Yamasaki Y4 Series Manual

Otdr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PREFACE:
Thank you very much for purchasing and using this series optical time domain reflectometers (OTDR). This manual mainly contains
information on common operation, safety instructions, basic operations and specifications of the Yamasaki Y44 OTDR, as well as common
troubleshooting guides.
For your convenience, before operating this Yamasaki Y4 series OTDR, please read this manual carefully and follow the instructions in the
book correctly.
This manual is only for use with the Yamasaki Y4 series OTDR. Without the authorization of the company, any unit or individual shall not
tamper, copy and disseminate the contents of this manual for commercial purposes.
The contents of this manual are subject to change without notice. If you have any questions, please call us on (03)
and we will
8761 6622
be happy to provide you with the best service possible!
Copyright Information
Copyright © 2023 belongs to Yamasaki Optical Technology Pty Ltd.
Page | 0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Y4 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Yamasaki Y4 Series

Summary of Contents for Yamasaki Y4 Series

  • Page 1 For your convenience, before operating this Yamasaki Y4 series OTDR, please read this manual carefully and follow the instructions in the book correctly. This manual is only for use with the Yamasaki Y4 series OTDR. Without the authorization of the company, any unit or individual shall not tamper, copy and disseminate the contents of this manual for commercial purposes.

  • Page 2: Table Of Contents

    3. Features of this series of OTDR products ............................9 3.1 Main function....................................9 3.2 Other function....................................10 4. Basic operation and usage of OTDR products of the Yamasaki Y44 OTDR..................11 4.1 The Yamasaki Y44 OTDR panel ..............................11 4.2 ON/OFF......................................11 4.3 Charge and Discharge..................................13 4.4 Connect Optical Cable ...................................14...
  • Page 3 5.1 How to observe the optical pulse waveform? .........................52 5.2 How to clean the optical output interface of OTDR? ......................56 5.3 How to copy the internal documents of the Yamasaki Y44 OTDR to the U disk or computer?..........56 5.4 How to print test trace in batch?.............................57 5.5 How to print test trace into PDF report?..........................57...

  • Page 4: Summary

    1.2 Product Overview The Yamasaki Y4 series OTDR is a new generation, 7-inch capacitive touch screen, comprehensive OTDR with many additional functions. It is constructed of sturdy and durable material for ease of use and peace of mind.

  • Page 5: Safety Tips

    Safety tips External power supply. The power adapter input meets the following requirements：100V～240V, 50/60Hz. The power adapter output meets the following requirements：5V/3A、9V/2A、12V/1.5A. Please use the adapter provided with the OTDR and use the external power supply strictly in accordance with the specifications, otherwise the equipment may get damaged.
  • Page 6 Laser Safety Warning when using this OTDR, please avoid looking directly at the laser output port, and do not look directly at the end of the optical fiber during testing; when the OTDR is used, please cover the light output port dust cap. LCD Screen: the display of this series of optical time domain reflectometers is a 7-inch color LCD screen with a touch screen, in order to maintain good viewing effect, please keep the LCD screen clean and clean.

  • Page 7: The Yamasaki Y44 Otdr Maintenance

    1.3 OTDR Maintenance The Yamasaki Y4 series OTDR is guaranteed for 18 months, and the battery, adapter, and consumable parts of the optical interface are guaranteed for 6 months. The items provided with the product are not within the scope of this warranty.

  • Page 8: Basic Knowledge Of Otdr

    2. Basic Knowledge An Optical Time Domain Reflectometer (OTDR) is a precision optical fiber measurement instrument made by using the principle of back- scattering generated by Rayleigh scattering and Fresnel reflection when laser light is transmitted in optical fiber. It measures the transit time of a light pulse back and forth, uses the formula L=c×t/(2n) to calculate the distance L, the unit of L is m, c is the propagation speed of light in vacuum 2.99792×...
  • Page 9 various connection points, fusion points and bending, cracking or breaking positions in the optical fiber link that lead to the loss of transmission signals, mainly divided into reflection events and non-reflection events. 1）Reflective event When the laser pulse sent by the OTDR is transmitted along the fiber under test, if it encounters an active connection point or the end of the fiber, reflection will occur due to the sudden change of the refractive index, and part of the optical signal will return to the OTDR along the fiber under test.
  • Page 10 as a signal with a drop in energy on the OTDR curve, and the magnitude of the drop indicates power loss. 3） ） ） ） Dynamic Range Dynamic range is an important parameter of optical time domain reflectometry, it is measured in dB. This parameter is expressed as the maximum optical loss that the OTDR can analyze from the back-scatter level at the output port of the OTDR down to a specific noise level.
  • Page 11 the next Fresnel reflection signal by OTDR is defined by the pulse width less than 1.5dB of the peak value. Attenuation Blind Zone: The shortest distance that an OTDR goes through from detecting Fresnel reflection signal to normal testing backward Rayleigh scattering signal, that is, the phase cannot measure fusion loss due to adjacent large reflection.

