Basic Troubleshooting
LED not displayed
Check the power source is correct voltage
and correct polarity.
Display appears scrambled
Check that all connections are correct and tight.
Check that there is no harsh interference nearby.
Just display 1 or -1
Voltage out of range.
Check the connection of signals cable.
Caution
Do not disassemble
The power polarity is not reversed
Installation Size
48mm+0.5
QP5588（8-30VDC Power Source Measure DC50A）
Distributed by:
Electus Distribution Pty Ltd
320 Victoria Rd
Rydalmere NSW 2116 Australia
Phone: 1300 738 555
Fax:
1300 738 500
www.electusdistribution.com.au
Digital Panel Meter
MANUAL
Advertisement
Related Manuals for Electus Distribution QP5588
Summary of Contents for Electus Distribution QP5588
- Page 1 Basic Troubleshooting QP5588（8-30VDC Power Source Measure DC50A） LED not displayed Check the power source is correct voltage and correct polarity. Digital Panel Meter MANUAL Display appears scrambled Check that all connections are correct and tight. Check that there is no harsh interference nearby.
- Page 2 QP5588 Digital Voltmeter WIRING DIAGRAM: Power Source DC8-30V measure DC voltage Power DC 8-30V+ FEATURES: Power DC 8-30V - -Ultra-bright LED display QP5588 Meter Signal Input - -Polarity: Automatic Sensing Signal Input + S B Q -Automatic Calibration upon zero reading for 0V input...
