 259M compliant (SD) / SMPTE DVI-D IN/DVI-D OUT 292M compliant (HD) / SMPTE 425M compliant (3G) / SMPTE ST 2081-10 (6G) / SMPTE ST 2082-10 •...
  • Page 11 USB IN/USB UP • Used for HW Calibrator (Optional Accessory) connection. • Connect peripheral device to the USB input port. • A keyboard, mouse, or USB storage device can be connected. • To use USB 2.0, connect the A-B type USB 2.0 cable to the PC. CAUTION Cautions When Using a USB Storage Device •...

  • Page 12: Installing The Monitor

    Installing the Monitor Once the back door is attached, assemble it using the screws. Cable connection and organize Before connecting the connectors, remove the back door as shown below. Once the screws are removed, lift the back door in the direction of the arrow below to remove it. The back door is held in place with a magnet.

  • Page 13: Installing On The Wall

    NOTE • A non-VESA standard screw may damage the product and cause the monitor to fall. Arthrex is not liable for any accidents relating to the use of non-standard screws. To install the monitor to a wall, attach a wall mount plate (optional) to the back of the monitor.
  • Page 14 CAUTION Precautions for Connecting the Power Cord • Disconnect the power cord before moving or installing the monitor. There is risk of electric shock. • Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury.

  • Page 15: User Settings

    USER SETTINGS Activating the Quick Menu Press to show the OSD Quick Menu. Among the Control Button, press to move to the left or right or ( , to move to the bottom or top or ( ) to set options. In order to exit from the OSD Menu, press the Control Button or select [Exit].
  • Page 16 [Quick Settings] Press and select [All Settings] to show the complete OSD Menu. Among the Control Button, press to move to the left or right or ( , to move to the bottom or top to go to the [Quick Settings]. Configure the options following the instructions that appear in the bottom right corner.
  • Page 17 [All Settings] > [Quick Explanation Settings] [User Preset] User Preset allows the user to save or load up to 10 picture quality settings for multiple connected devices in each preset. NOTE • You can use User Preset to import or save items in [Picture Adjust] and [Color Adjust] of the [Picture] menu. [User Name] Allows the user to change and register a user name (Preset 1 ~ Preset 3, User 1 ~ User 7) as the user wants.
  • Page 18 [Input] Press and select [All Settings] to show the complete OSD Menu. Among the Control Button, press to move to the left or right or ( , to move to the bottom or top to go to the [Input]. Configure the options following the instructions that appear in the bottom right corner. To configure an upper menu or another item, press the Control Button or press ( ) to move to the settings.
  • Page 19 [All Settings] > [Input] Explanation [SDI Mode] Selects among the SDI signal processing modes. ([Single1], [Single2], [Single3], [Single4], [12G 2-SI(QUAD Link)], [12G Square(QUAD Link)], [SFP]) NOTE • Single 12G-SDI Signal Format: [Single1], [Single2], [Single3], [Single4], [SFP] • Quad 3G-SDI Signal Format: [12G 2-SI(QUAD Link)], [12G Square(QUAD Link)] - Square Division: The full image is divided into four quadrants using four 3G-SDI signal format.