  • Page 12: Features Of This Series Of Otdr Products

    3.Features of this series of OTDR products 3.1Main function : 1） ） ） ） OTDR：Support transmitting fiber, receiving fiber setting, Pass/Fail threshold determination, test report generation and other functions. 2） ） ） ） Event Map: Intelligent link test (multi-pulse width test) and visual event list. 3）...

  • Page 13: Other Function

    9） ） ） ） Remote Test： ： ： ： Remotely connect the OTDR via Ethernet to realize remote control of the OTDR function. 3.2 Other functions Support fast charging and power bank functions. The Type-C interface supports PD/QC/AFC/FCP/PE/SFCP and other fast charging protocols to charge the built-in battery; the OTDR is powered by U -SBA as a power bank.

  • Page 14: Basic Operation And Usage Of Otdr Products Of The Yamasaki Y44 Otdr

    4. Basic operation and usage of OTDR 4.1 Instrument panel Page | - 11 -...

  • Page 15: On/Off

    4.2 ON/OFF Power-on operation: In the power-off state, press the power-on button for >2s and the battery power >3% when the OTDR is turned on, and the power-on indicator lights up. Soft shutdown operation: (1) Press the on/off button for > 2s, a shutdown prompt box will pop up, select "Yes", and the OTDR will shut down.

  • Page 16: Charge And Discharge

    4.3 Charge and Discharge Charge： ： ： ： The OTDR is charged via the Type-C USB interface support 5V/3A normal charging and 9V/2A, 12V/1.5A fast charging mode up to 18W. The indicator light is on when charging, and the charging icon is displayed in the status bar. Discharge：...

  • Page 17: Connect Optical Cable

    4.4 Connect Optical Cable Warning The light is emitted from the light source port of the OTDR, please do not unplug the connected optical cable, the light can damage the eyes. If there is no optical cable connected to the light source port, close the cover of the light source port. When using an OTDR with more than 2 light source ports, it may cause eye damage if it reflects in the eyes.

  • Page 18: Homepage And Status Bar

    4.5 Homepage and status bar. Status bar: Indicates BT (Bluetooth), TF card, U disk, VFL, charging status, and power in turn. Pull down the status bar to pop up the shortcut interface, click other areas to close the shortcut interface. The quick operation interface controls the Bluetooth switch, Type-C USB (data transfer) switch, red light switch, quick screenshot, main sound switch, and brightness adjustment, and can also perform shortcut operations of shutting down and returning to the homepage.

  • Page 19: Otdr

    4.6 OTDR 1） ） ） ） Settings The setting interface is the first interface of the OTDR function: select test range, pulse width, time, wavelength, mode. Different ranges correspond to different optional pulse widths. RT is the real-time test mode, and the selected test time is the average mode.
  • Page 20 Note: During test, the test parameters can be modified in real time (except for automatic test and multi-wavelength real-time test), and the output port cannot be directly viewed. 2) Advanced settings Options: Click “Options” /set title to switch the setting content; Restore default: The current interface setting parameters are restored to the factory settings.
  • Page 21 High-resolution mode: After turning on the high-precision mode, the minimum point spacing within the 5km range is ≤ 0.02m, and the maximum number of sampling points above the 260km range is ≥256k. When the start fiber and end fiber are set to 5km, the test is shown on the right.
  • Page 22 Step 1: Touch the "Pass/Fail Threshold" switch to enable the Pass/Fail function; Step 2: Click the number area to pop up the key-board to modify the parameters; Step 3: Test: after the pass/fail threshold function is enabled, the event list display effect is as displayed as pictured. ④...
  • Page 23 Save route: select the storage path; Show from start fiber: After it is turned on, the display starts from the set launch fiber position; Show Thumbnail: When turned on, the curve thumbnails are displayed in the upper right corner of the test interface. （...
  • Page 24 （ （ （ （ 4） ） ） ） Curve operation Save: Save the current curve and generate a test report by SOR; Settings: Click to return to the setting interface and set the test parameters; Curve: Perform operations such as zooming in, moving the cursor, and comparing curves to the test curve;...
  • Page 25 Waveform Analysis: Waveform zoom and move operations Waveform zoom: Full touch screen gestures expand outward to zoom in the zoom center area; Waveform zoom out: The full touch screen gesture shrinks inward in the zoom center area to zoom out; Waveform reset: Click the "1:1"...

