- Page 1 en 12-04-2021 Technical Manual EBELTOFT www.sunshade-experts.com service@sunshade-experts.com...
-
Page 3: Descriptive Specifications
With its reduced dimensions, it represents an ideal new model for large installations and requires minimal installation time at the selected location. 2. DESCRIPTION OF THE SYSTEM The advanced technology applied to the Sunshade Experts system provides a series of advantages, which guarantee maximum performance from the awning: Improved durability ... - Page 4 MONOBLOC - Descriptive specifications o ś o ś ( ś o ż d ł y ć u ż e ż a ż The acrylic or high-tech fabric offers superior sun protection, and extends and retracts by rolling onto a steel tube. This tube is held in place by the side brackets, which are in turn attached to the 40x40 millimetre square bar using a clamp system and tightened allen-head bolts.
-
Page 5: Final Considerations
Descriptive memory *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności IMPORTANT: By changing the cover set of the ART 350 arm bracket, by the covers of the Splendor 300 arm bracket, we can make a Monobloc with SPLENDOR 300 arms (this change is not needed with the Splendor 400 arms). -
Page 6: Component Specifications
MONOBLOC - Discriptive specifications o ś o ś ( ś o ż d ł y ć u ż e ż a ż 5. COMPONENT SPECIFICATIONS GEOMETRIC PROPERTIES Geometry Section (mm2) Mt (cm4) Structure Components Ixx = 10.19 Iyy = 10.19 40x40 support profile Ixx = 28.71 Iyy = 18.84 Front EVO - 80 profile... -
Page 7: Description Du Produit
Description du produit *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności 1. GENERAL CHARACTERISTICS The ART-350 awning with the monobloc system essentially owes its creation to the need to provide a solu-tion for sun protection on large-scale installations. It allows all its components to be mounted on a square bar, which makes this model an agile, efficient, and simple solution for positioning multiple suspension brackets to anchor the self-bearing system. - Page 8 MONOBLOC - Cutting, selection, and classification tables o ś o ś ( ś o ż d ł y ć u ż e ż a ż ANGLE OF INCLINATION WALL CEILING 0º to 90º 0º to 90º MAXIMUM WIDTHS BASED ON PROJECTION ARM PROJECTION (m) 2 ARMS 3 ARMS...
-
Page 9: Cutting, Selection, And Classification Tables
Monobloc *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności Cutting, selection, and classification tables MINIMUM WIDTH (m) NUMBER OF ARMS CROSSED ARMS PROJECTION MINIMUM MINIMUM MINIMUM Maximum inclination 45º 4 BRACKETS 6 BRACKETS 8 BRACKETS 1,50... - Page 10 MONOBLOC ART-350 Number of brackets for square bar (when using two arms) Projection (m) Width Number of brackets for square bar (when using threearms) Projection Width Number of brackets for square bar (when using four arms) Projection Width Number of brackets for square bar (when using six arms) Projection Width www.sunshade-experts.com...
-
Page 11: Bracket Dimensions
Sections délimitées *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności Nº of ROLLER SUPPORTS From 5,50 m to 8,00 m width 1 roller From 8,01 m to 11,00 m width 2 rollers From 11,01 m to 14,00 m width 3 rollers From 14,01 m to 16,00 m width... -
Page 12: Mounting The Brackets
Assembly instructions o ś o ś ( ś o ż d ł y ć u ż e ż a ż 1. MOUNTING THE BRACKETS Mount the brackets (wall or ceiling), then ensure they are well anchored to the surface and check their alignment. For proper installation, first determine the number of brackets to use, in accordance with the diagram and the indications specified on page 10 of this manual. - Page 13 Assembly instructions *uwaga! do montażu należy użyć kotew odpowiednich dla podłoża (ściana ceglana, betonowa itp.) i o odpowiedniej nośności Position the other bracket on the opposite side, either with the gearbox or with the HiPro bracket for attaching the appropriate motor (see motor selection table, based upon measurements).
- Page 14 Assembly instructions o ś o ś ( ś o ż d ł y ć u ż e ż a ż 4. INSTALLING THE ROLLING TUBE AND FABRIC Insert the fabric into the slot on the rolling tube as well as the one on the EVO front profile.
-
Page 15: Final Adjustment
The ability to adjust the tightness of the allen bolts is one of the characteristics of Sunshade Experts products that makes adjusting the awning considerably easier after it has been installed. - Page 16 Assembly instructions o ś o ś ( ś o ż d ł y ć u ż e ż a ż Once everything has been tightened, open the awning about 200-300 millimetres and check the alignment of the arm joints. If they are not correctly aligned, loosen the bolts again with the awning remaining open and adjust the position of the arm end, so that the two joints are aligned.
- Page 18 www.sunshade-experts.com...
