Table of Contents SAFETY INSTRUCTIONS ..................3 Symbols used ........................3 Electrical safety ........................3 Dangers to eyes, breathing and skin ..................3 INSTALLATION ...................... 4 The need for fume extraction ....................4 Extractor Installation Procedure ................... 4 Single phase units – Electrical supply connection ..............6 OPERATION ......................
SAFETY INSTRUCTIONS Symbols used Danger Refers to an immediately impending danger. If the danger is not avoided, it could result in death or severe (crippling) injury. Warning Refers to a possibly dangerous situation. If it is not avoided, it could result in death or severe injury Caution Refers to a possibly harmful situation.
INSTALLATION The need for fume extraction Soldering activities take many forms, but in most operations flux must be used to clean the component surfaces and help the molten solder to flow. This helps to ensure a good mechanical/electrical joint between the components. The temperature required to melt the solder causes the flux to vaporise, producing solder fume.
Page 5
The V600 unit is supplied with a length of 50mm flexible hose to be connected between the extraction unit and the fumeCAB 600. Typical installation shown below. Fig 1...
Single phase units – Electrical supply connection Check the integrity of the electrical power cable. Connect the power cable to an isolated electrical supply. The mains socket outlet should be installed near the equipment and be easily accessible. The cable run to the machine should be arranged so as not to create a trip hazard.
OPERATION On/Off switch This extraction unit is turned on and off by using the switch on the front or rear of the unit. Single LED Filter condition indication An LED on the front panel of the machine will illuminate when the filters need attention.
MAINTENANCE It is a legal requirement, under regulation 9, of the COSHH regulations that all local exhaust ventilation systems are visually inspected on a weekly basis, where possible and undergo a thorough inspection and test on an annual basis. COSHH requires the annual inspection and testing to be carried out by a competent person with specific documentation of the results held in a log book.
Page 9
Filter replacement indication The first few filter changes should only apply to the pre-filter. The indication that the Combined or Gas / HEPA filter needs replacing is when the filter alarm signal and LED’s (if fitted) do not go off after the pre filter has been changed. Please note that the carbon media within the combined filter or Gas filter is hygroscopic and will absorb moisture from the atmosphere.
Consumable Spares Unit Part Number Description V600 A1030118 Combined filter A1030119 Pre filter Fuses The following table gives details of the internal fuses in the Volume units: Item Protected Voltage Fuse Rating A FLC A Fuse Type V600 Exhaust Fan 100-230V 0.1A T1AH250V...
TROUBLE SHOOTING In the unlikely event of a problem with your extractor please contact your local representative. BOFA International Ltd 19-20 Balena Close, Creekmoor Industrial Estate, Poole, Dorset BH17 7DX, UK Tel: +44 (0)1202 699444 Email: technical@bofa.co.uk Website: www.bofainternational.com BOFA Americas, Inc 303 S.