  • Page 26: Cursor Operation

    Cursor operation: Cursor movement: click and hold the cursor symbol and drag or select the cursor in the key area and click the direction of movement; Cursor Hide: All cursors can be hidden, and the cursor centering resets all cursors to the center of the screen. Page | - 23 -...
  • Page 27 Open multiple curves: File -> Target SOR File -> Open Hide: hide the currently selected curve; Reference: Select a curve as a reference, then test, the test curve can be compared and analyzed with the reference curve. Page | - 24 -...
  • Page 28 Loss Analysis Loss analysis: When calculating the loss of "Event 1" in the figure, the cursor sequence position is shown below. The 2-point method displays the distance and loss of the A-B cursor in real time; as shown on the left below. The 4-point method calculates the event loss in real time, and the LSA method calculates the A-B cursor loss in real time, as shown below.
  • Page 29 Slope Analysis: When calculating the decay of event 1 in the figure, the cursor order position is shown on the right. The 2-point method calculates the attenuation of the A-B cursor area in real time, and the LSA method calculates the attenuation of the A-B area in real time as shown on the right below.
  • Page 30 Reflectivity Analysis: When calculating the reflectivity of event 1 in the figure, the cursor sequence position is shown below. The distance and loss of the A-B cursor in real time using the 2-point method as shown on the left below. The 3-point method calculates the reflectivity of the measured event in real time, as shown below.
  • Page 31 Return Loss Analysis: Analyze the total return loss of the link under test and the return loss within the A-B cursor position, as shown below. Calculate the total return loss of the link and the return loss within the 2- points of the A-B cursor, as shown below. Page | - 28 -...
  • Page 32 （ （ （ （ 5） ） ） ） Save ① Save File: Curve Operation -> Save -> Save File Step 1: Set the name and save parameters, select the storage path. Step 2: Confirm to save. Curve Operation -> Save -> Save File -> Save Settings Save setting is used to set the SOR file save content such as fiber identification, cable identification, cable code, location and project type, project code, company name, operator, direction, etc.
  • Page 33 ②To generate a PDF test report: Curve Operation -> Save -> Save PDF Step 1: Set the name and save parameters, select the storage path. Step 2: Confirm to save. Curve Operation -> Save -> Save PDF -> Save Settings Save settings are used to set the test information included in the generated PDF report. Page | - 30 -...

  • Page 34: Event Map

    4.7 Event map (1） ） ） ） Test Step 1: Select the test wavelength, you can choose single wavelength or dual wavelength test mode; Step 2: Click Auto Test. After the test is completed, the test results are displayed in the event map and list. Click the corresponding wavelength to view the event list for each wavelength.
  • Page 35 （ （ （ （ 2） ） ） ） File - file can open, delete, rename and copy （3） ） ） ） Save - Save test results on event maps as .emp files or the saved event map in .emp format. generate pdf test reports.
  • Page 36 （ （ （ （ 4） ） ） ） Settings ① Measurement seCngs; Set the refractive index, back-scatter coefficient, start fiber, end fiber and measurement unit. ②Analysis seCngs Set the reflection threshold, non-reflection threshold, and end threshold required for event analysis. Page | - 33 -...
  • Page 37 (3) Pass/Fail Pass/Fail is used to set the Pass/Fail function parameters, and can set the judgment thresholds of different wavelength average loss, total link loss, splice loss, connection loss, reflectivity and splitter loss. marked in the list. (4) General settings Set the display mode of auto save, prompt save, save name prefix,...

