- Page 1 FP-90 Digital Piano...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 26.04.2024, ID: 551909...
-
Page 3: Table Of Contents
Table of contents Table of contents General information......................4 1.1 Symbols and signal words................... 4 Safety instructions......................... 5 Features............................7 Installation..........................8 Connection options......................10 Connections and controls....................12 Operation..........................13 7.1 Turning on / off......................13 7.2 Automatic shutoff......................13 7.3 Adjusting the volume.................... -
Page 4: General Information
Our products and documentation are subject to a process of continuous develop‐ ment. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. -
Page 5: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended to be used for electronic sound generation using a piano key‐ board. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in per‐ sonal injury or property damage. - Page 6 Safety instructions NOTICE! Possible staining due to plasticiser in rubber feet! The plasticiser contained in the rubber feet of this product may react with the coating of the floor and cause permanent dark stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the floor.
-
Page 7: Features
Features Features The digital piano offers the following features: 88 buttons with touch velocity Digital display 128 sounds 128 rhythms 20 songs 32-voice polyphony Record and playback function Tempo control Dual mode Learning mode Bluetooth® audio/MIDI Integrated metronome Automatic shutoff Operation via 5 V plug-in power supply (not contained in the scope of delivery) or built-in battery Operating system: Windows®... -
Page 8: Installation
Installation Installation The device can be operated via a 5 V plug-in power supply (not contained in the scope of delivery). Connect the cable of the 5 V plug-in power supply to the [USB] USB connection on the back of the device and connect the 5 V plug-in power supply to the power supply. - Page 9 Installation Standby operation The device automatically switches to standby mode if you do not press any of the buttons for about ten minutes. To return to the normal operating mode, switch the device on again. FP-90 Digital Piano...
-
Page 10: Connection Options
Connection options Connection options Headphones The headphone output is located on the back of the device. If you connect headphones (not included in the scope of delivery) to the headphone output, this switches off the speakers. WARNING! Possible hearing damage due to high volumes on headphones! The use of headphones at high volumes may result in permanent hearing impairment. - Page 11 Connection options Use a current operating system still supported by the provider to avoid tech‐ nical difficulties. Pedal The [SUS] input for connecting a sustain pedal (not included in the scope of delivery) is located on the back of the device. With the sustain pedal all played notes sound longer.
-
Page 12: Connections And Controls
Connections and controls Connections and controls ö & 1 Display 2 [–/+] | Volume control for the built-in speakers and connected headphones. Press [–/+] to enter the settings menu. Then turn [–/+] to make the desired settings. Confirm the setting by pressing [–/+] again. -
Page 13: Operation
Operation Operation 7.1 Turning on / off To switch the device on and off, press and hold the main switch for one second. If you do not hear anything from the speakers, the volume may be set to "minimum". To increase the volume, turn the volume knob clockwise 7.2 Automatic shutoff If the device is not used for ten minutes, it switches off automatically. -
Page 14: Selecting And Playing Songs
Operation The sound list is available for download on the product page at www.thomann.de. Press [Tone] to activate the selection. ð The display shows the first sound. Turn [–/+] to select a desired sound. Wait three seconds without pressing a button to exit the menu. -
Page 15: Recording
Operation Turn [–/+] to change the time signature. Press [Metronome] again to switch off the metronome. Wait three seconds without pressing a button to exit the menu. 7.8 Recording Hold down hold [REC/Play] for one second to start recording mode. The recording starts with the first keystroke. -
Page 16: Dual Mode
Operation 7.11 Dual mode Press [–/+] to enter the settings menu. Turn [–/+] until the display shows ‘DKeyboard’ . Press [–/+] to confirm the selection. Turn [–/+] and choose between ‘On’ (dual mode enabled) and ‘Off’ (dual mode disabled). Wait three seconds without pressing a button to exit the settings menu. 7.12 Learning mode When practising, it is mainly important to play the right notes at the right time. -
Page 17: Vibrato Effect
Operation 7.14 Vibrato effect When the vibrato effect is activated, all sounds played on the device are changed in height by a frequency that has been changed several times. Press [–/+] to enter the settings menu. Turn [–/+] until the display shows ‘Vibrato’ . Press [–/+] to confirm the selection. -
Page 18: Bluetooth® Audio
Operation The Bluetooth® connection is activated by default. Switch on the device and the mobile device. Activate the Bluetooth® connection on your mobile device. Open the app on your mobile device and pair it with the ‘GZUT-MIDI’ device. ð You can now control the device from your mobile device. 7.17.2 Bluetooth®... -
Page 19: Troubleshooting
To prevent this, switch off the mobile phone or use it only at a sufficient distance. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. FP-90 Digital Piano... -
Page 20: Technical Specifications
Technical specifications Technical specifications Input connections Power supply / USB interface 1 × USB-C Microphone 1 × 3.5-mm jack socket Sustain pedal 1 × 6.35-mm jack socket AUX IN 1 × 3.5 mm jack socket Output connections Headphones 1 × 3.5-mm jack socket Keyboard 88 buttons with touch velocity Polyphony... - Page 21 Technical specifications Dimensions (W × H × D) 1,234 mm × 62 mm × 218 mm (unfolded) 660 mm × 150 mm × 218 mm (folded) Weight 4.1 kg Colour black Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) Further information Surface...
-
Page 22: Protecting The Environment
You can also return your old device to Tho‐ mann GmbH at no charge. Check the current conditions on www.thomann.de. Proper disposal protects the environment as well as the health of your fellow human beings. - Page 24 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
