Routing - TP-Link TD-W150KIT User Manual

TD-W8951ND
Firewall: Select this option can automatically detect and block Denial of Service (DoS)
attacks, such as Ping of Death, SYN Flood, Port Scan and Land Attack.
SPI: If you enable SPI, all traffics initiated from WAN would be blocked, including DMZ, Virtual
Server, and ACL WAN side.

4.4.2 Routing

Choose "Advanced Setup→Routing" menu, and you will see the routing information in the next
screen (shown in Figure 4-26).
Click ADD ROUTE button to add a new route in the next screen (shown in Figure 4-27).
Destination IP Address: This parameter specifies the IP network address of the final
destination.
150Mbps Wireless N ADSL2+ Modem Router User Guide
Figure 4-25
Figure 4-26
Figure 4-27
41
