2. Hardware Installation

1. Attach the mounting stand to the

side of the unit.

2. Connect one end of the yellow RJ-

45 cable to one of the

TEW-435BRM's LAN ports.

Connect the other end of cable to

the computer's Ethernet port. Then

connect the 2dBi detachable

antenna.

3. Connect one end of the gray RJ-11

cable to the TEW-435BRM's ADSL

port. Connect the other end of the

cable to the phone jack.

4. Connect the AC Power Adapter to

the TEW-435BRM and then to a

power outlet.

5. Verify that the following panel lights

are on: Power, LAN, and WLAN.