  • Page 20 [All Settings] > [Input] Explanation [Aspect Ratio] Adjusts the aspect ratio of the screen. ([Full Wide], [Original], [Just Scan]) NOTE • The display may look the same for [Full Wide], [Original] and [Just Scan] options at the 3840 x 2160 resolution. [Screen Flip] Adjusts the screen image rotation.
  • Page 21 [Picture] Press and select [All Settings] to show the complete OSD Menu. Among the Control Button, press to move to the left or right or ( , to move to the bottom or top to go to the [Picture]. Configure the options following the instructions that appear in the bottom right corner. To configure an upper menu or another item, press the Control Button or press ( ) to move to the settings.
  • Page 22 [Picture Mode] on HDR signal (HDMI Only) [All Settings] > [Picture] Explanation [Custom] Allows the user to adjust each element. [Picture Mode] [Vivid] Optimized the screen for HDR vivid colors. [Standard] Optimized the screen for HDR standard. NOTE • HDR content may not display correctly depending on Windows 10 OS settings, please check HDR On/Off settings in Windows. •...
  • Page 23 Explanation [All Settings] > [Picture] [Brightness] Adjusts screen brightness. [Picture Adjust] NOTE • Press the button to toggle between [Turn on 'Brightness Stabilization']/[Turn off 'Brightness Stabilization']. • When [Brightness Stabilization] is [On], the [Brightness] adjustment function is deactivated. • When [Brightness Stabilization] is [On], [SMART ENERGY SAVING] and [DFC] functions are deactivated. •...
  • Page 24 Explanation [All Settings] > [Picture] [Picture Adjust] [DFC] [On] Automatically adjusts brightness depending on the screen. [Off] Deactivates the [DFC] function. [Response Time] Sets a response time for displayed pictures based on the movement of the picture on the screen. In a normal environment, it is recommended that you set [Fast].
  • Page 25 Explanation [All Settings] > [Picture] [Color Adjust] [Gamma] Set your own gamma value. ([Gamma 1.8], [Gamma 2.0], [Gamma 2.2], [Gamma 2.4], [Gamma 2.6], [DICOM Gamma Curve]) Higher gamma settings mean a darker image is displayed or vice versa. [Color Temp] Set your own color temperature.
  • Page 26 [General] Press and select [All Settings] to show the complete OSD Menu. Among the Control Button, press to move to the left or right or ( , to move to the bottom or top to go to the [General]. Configure the options following the instructions that appear in the bottom right corner. To configure an upper menu or another item, press the Control Button or press ( ) to move to the settings.
  • Page 27 [All Settings] > [General] Explanation [User Preset] User Preset allows the user to save or load up to 10 picture quality settings for multiple connected devices in each preset. NOTE • You can use User Preset to import or save items in [Picture Adjust] and [Color Adjust] of the [Picture] menu. [User Name] Allows the user to change and register a user name (Preset 1 ~ Preset 3, User 1 ~ User 7) as the user wants.
  • Page 28 [All Settings] > [General] Explanation [RS-232C] [RS-232C] and the [HW Calibration] cannot be used at the same time. [RS-232C] The [RS-232C] function will be operated or turned off. [Set ID] Adjusts [Set ID]. (The scope of adjustment: 1-10) [Input Compatibility Version] Please set the [Input Compatibility Version] to match the version of the connected external device.