  • Page 38: Laser Source

    4.8 Laser source On the main interface, press the 【Light Source】 icon to enter the light source test interface. The wavelength of the light source function is consistent with the wavelength of the OTDR, and supports the output of continuous CW light and 270Hz, 1kHz, 2kHz modulated light.

  • Page 39: Vfl

    4.9 VFL The red-light function means that the wavelength of the visual fault locator is 650nm, and it supports constant light and 1Hz, 2Hz debugging light output. Step 1: Connect the VFL interface; Step 2: Click the constant light to turn on the red light function or pull down the status bar to switch the red light on and off through the shortcut...

  • Page 40: Opm

    4.10 OPM The optical power meter function displays the optical power value of the DUT in dBm and mW in real time, and automatically determines and displays the frequency of the DUT (power value >-20dBm) Step 1: Connect to the DUT, click Start; Step 2: Select the wavelength.

  • Page 41: Insertion Loss

    4.11 Insertion Loss The optical loss test function supports turning on the light source and the optical power meter at the same time, and is mainly used to measure the insertion loss of the DUT. Step 1: Click Start; Step 2: Use a short jumper to short-circuit the light source LS and the OPM port of the optical power meter,...

  • Page 42: Fiber Inspection (Optional)

    4.12 Fiber inspection End-face inspection enables real-time viewing of fiber connector cleanliness. Step 1: Connect the end face detection probe to the USB -A interface; Step 2: Click Start; Step 3: Connect to the DUT and check the cleanliness of the end face under test in real time.

  • Page 43: Ethernet Tools

    4.13 Ethernet Tools 1） ） ） ） Network tools ①PING Connect to Ethernet LAN2, enter the remote host IP in the PING test, and click Start. To determine whether the Ethernet physical link is successfully connected, the test result can be saved as a txt file. ②PPPOE Connect to Ethernet LAN2, enter the username and password in PPPOE, select the remote host, and click Start to determine whether the network can...
  • Page 44 ③IP Scan Connect the Ethernet LAN2, enter the start scan IP and end scan IP in the same IP segment, and scan the IP used in the IP segment. Page | - 41 -...
  • Page 45 (2） ） ） ） Link Tools ① Link speed(opKonal) The link test is used to test the speed performance between the physical links, routers, switches, photoelectric conversion devices, etc. of the two instruments, and supports a maximum speed test of 100Mbps. Step 1: Connect the DUT between the two instruments through the LAN2 interface;...
  • Page 46 ② RI45 Find (OpKonal) Step 1: Connect the tested network cable to the Ethernet port LAN2 and select the network cable channel; Step 2: Click Start; Step 3: Test with a separate line finder. ③ RJ45 Order (OpKonal) Step 1: Connect the network cable under test to the Ethernet interface LAN1;...

  • Page 47: Ethernet Remote

    ④ RJ45 length (OpKon) Step 1: Connect the network cable under test to the Ethernet interface LAN1; Step 2: Click Start. 4.14 Ethernet Remote The host computer is connected to the OTDR through Ethernet, and the software of the host computer realizes remote control such as parameter distribution, start-up test and graphic display.

  • Page 48: File Management

    4.15 File management System-level file management can open, delete, copy, rename and other internal files of local disks, external U disks, TF cards and other storage devices (files can be imported through the Type-C USB interface). The files in the local disk are stored and displayed according to functional modules.

  • Page 49: System Settings

    4.16 System settings （ （ （ （ 1） ） ） ） Backlight Set the backlight brightness and backlight sleep time. If there is no operation within the set time, the backlight will automatically turn down and recover after operation. （ （ （ （ 2） ） ） ） Date and time Set the date and time of the system, and click Save after modification.
  • Page 50 （ （ （ （ 3） ） ） ） Language Select the language of the system. （ （ （ （ 4） ） ） ） Power Options Set the automatic shutdown time of the OTDR. If no operation is performed within the set time, the OTDR will automatically shut down.

  • Page 51: Bluetooth Switch

    （ （ （ （ 5） ） ） ） Connect (For Bluetooth and APP connection operations, see Appendix II on the last page) The main connections are Type-C interface USB switch and Bluetooth switch. Turn on the Type-C USB switch, connect the OTDR to the computer through the data cable, and export or import the internal test files of the OTDR on the computer;...
  • Page 52 (9） ） ） ） Default APP Sets the default startup add-on when the OTDR is powered on. (10） ） ） ） Internet Set the internal IP address of the OTDR and other information, the IP is consistent with the Ethernet test and Ethernet remote. (11）...

