Installation/Service Manual
for use by heating contractor
Vitogas 050
ECD-S Series
Natural gas-/propane-fired
atmospheric cast iron boiler
Heating input
65 to 200 MBH
19 to 59 kW
VITOGAS 050
IMPORTANT
Re
Read and save these instructions
fo
for future reference
5285 735 v1.2 10/2007
Do not store or use gasoline or other
flammable liquids in the vicinity of this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS
g
g
g
g
Installation and service must be
.
performed by a qualified installer,
service agency or the gas supplier.
WARNING
If the information in this manual is not followed
exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
Do not try to light any appliances.
Do not touch any electrical switches,
do not use any phone in your building.
Immediately call your gas supplier
from a neighbor's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
WARNING
Should overheating occur or the gas supply fail
to shut off, do not disconnect the electrical supply
to the pump. Instead, shut off the gas supply at
a location external to the appliance.
Advertisement
Table of Contents
Related Manuals for Viessmann Vitogas 050 ECD-S Series
Summary of Contents for Viessmann Vitogas 050 ECD-S Series
- Page 1 Installation/Service Manual for use by heating contractor Vitogas 050 ECD-S Series Natural gas-/propane-fired atmospheric cast iron boiler Heating input 65 to 200 MBH 19 to 59 kW VITOGAS 050 WARNING If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
- Page 2 Safety Safety This symbol is located beside all important safety WARNING recommendations. Please follow the instructions in detail to avoid property damage, severe personal Before each heating season begins, have the following injury, or loss of life. service and maintenance done by a professional service technician: WARNING Boiler heat exchanger inspected and cleaned.
- Page 3 Safety Safety (continued) Hazardous materials Fiberglass wool and ceramic fiber materials The state of California has listed the air-borne fibers of these WARNING materials as a possible cancer hazard through inhalation. When handling these materials, special care must be applied. Appliance materials of construction, products of combustion and the fuel contain alumina, silica, heavy metals, carbon monoxide, nitrogen oxides, aldehydes...
-
Page 4: Technical Data
Installation Technical Data Vitogas 050, ECD-S Series Technical Data Cut-away view Left View Front View (left side) Boiler electrical requirements are 120V, 60 Hz, less than 12A Max. pump amperage is 4A. Use field supplied relay for pumps over 4A. Model CSA input DOE heating... - Page 5 The ECD-S Series boiler is for use in closed-loop forced Please reference the Viessmann Price List. circulation hot water heating systems only. Boiler operation is limited by ASME Code to maximum water pressure of 50 psig Typical boiler piping is shown in Fig.
- Page 6 Installation Closet/alcove If the vent damper becomes defective: 1. Follow the vent damper manufacturer’s instructions to leave the vent damper in the “Service” mode by using Molex the service switch on the damper motor. Vent damper connector blade should stay open and boiler should operate normally. Closet/alcove installation Models ECD-S (65–155) are approved for closet installation with the clearances shown in Fig.1.
-
Page 7: Combustion Air Supply
Installation Combustion air supply Provisions for combustion and ventilation air must be made in accordance with section 5.3, Air for Combustion and Ventilation, of the National Fuel Gas Code, ANSI Z223.1 (latest edition) or applicable provisions of the local codes. In Canada follow CAN/CSA-B149.1 or .2 Natural Gas Installation Codes (latest edition) for combustion and ventilation air requirements. - Page 8 Viessmann recommends above items 1-8 for all installations, even in buildings without airtight construction. 5. If windows or doors are used for combustion air openings, they must be locked open.
- Page 9 No isolation valve must be installed between boiler have the non-oxygen diffusion barrier tubing separated from supply and pressure relief valve. Install pressure relief valve the boiler with a heat exchanger. Viessmann recommends as shown in Fig. 4. the use of underfloor plastic tubing with an oxygen diffusion barrier.
- Page 10 Transformer/Relay or other operating control. It is located behind the front access input Viessmann panel. Honeywell L4008A aquastat or equivalent may be used. Ensure sensing bulb is fully inserted in well, see Fig. 4c. Never permanently bypass high limit aquastats. Additional 120V pump temperature limit controls may be required by local authorities.
-
Page 11: System Fill
Installation System fill 1. Install full size bypass as shown below. Heating/ Cooling unit 2. Use valve in bypass and valve in supply line to balance flow so that boiler water temperature quickly reaches 140°F or higher. Use globe valve or ball valve. Heating/ Cooling unit 3. -
Page 12: Boiler Venting
Installation Boiler venting 4. Place in operation the appliance being inspected. Follow Avoid long horizontal runs of vent pipe. Horizontal runs must the lighting instructions. Adjust thermostat so appliance be supported by appropriate means to prevent sagging, and will operate continuously. should have not less than a”... -
Page 13: Gas Piping
Installation Gas piping CAUTION Discharge piping of pressure relief valve must be installed so there will be no danger of scalding personnel. Ground joint union Boiler is standard equipped with 30 psig ASME-rated pressure relief valve. This 30 psig pressure relief valve may be exchanged at the job site with a 50 psig ASME-rated pressure relief valve only by strictly observing the minimum relief valve capacity in lb/h marked on the nameplate. -
Page 14: Main Burner
Installation Main burner Flame roll-out CAUTION switch For ECD-S boiler with Honeywell intermittent pilot (spark) ignition the main burner for mounting the Q3451A pilot Burner 13 mm assembly contains one less group of main burner ports (5). tubes socket If the burners are disassembled or replaced for any reason Manifold they must be reassembled as shown in Figs. - Page 15 See wiring diagram in rear of manual and wiring label on boiler. Viessmann reserves the right to substitute electrical components as necessary. The boiler wiring label takes precedence.
