- Page 1 PMSM Industrial Ceiling Fan Operation and maintenance manual...
-
Page 2: Table Of Contents
Catalog Foreword ..................1 1.Product introduction ............... 1 1.1Product Specifications ..........1 2.Parts List .................. 2 3.Fan installation ................ 4 3.1 Installation forms .............4 3.2Fan installation steps ............5 Step 1: Install the motor bracket 3.2.1 ........8 Step 2:Install the ceiling bracket and extension rod 3.2.2 Step 3:Install the motor 3.2.3... -
Page 3: Foreword
Foreword First of all, thank you for purchasing the geared motor industrial ceiling fan developed by our company! Large permanent magnet silent industrial energy-saving fan can produce the best three-dimensional natural wind effect for the human body, with a large coverage area and soft wind. -
Page 4: Product Specifications
1.1Product Specifications Spec. 6.1m 7.3m Model YZ-30B-6 YZ-42B-6 YZ-50B-6 YD-61-6 YD-73B-6 6500m³/min 9200m³/min 9900m³/min 11000m³/min 13000m³/min volume Max speed 100r/min 85r/min 70r/min 60r/min 52r/min weight 40kg 51kg 55kg 90kg 100kg Voltage/P 220V 0.4KW 220V 0.55KW 220V 0.75KW 220V 0.95KW 380V 1.5KW... -
Page 5: Fan Parts List
2. Fan Parts List Description Sets Picture Ceiling bracket Pressing plate extension rod Motor connection bracket Ceiling Motor Blades fan blade connector... - Page 6 Turntable Steel wire rope Steel wire tensioner Electric control box electric Cable、 threading pipe screws Before installation, check whether there are any missing accessories and quantities against the parts list。...
-
Page 7: Fan Installation
3.Fan installation Three common types of installation I-beam structure 3.1.1 I-beam high strength bolts Pressing plate Ceiling bracket Square tube, round tube and other structures 3.1.2 High strength bolts and screws（The length is customized Press plate or according to the square tube） angle steel Square tube, round tube, etc. -
Page 8: Fan Installation Steps
Fan installation steps 3.2.1 Step 1: Installing the Motor Bracket 1.Insert motor connection bracket into the motor shaft to align the two screw holes, and then thread two M14 bolts. Be careful not to damage the electrical wires inside motor shaft when threading the bolts... -
Page 9: Step 1: Install The Motor Bracket
3.2.3 Step 3:Install the motor Align the holes of the motor bracket with the two mounting holes at the lower part of the extension rod, and use 2pcs M12 bolts to fix them. 3.2.4 Step 4: Install the steel wire rope Hang the 4pcs steel wire tensioners into the 4 ring holes of the ceiling fan... -
Page 10: Step 5: Adjust The Balance
Connect the other ends of the 4 steel wire ropes to the top of the workshop (suitable fixing place), and the 4 steel wire ropes are evenly distributed in 4 directions. Each steel wire rope connection must be locked by 2pcs wire buckles 3.2.5 Step 5: Adjust the balance Stick the level ruler on the bottom... -
Page 11: Step 6:Install The Fan Blades
3.2.6 Step 6:Install the fan blades 1.Use M8 bolts to connect the fan blade and the fan connecting piece, as shown in the figure below, and then tighten the bolts。 Using M8 screws.Fan connecting pieces installed alternately up and down(Note: The straight hole is at the bottom and the circular hole is at the top) As shown in the figure... -
Page 12: Step 7: Connect The Power Supply
3.2.7 Step 7: Connect the power supply Power Motor input output line(L 、 line（U、 N、PE) V、W） The motor output line Power input 220V （U、V、W） line（L1、L2）/380V Power input line（R、 Connect ground S、T） （PE） Looking from bottom to top, it is correct that the motor rotates counterclockwise. -
Page 13: Control Panel
4.Control panel The actual situation of the fan live surveillance Fan start/stop button speed adjustment knob Workshop Motor output power input line（U、X、W） line（L、N、PE）... -
Page 14: Operating Instructions
5. Safe Operating Instructions Before operating the equipment, please read the product instructions carefully, and remove obstacles in the operating area to ensure that the fan runs at a safe distance. Warning: Before doing any electrical and fan maintenance, be sure to turn off the power and have it operated by a professional to avoid being injured by the power supply. -
Page 15: Safety Precautions
6.Safety Precautions Prohibit Do not bend the fan blades when installing, adjusting or cleaning the fan, otherwise it will damage the fan or affect the use of the fan. Before turning on the power, please confirm whether the input voltage of the fan is consistent with the power supply voltage. - Page 16 It is strictly forbidden to operate the fan when the safe space is insufficient. Warning When the fan is running, do not cut off the power supply, otherwise the gearbox of the reducer will be damaged, and the power supply should be cut off when the fan is completely stopped.
- Page 17 7.Fault diagnosis and its solutions Fault display Fault reason Solutions 1. Power grid low 1.Check the input power voltage source Under voltage 2. power line phase 2.Check the power line voltage loss 1.Check the input power 1.Power supply Over Voltage abnormal source 1.
- Page 18 cables between phases. 1.Check motor coil for short 1.Short circuit circuit short circuit between inverter and 2.Check if the motor input motor wiring power is shorted 3.Seek manufacturer service Fan low speed 1.The motor wire is 1.Check that each connection jitter not connected point is securely connected...
-
Page 19: Repair And Maintenance
8.Repair and Maintenance Our product design is maintenance-free, but in order to ensure the long life of the fan and the normal operation of the fan, the fan should also be maintained, especially for applications in harsh environments, for any maintenance of the fan or variable controller,always ensure that the fans are stopped and the controller is powered off to protect personnel.