  • Page 53: Analysis Software

    4.17 Analysis Software The OTDR analysis software is equipped in the U disk of the OTDR. Copy it to the computer. Double-click Open, click 【File】 -【Open】and select Trace Storage Directory to view all files in the directory. (1） ） ） ） Trace Analysis Open the selected file, analyze and operate the trace through the trace operation menu, and the event information...
  • Page 54 （ （ （ （ 2） ） ） ） Report Print Click on File -【BatPrint】to select the Trace Storage Directory to view all the files in the directory. Add the printed file to the printing area, determine the type of printing, and perform the printing operation.

  • Page 55: Common Problems And Solutions

    5. Common problems and Solutions 5.1 How to observe the optical pulse waveform? Pulsed light emitted by OTDR injects into different locations of the measured optical fiber links, which can cause loss, such as connection points, bends and end of the optical fiber.
  • Page 56 Splice loss: Due to the uneven density of the welded parts or the change of material quality, the increase of Rayleigh scattering loss results in the welding loss. Reflection of Connector: There is a small gap in the connecting part of the connector, and the group refractive index of the gap changes, so the reflection occurs and causes loss.
  • Page 57 （ （ （ （ 2） ） ） ） Curves Have Large Steps If there is an obvious "step" in the lower right figure, if this is the joint, it means that the joint is not qualified or that the bending radius of the optical fiber is too small or squeezed in the fused disc;...
  • Page 58 （ （ （ （ 5） ） ） ） Recognition and Processing of Mirage Peak (Ghost) Recognition of phantom peaks (ghosts): The ghosts on the curve do not cause obvious loss (such as the upper right figure); the distance between the ghosts and the beginning of the curve is a multiple of the distance between the strong reflection event and the beginning, which is symmetrical (such as the lower right figure).

  • Page 59: How To Clean The Optical Output Interface Of Otdr

    5.2 How to clean the optical output interface of OTDR? The optical output interface of OTDR series is replaceable universal interface, which must be kept clean during use. When the OTDR is unable to test the normal curve or the test results are inaccurate, the first consideration is to clean the optical interface of the OTDR.

  • Page 60: How To Print Test Trace In Batch

    Note: The file management of each function module can perform operations such as opening, copying, and deleting the file format saved by this function. In the file management of the system, operations such as copying and deleting files of all functional modules can be performed, but files such as SOR cannot be viewed.

  • Page 61: Other Common Faults And Treatment Methods

    5.6 Other common faults and treatment methods Page | - 58 -...
  • Page 62 The above description is for reference only. Please refer to the instructions for detailed usage. In the process of using the OTDR, if you have any questions, you can Contact Yamasaki Optical Technology to solve them. Page | - 59 -...

  • Page 63: Technical Specifications

    Page | - 60 -...
  • Page 64 Page | - 61 -...
  • Page 65 Page | - 62 -...
  • Page 66 Page | - 63 -...
  • Page 67 Page | - 64 -...

  • Page 68: Appendix I Ethernet Remote Operation

    7.Appendix I Ethernet Remote Operation Step 1: Connect the device to remote computer through the Ethernet LAN2 interface (modify the IP address in the system settings); Step 2: Select the Ethernet r emote test function and start the monitoring service; Step 3: Configure the TCP/IPv4 IP address of the host computer to be in the same segment as the device;...

  • Page 69: Appendix Ii App-Side Bluetooth Control Device

    8. Appendix II APP-side Bluetooth control device Please scan QI code to download the Bluetooth APP. Page | - 66 -...
  • Page 70 Step 1: Turn on Bluetooth in System Settings -> Connect “Bluetooth”, until display the Bluetooth MAC address Page | - 67 -...
  • Page 71 Step 2: On mobile phone APP, add a Bluetooth device, scan the corresponding MAC information, and then the connection is successful. Page | - 68 -...
  • Page 72 Step 3: The Bluetooth APP terminal can control the operation of the light source function, the optical power meter function (OPM) and the red-light function (VFL). Page | - 69 -...
  • Page 73 Step 4: The Bluetooth APP terminal operates the OTDR function, sets the test parameters, starts the test and checks the test results; Page | - 70 -...
  • Page 74 Step 5: Transmission and sharing test results. Page | - 71 -...