  • Page 29: Troubleshooting

    TROUBLESHOOTING Nothing is displayed on the screen. Problem Action Is the monitor's power cord plugged in? • Check if the power cord is correctly plugged into the power outlet. Is the power indicator on? • Check the power cable connection and turn on the power switch. Is the power indicator displaying as green? •...
  • Page 30 The screen is unstable and shakes. / There are shadowy traces left on the screen. Problem Action Did you select the appropriate resolution? • If the selected resolution is HDMI 1080i 60/50 Hz (interlaced), the screen may be flickering. Change the resolution to 1080p or the recommended resolution. The display color is abnormal.

  • Page 31: Product Specifications

    PRODUCT SPECIFICATIONS Specifications are subject to change without notice. The symbol ~ means alternating current, and the symbol means direct current. LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Pixel Pitch 0.18159 mm x 0.18159 mm Resolution Max Resolution DVI-D: 1920 x 1080 @ 60 Hz...
  • Page 32 Environmental Conditions Operating Conditions Temperature 0 °C to 40 °C (32 °F to 104 °F) Humidity 0 % to 80 % Pressure 700 hPa to 1060 hPa Storage / Transport Conditions Temperature -20 °C to 60 °C (-4 °F to 140 °F) Humidity 0 % to 85 % Pressure...
  • Page 33 IP35...
  • Page 34 Support Mode (Preset Mode - PC) DisplayPort Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 45.00 60.00 1280 x 1024 63.981...
  • Page 35 HDMI Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 45.00 60.00 1280 x 1024 63.981 60.02 1600 x 900 60.00 60.00...
  • Page 36 Support Mode (Video) DVI-D, HDMI, DisplayPort Vertical dimensions Vertical Frequency (Hz) DVI-D HDMI 1.4 HDMI 2.0 DisplayPort 480i 59.94/60 480p 59.94/60 576p 576i 720p 59.94/60 720p 1080i 59.94/60 1080p 59.94/60 1080i 1080p 1080p 23.97/24 1080p 29.97/30 2160p 23.98/24 2160p 2160p 29.97/30 2160p 2160p...
  • Page 37 Sampling SMPTE Interface Signal type Image Format Signal Format Pixel Depth Field/Frame Rate Remark Structure 720 x 486 4 : 2 : 2 YCbCr 10 bit 59.94i 259M SD-SDI 720 x 576 4 : 2 : 2 YCbCr 10 bit 30p, 29.97p, 25p, 24p, 23.98p 2048 x 1080 4 : 2 : 2...
  • Page 38 Sampling SMPTE Interface Signal type Image Format Signal Format Pixel Depth Field/Frame Rate Remark Structure 4 : 4 : 4 RGB & YCbCr 12 bit / 10 bit 30p, 29.97p, 25p, 24p, 23.98p 4096 x 2160 10 bit 60p, 59.94p, 50p 4 : 2 : 2 YCbCr 2-sample interleave...

  • Page 39: Power Indicator

    Power indicator Mode LED Color On Mode Green NOTE • Vertical Frequency: In order to display an image, the screen must be refreshed dozens of times per second, like a fluorescent lamp. The number of times the screen is refreshed per second is called vertical frequency, or refresh rate, and is represented by Hz.

  • Page 40: External Controller Setup

    EXTERNAL CONTROLLER SETUP Set ID Function This function allows you to assign a unique ID to the monitor to control it remotely from your PC. The actual product may differ from the picture shown. Please refer to the "Transmission/Reception Protocol". Connect the RS-232C (serial connector) of the PC to the RS-232C IN connector at the back of the monitor.
  • Page 41 Command Reference List Data Command Command1 Command2 (Hexadecimal) 16. [DFC] 00 ~ 01 Data Command Command1 Command2 17. [Response Time] 00 ~ 03 (Hexadecimal) 18. [Black Stabilizer] 00 ~ 64 01. Power 00 ~ 01 19. [Uniformity] 00 ~ 01 02.

  • Page 42: Transmission/Reception Protocol

    Transmission/Reception Protocol Error Acknowledgment (Command2)( )(Set ID)( )(NG)(Data)(x) Transmission When the set receives an abnormal piece of Data for an unsupported function or there is a communication error, (Command1)(Command2)( )(Set ID)( )(Data)(Cr) it returns ACK in the format above. (Command 1): j, k, m, x, t, f, d Data 00: Illegal code (Command 2): This command is used to control the monitor.
  • Page 43 01. Power (Command: k a) [Input List] (Sub) (Command: x c) ʢ Controls the On/Off of the power supply to the monitor. ʢ Controls the input mode of the Sub. Transmission (k)(a)( )(Set ID)( )(Data)(Cr) Transmission (x)(c)( )(Set ID)( )(Data)(Cr) Data Data 00: Power Off...

  • Page 44: Aspect Ratio] (Main) X F 00

    04. [Aspect Ratio] (Main) (Command: x f) [Aspect Ratio] (Sub 3) (Command: x i) ʢ Adjusts the Aspect Ratio of the Main. ʢ Adjusts the Aspect Ratio of the Sub 3. Transmission (x)(f)( )(Set ID)( )(Data)(Cr) Transmission (x)(i)( )(Set ID)( )(Data)(Cr) Data Data 00: [Full Wide]...

