- Page 1 07-04-2023 Installation instruction HALMSTAD www.sunshade-experts.com service@sunshade-experts.com...
-
Page 2: Tools Required For Installation
Elements of the awning side covers cassette arms front bar fabric Tools required for installation hammer drill Spanners for M and M screws* tape measure hammer level * Attention! For installation, screws suitable for the surface (brick wall, concrete, etc.) and with suf cient load-bearing capacity can be used. - Page 3 Measurements and installation Measure the distance between the marks on the wall or on the ceiling (when mounting there). The distance between marks depends on the width of the awning and the number of arms. 33,5 26,5 In case of wall mounting, mount the brackets at the desired height in the previously measured distances. In the case of walls with a weak structure, wall brackets should be installed at a previously measured distance.
- Page 4 Screw in the upper xing screws ( ), hang the cassette on, lower it ( ) and tighten the lower xing screws. Lightly tighten all screws ( ). With the help of a second person, support the cassette in the center section to eliminate the de ection under the weight ( ).
- Page 5 Open the awning using a remote control or a wall switch. position of inclination angle adjustment front bar position of inclination angle adjustment Tighten the locking screw on each of the arms with a spanner. locking screw Lowering the arms. Drive in the adjusting screw with a spanner to obtain the desired position.
- Page 6 Podnoszenie ramion Adjusting the arms' lift. In order to set the angle of sliding the front bar, adjust the screw. screw for adjusting the angle of inclination Repeat the procedure for each arm. Po ustawieniu żądanego kąta pochylenia markizy, sprawdzić wypoziomowanie belki przedniej. After setting the desired angle of inclination of the awning, check the leveling of the front bar.
- Page 7 After closing the awning, check the alignment of the front bar. It should close tightly and evenly. Loosen the locking screws on the ends of both arms. Adjust the position of the front bar and tighten the locking screws securely. Close the awning to check the position of the front bar. Repeat the adjustment if necessary.
- Page 8 www.sunshade-experts.com service@sunshade-experts.com...