- Page 16 Installation Shut-down Advise the operator/ultimate owner Honeywell 1. Of the proper system operation sequence. Chronotherm 2. Explain the equipment as well as the need for electronic set-back combustion air. room thermostat 3. Demonstrate an emergency shut-down, what to do and what not.
-
Page 17: Maintenance
Service Maintenance Boiler servicing – heat exchanger cleaning Diagonal brush application A service/inspection of the boiler and the system is mandatory once a year. Before heating season starts, boiler/burner should be serviced by a qualified service agency. The owner should establish a service contract with a qualified service agency. - Page 18 VR8304P3308 (ECD-S 200) Ignition Control S8600H3002 S8600H3002 Pilot Burner *1 Q3451A2012 Q3451A2012 Pilot Orifice .020 inches dia. .014 inches dia. 390686-4 390696-24 BCR 20 BBR 14 *1 Pilot burner has ignition cable permanently attached. Consult your Viessmann representative for parts replacement.
-
Page 19: Terminal Strip
Service Troubleshooting - Vent Damper 24VAC power Power On Damper Position 4 & 1 All times Open or closed 4 & 2 Calling for heat Open or opening 4 & 3 During combustion Damper open COUNTER MOLEX CONNECTOR FEMALE BLK 4 3 YEL 1 BRN ORG 2... -
Page 20: For Your Safety Read Before Operating
Service Lighting Instructions for Intermittent Pilot (Spark to Pilot) FOR YOUR SAFETY READ BEFORE OPERATING W A R N I N G: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. - Page 21 Service Wiring...
- Page 22 Service Wiring (continued) Vitogas 050, ECD-S Series with Honeywell intermittent pilot and vent damper-ladder diagram LEGEND PA - Pump Aquastst (104 SHL - Adjustable Aquastat High Limit (240 F - Field Supplied BVS - Blocked Vent Switch (235 FRS - Flame Roll Out Switch (140...
- Page 23 Service Parts Vitogas 050, ECD-S Series Cast-Iron Atmospheric Gas-Fired (exploded view example of: ECD-S 140 / ECD-S 155) Inspection opening for heat exchanger Note: Ref. No. 19 not shown, as only applicable to ECD-S 180 / ECD-S 200 Note: Ref. No. 35 is at a different location for the ECD-S 180 / ECD-S 200...
- Page 24 Service Parts (continued) Ref. # Part Name Part No. ECD-S ECD-S ECD-S ECD-S ECD-S ECD-S ECD-S ECD-S Left Panel 9544 200 9544 201 Right Panel 9544 202 9544 203 Back Panel 9544 204 9544 205 9544 206 9544 207 Top Panel 9544 208 9544 209 9544 210...
- Page 25 Service Parts (continued) Ref. Part Name Part No. ECD-S ECD-S ECD-S ECD-S ECD-S ECD-S ECD-S ECD-S Section - 9507 593 right side* Section - 9507 592 left side* Section - 9507 596 intermediate* Section - int. 9507 595 with pilot opening on right* Section - int.
- Page 26 Service Parts (continued) Ref. # Part Name Part No. ECD-S ECD-S ECD-S ECD-S ECD-S ECD-S ECD-S ECD-S Pilot Bracket for 9543 384 Q3451A Safety High Limit 9543 875 Control Pump Aquastat 9519 214 Support Bracket upper 9543 731 lower 9543 732 Insulation Steel Cover left side...
- Page 27 5285 735 v1.2 Year Service Contractor Clean Boiler Check for proper supply Vent system inspected for soot, Burner serviced and (name, phone number) of combustion air leaks, deterioration, proper draft, combustion test adherence to codes, blockage* performed *Any defects, blockages, etc. in vent system must be corrected to ensure safe operation. Inspect draft hood for corrosion, replace if necessary. Cast iron heat exchanger must be kept clean for safe operation.
- Page 28 Viessmann Manufacturing Company (U.S.) Inc. Viessmann Manufacturing Company Inc. 45 Access Road 750 McMurray Road Warwick, Rhode Island · 02886 · USA Waterloo, Ontario · N2V 2G5 · Canada 1-800-288-0667 · Fax (401) 732-0590 1-800-387-7373 · Fax (519) 885-0887 www.viessmann-us.com · info@viessmann-us.com...
