OWNER'S MANUAL
Patio Heater
Model: HIL-GR15Y
ATTACH YOUR RECEIPT HERE
Serial Number:
Purchase Date:
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-888-775-1330,7 a.m.- 4 p.m., Monday –
Friday or email our warranty department at warranty@azpatioheaters.com.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HIL-GR15Y and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AZ Patio Heaters HIL-GR15Y

Summary of Contents for AZ Patio Heaters HIL-GR15Y

  • Page 1 OWNER’S MANUAL Patio Heater Model: HIL-GR15Y ATTACH YOUR RECEIPT HERE Serial Number: Purchase Date: Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-775-1330,7 a.m.- 4 p.m., Monday – Friday or email our warranty department at warranty@azpatioheaters.com.

  • Page 2: Safety Warning

    Thank you for purchasing the new remote infrared heater. These operating instructions will help you use it correctly and safely. We recommend that you take some time to read this instruction manual so that you can fully understand all the operating functions it provides. Please read all safety instructions carefully before use, and keep this manual for future reference.
  • Page 3 -Do not try to repair or adjust any electrical or mechanical functions on this device. The device does not contain any user-serviceable parts. Only qualified electricians can carry out maintenance or repair. Trying to repair the equipment yourself will void your warranty.
  • Page 4 -To disconnect the heater, turn off the main switch and then unplug the plug from the socket. Do not unplug the plug by pulling the power cord. Do not unplug the heater before turning the main switch to the off position. -Before moving, cleaning or storing, always unplug the equipment and ensure that it is completely cooled.
  • Page 5 Installation instructions for the fireproof bracket Install the bracket on the product as shown and secure with included screws Product operating instructions Product overview: ① Control knob ② Handle ③ Remote control receiver ④ Protective net ⑤ Power cord ⑥ ON/OFF switch ⑦...
  • Page 6 4. Press the knob switch lightly in the heating mode of the machine, and all the indicators will turn green, indicating that the heater is in timer mode. It can be set for 8 hours in total, and each green light represents one hour. After stopping any operation, it will revert back to the power mode.

  • Page 7: Maintenance And Cleaning

    Note: computer heater gear division Model HIL-GR15Y P1(W) 187.5WW P2(W) 375W P3(W) 562.5W P4(W) 750W P5(W) 937.5W P6(W) 1125W P7(W) 1312.5W P8(W) 1500W Timing (h) eight Maintenance and cleaning It is necessary to regularly and carefully maintain the infrared heater to realize the long-term and efficient operation of the equipment.
  • Page 8 Check more often if in a dusty area. When cleaning the equipment, visually inspect for the deformation of mirrors, wires and frames. If there is any deformation, please consult a qualified technician. When cleaning the equipment, visually check the power cord and plug. If there is any deformation, please consult a qualified technician.

  • Page 9: Limited Warranty

    For all warranty issues, please call the warranty department at 1-888-775-1330. LIMITED WARRANTY AZ Patio Heater, LLC (“Vendor”) warrants to the original retail purchaser of this heater to no other person, that if this heater is assembled and operated in accordance with the printed instructions accompanying it, then for a period of one year from the date of purchase, all parts in such heater shall be free from defects in manufacturing and workmanship.
  • Page 10 Vendor does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment, and no such representations are binding on vendor. For warranty service, please contact warranty@azpatioheaters.com or call us toll free at 888- 775-1330.
