- Page 1 Mitsubishi Programmable Controller MELSEC-FX Series FX3U-16MCPU (RS-232 Connection) Sample Screen Manual Mitsubishi Electric Corporation...
- Page 2 Using the Samples The sample screen data and files such as the instruction manual can be used upon agreement to the following matters. (1) This data is available for use by customers currently using or considering use of Mitsubishi products. (2) The intellectual property rights of the files provided by Mitsubishi (hereinafter referred to as the “Files”) belong to Mitsubishi.
-
Page 3: Table Of Contents
CONTENTS REVISIONS ..................................4 OUTLINE .................................5 SYSTEM CONFIGURATION ..........................5 Device Monitor Range .............................5 GOT ..................................5 Required System Applications .........................5 Controller Setting of Screen Design Software ....................5 Overlap Window Setting of Screen Design Software ..................5 SCREEN SPECIFICATIONS ..........................6 Display Language ............................6 Screen List/Transition ............................6 Explanation of Screens ............................8 4.3.1 Menu (B-30001) ............................8... -
Page 4: Revisions
REVISIONS Sample Screen Manual Date Control No.* Description 2015/1 BCN-P5999-0454 First edition * The Control No. is noted at the lower right of each page. Project Data Date Project data Description Designer3* 2015/1 GS21_MITSUBISHI_FXCPU-RS232_V_Ver1_E.GTX 1.126G First edition * The version number of screen design software used to create the project data is listed. Please use the screen design software with the listed version or later. -
Page 5: Outline
1. OUTLINE This manual explains the sample screens of GS series connected to a MELSEC-FX Series PLC (FX3U-16MCPU) in serial (RS-232) communication. The sample screens are created for using the alarm function, logging function, and device monitor. 2. SYSTEM CONFIGURATION ・... -
Page 6: Screen Specifications
4. SCREEN SPECIFICATIONS 4.1 Display Language The language of the text displayed on the screen can be switched between Japanese, English, and Chinese (Simplified). The text strings in each language are registered in the columns No. 1 to No. 3 in the comment groups No. 495 to 500 as shown below. - Page 7 4.2.2 Screen list/transition (individual) Base screen Base screen B-30002: Window screen B-30005: X Device Device Monitor W-30004: X Device Change Check Window screen Base screen Base screen Base screen B-30003: W-30005: B-30006: Y Device B-30001: Menu Alarm Y Device Change Check Window screen W-30006:...
-
Page 8: Explanation Of Screens
4.3 Explanation of Screens 4.3.1 Menu (B-30001) Outline This is the Menu screen. Description Switches to the [Device Monitor] menu screen. Switches to the [Alarm] screen. Switches to the [Logging] screen. Displays the current date and time. Touch the button to open the [Clock Setting] window of the utility. Opens the [Language Setting] window. -
Page 9: Device Monitor (B-30002)
4.3.2 Device Monitor (B-30002) Outline This is the device monitor menu screen. Description Switches to the [X Device] screen. Switches to the [Y Device] screen. Switches to the [M Device] screen. Switches to the [D Device] screen. Switches to each screen. The blue switch indicates the currently displayed screen, thus selecting this switch will not switch the screen. -
Page 10: Alarm (B-30003)
4.3.3 Alarm (B-30003) Outline This screen displays the alarm history. Description Displays alarms. Touch an alarm to display/hide the cursor. These switches operate alarms. : Scrolls the page up and down. : Scrolls alarms up and down line by line. Delete : Deletes only the selected restored alarm. -
Page 11: Logging (B-30004)
4.3.4 Logging (B-30004) Outline This screen displays the values collected with the logging function in numerical values and a historical trend graph. Description Displays the present values of No. 1 to 4 and the cursor display time on the graph. Displays a historical trend graph of the values of No. -
Page 12: Device (B-30005)
4.3.5 X Device (B-30005) Outline This screen allows monitoring and setting of X devices. Description Displays the device range currently monitored. Displays the current device statuses (lamps), device numbers, and comments. Touch a lamp or device number to invert the bit. The change confirmation window is displayed when a change is made. -
Page 13: Y Device (B-30006)
4.3.6 Y Device (B-30006) Outline This screen allows monitoring and setting of Y devices. Description Displays the device range currently monitored. Displays the current device statuses (lamps), device numbers, and comments. Touch a lamp or device number to invert the bit. The change confirmation window is displayed when a change is made. -
Page 14: M Device (B-30007)
4.3.7 M Device (B-30007) Outline This screen allows monitoring and setting of M devices. Description Displays the device range currently monitored. Displays the current device statuses (lamps), device numbers, and comments. Touch a lamp or device number to invert the bit. The change confirmation window is displayed when a change is made. -
Page 15: D Device (B-30008)
4.3.8 D Device (B-30008) Outline This screen allows monitoring and setting of D devices. Description Displays the device range currently monitored. Displays the current device numbers, comments, and device values. Touch a numerical value to change the value. The input confirmation dialog is displayed when a change is made. -
Page 16: Language Setting (W-30002)
4.3.9 Language Setting (W-30002) Outline This window screen allows setting the GOT language. Description Switches the language, and closes the window screen. Closes the window screen. Remarks The system language is also switched corresponding to the display language. 16/21 BCN-P5999-0454... -
Page 17: Y And M) Device Change Check (W-30004 To 30006)
4.3.10 X (Y and M) Device Change Check (W-30004 to 30006) Outline This window screen is used to select whether to invert the on/off of the bit device or to cancel the processing. Description Inverts the on/off of the bit device, and closes the window screen. Closes the window screen without inverting the on/off of the bit device. -
Page 18: System Dialog
4.3.11 System Dialog Outline This window screen is used to select whether to change the word device value or to cancel the processing. Description Changes the word device value, and closes the window screen. Closes the window screen without changing the word device value. Remarks 18/21 BCN-P5999-0454... -
Page 19: Device List
4.4 Device List Some of the devices specified for the on-screen switches, lamps, or others are also used for common settings of functions such as scripts. Using [Batch Edit] is recommended to change these devices in a batch. For details on using [Batch Edit], refer to "GT Designer3 (GOT2000) Help". -
Page 20: Comment List
4.5 Comment List Comment Group No. Comment No. Where comments are used No. 1 to No. 16 B-30005 No. 1 to No. 16 B-30006 No. 1 to No. 10 B-30007 No. 1 to No. 10 B-30008 No. 1 to No. 20 B-30003 (User alarm observation ID 30001) No. -
Page 21: Others
5. OTHERS 5.1 Selecting System Applications Manually Refer to the following procedure to select the system applications that are not selected automatically when writing the package data to a GOT. Example: Selecting Chinese (Simplified) Change the Write Mode to “Select”. Check [Chinese (Simplified)] checkbox.