  • Page 45: Main/Sub Screen Change]

    05. [PBP / PIP] (Command: k n) 08. [Picture Mode] (Command: d x) ʢ Controls the PBP / PIP mode. ʢ Controls the Picture Mode. Transmission (k)(n)( )(Set ID)( )(Data)(Cr) Transmission (d)(x)( )(Set ID)( )(Data)(Cr) Data Data 00: Off 01: 2PBP 00: [Custom] 01: [Vivid] 09: 3PBP...

  • Page 46: Brightness Stabilization]

    11. [Sharpness] (Command: k k) 14. [Black Level] (Command: m d) ʢ Adjusts the sharpness of the screen. ʢ Controls the Offset level. (HDMI only) Transmission (k)(k)( )(Set ID)( )(Data)(Cr) Transmission (m)(d)( )(Set ID)( )(Data)(Cr) Data Data Min: 00 - Max: 64 00: [High] 01: [Low] Ack (k)( )(Set ID)( )(OK/NG)(Data)(x)
  • Page 47 16. [DFC] (Command: m f) 19. [Uniformity] (Command: m i) ʢ Controls the DFC function. ʢ Controls the Uniformity function. Transmission (m)(f)( )(Set ID)( )(Data)(Cr) Transmission (m)(i)( )(Set ID)( )(Data)(Cr) Data Data 00: [On] 01: [Off] 00: [On] 01: [Off] Ack (f)( )(Set ID)( )(OK/NG)(Data)(x) Ack (i)( )(Set ID)( )(OK/NG)(Data)(x) 17.

  • Page 48: Smart Energy Saving]

    22. [Red] (Command: j w) 25. [Language] (Command: f i) ʢ Adjusts the red. ʢ Adjusts the language of the Menu screen. Transmission (j)(w)( )(Set ID)( )(Data)(Cr) Transmission (f)(i)( )(Set ID)( )(Data)(Cr) Data 00 - 10: English - Korean (17 languages) Min: 00 - Max: 64 Ack (i)( )(Set ID)( )(OK/NG)(Data)(x) Ack (w)( )(Set ID)( )(OK/NG)(Data)(x)

  • Page 49: Dvi Power Supply] M M 00

    27. [DVI Power Supply] (Command: m m) 29. [OSD Lock] (Command: k m) ʢ Controls the DVI Power Supply function. ʢ Controls the OSD Lock function. Transmission (m)(m)( )(Set ID)( )(Data)(Cr) Transmission (k)(m)( )(Set ID)( )(Data)(Cr) Data Data 00: [On] 01: [Off] 00: [Off] 01: [On]...

  • Page 50: Screen Flip] (Main) T H 00

    31. [Screen Flip] (Main) (Command: t h) 32. [Failover Input Switch] (Command: k z) ʢ Adjusts the screen image rotation of Main screen. ʢ Controls the Failover Input Switch function. Transmission (t)(h)( )(Set ID)( )(Data)(Cr) Transmission (k)(z)( )(Set ID)( )(Data)(Cr) Data Data 00: [Off]...

  • Page 51: Sdi Mode]

    35. [SDI Mode] (Command: x x) ʢ Selects among the SDI signal processing modes. Transmission (x)(x)( )(Set ID)( )(Data)(Cr) Data 00: [Single1] 01: [Single2] 02: [Single3] 03: [Single4] 04: [12G 2-SI(QUAD Link)] 05: [12G Square(QUAD Link)] 06: [SFP] Ack (x)( )(Set ID)( )(OK/NG)(Data)(x) 36.
  • Page 52 LG Electronics Inc. 168, Suchul-daero, Gumi-si, Gyeongsangbuk-do, 39368 Republic of Korea Tel: +82-1544-8777 www.lg.com Distributed by: www.arthrex.com www.arthrex.com/dfu-list Germany www.arthrex.de WARNING: This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference.
